Tool Kit And Handbook - Triumph Thunderbird Commander Handbook

Tool Kit and Handbook

1
cigu
1. Allen key
2
3
cigt
1. Pillion seat
2. C-spanner
3. Wire clip
General Information
The tool kit consists of an Allen key for
removal of the rider and pillion seats and a
C-spanner for adjustment of the rear
suspension.
The Allen key is attached to the inside of the
left hand side panel.
The C-spanner is stored under the pillion
seat, behind the handbook. The spanner is
secured in position by a wire clip.
To gain access to the handbook, remove the
pillion seat (see page 40). The handbook is
located on the underside of the pillion seat.
Note:
• The fitting of some accessory kits
requires removal of the original
pillion seat,
handbook. In these circumstances,
ensure the Owner's Handbook is
removed from the pillion seat and
carried with the motorcycle at all
times.
1
which houses the
39
