Quick Start Guide
FLEX ARRAY
The Health and Safety at Work Act 1974
The Supply of Machinery (Safety) Regulations 1992
The Lifting Operations and Lifting Equipment Regulations 1998

GENERAL DESCRIPTION

To take full advantage of the extremely flexible properties of the Flex Array system, the rigging is fully integrated
into the enclosure. The flying systems are inherently safe, flexible, self-contained and simple to use. The load is
taken entirely through the flygear and not through the cabinet's woodwork.
The rigging design allows the creation of clusters and arrays that can be assembled quickly and with a minimum
number of crew, and with full control of the vertical angles between enclosures and their vertical inclination.
RIGGING PARTS
The rigging system consists of steel flygear rebated into the short sides of the loudspeaker enclosure, working
together with integrated drop links which locate into the flygear of the cabinet directly underneath, and form the
pivot point about which cabinets can be angled. The drop links are secured in position with captive ball-lock pins
and retract into the flygear for transportation.
The Flex Array rigging system includes all the necessary hardware to enable vertical suspension of TFA-600 series
cabinets from a single rigging point and using a single motor rated at up to and including 1 tonne.
The rigging system permits a range of inter-cabinet angle adjustment in 2° increments from 0° to 16°. A rear link
locates into a clevis connection plate with multiple holes at the rear of the cabinet.
FB-600 Flybar
A rigid 'T' shaped flybar with screw thread front-to-rear adjustment of the pickup point that enables the
suspension of loads up to the SWL of 700kg. The frame is constructed from a rectangular box section with a
unique formed rear spine that forms a channel in which the movable lift point is located.
A single hang of up to 12 mid/high cabinets, or a combination of mid/high and low frequency cabinets of equal
weight, can be flown using this bar and a single one-tonne motor. The drop links at the front of the bar locate into
the Flex Array cabinet's integrated flygear and are secured with ball-lock pins.
