Parts Identification
Thunderbird LT Shown
1 2 3 4
14 13
cihe
1. Clutch lever
2. Headlight dip switch
3. Fog lamp switch
4. Clutch lever adjuster
5. Speedometer
6. Front brake fluid reservoir
7. Engine stop switch
18
5
TRIP 1 2
12 11
8. Front brake lever
9. Scroll button
10. Starter button
11. Odometer
12. Fuel gauge
13. Horn button
14. Indicator switch
6 7 8
10 9
