SOLTEK SL-56D1 User Manual page 3

IDE LED Activity Light: (J1 pin1Ð4)------------------------------ 15
Infrared Port Module Connector (J1 pin6Ð10) ----------------- 15
J1 pin12, 13: ATX Power Button ---------------------------------- 15
J1 pin14, 15: Reserved ----------------------------------------------- 15
Speaker Connector (J2 pin1Ð4) ------------------------------------ 15
Reset Switch (J2 pin5, 6)--------------------------------------------- 16
Power LED and Keylock Switch (J2 pin8Ð12)------------------ 16
JWOL1: Wake On Lan (WOL) Connector ---------------------- 16
Turbo LED (J2 pin14, 15)-------------------------------------------- 17
J1 Switch Signal Summary ----------------------------------------- 18
J2 Switch Signal Summary ----------------------------------------- 19
Chapter 3: BIOS Setup --------------------------------------- 20
Standard CMOS Setup ---------------------------------------------------- 21
BIOS Features Setup ------------------------------------------------------- 23
Chipset Features Setup --------------------------------------------------- 26
Power Management Setup ----------------------------------------------- 29
PnP/PCI Configuration Setup ------------------------------------------ 31
Load Setup Defaults ------------------------------------------------------- 34
Integrated Peripherals ---------------------------------------------------- 35
Supervisor/User Password ---------------------------------------------- 38
IDE HDD Auto Detection ------------------------------------------------ 39
Save & Exit Setup ---------------------------------------------------------- 39
HDD Low Level Format -------------------------------------------------- 39
Exit Without Saving ------------------------------------------------------- 40
Contents iii
