Maintenance and Adjustment

Bank Angle Indicators

Warning
Use of a motorcycle with bank angle
indicators worn beyond the maximum
limit (as described below) will allow the
motorcycle to be banked to an unsafe
angle.
Banking to an unsafe angle may cause
instability, loss of motorcycle control and
an accident.
Bank angle indicators are located on the
outer edge of the rider's footboards.
Regularly check the bank angle indicators for
wear on the outer edge.
Replace the bank angle indicators when the
bank angle indicator is worn before the
footboard starts to get damaged.
1
cihf_1
1. Bank angle indicator
78

Throttle Control

2
1
cfcd
1. Throttle grip
2. Correct setting 2 - 3 mm
Warning
The throttle grip controls the throttle valves
in the throttle bodies. If the throttle cables
are incorrectly adjusted, either too tight or
too loose, the throttle may be difficult to
control and performance will be adversely
affected.
Check the throttle grip free play in
accordance with scheduled maintenance
requirements and make adjustments as
necessary.
Always be alert for changes in the 'feel' of
the throttle and have the throttle system
checked by an authorised Triumph dealer
if any changes are detected. Changes can
be due to wear in the mechanism, which
could lead to a sticking throttle.
An incorrectly adjusted, sticking or stuck
throttle will lead to loss of motorcycle
control and an accident.
