Features

CPU

1. Supports Intel Pentium MMX CPUs at 100 ~ 233 MHz;
2. Supports Cyrix 6x86(L) CPUs at PR133 + ~ PR200 + MHz
and 6x86MX (MII) CPUs at PR166 + ~ PR350 + MHz;
3. Supports AMD K5: PR100 ~ PR200MHz, AMD K6: 166 ~
333MHz, and AMD K6-2: 250 ~ 350MHz;
4. Suports IDT C6: 200 ~ 225MHz;
5. Provides SOCKET 7 ZIF Socket;
6. Supports 66/75/83/95/100/112/124/133 MHz CPU clock.

Chipset

1. VIA Apollo MVP3 chipset;
2. PCI Rev 2.1 and APM1.1/1.2 compliant.

L2 Cache

1. Onboard supports 512K/1MB write back cache with
Pipelined Burst SRAMs.

Main Memory

1. Memory range from 4MB (minimum) to 768MB
(maximum) with DRAM Table Free configurations;
2. Supports SDRAM with 8/10ns;
3. Supports 3 pcs of 168pin DIMM sockets (3.3V
unbuffered 4 clock type).
Chapter 1
Introduction
Introduction 1
