- Page 1 DCS Pro Back 645 DCS Pro Back 645 User’s Guide for the DCS Pro Back 645...
-
Page 2: Table Of Contents
Table of Contents Overview ............10 About This Manual . - Page 3 KODAK PROFESSIONAL DCS Camera Manager (DCS Camera Manager)..28 KODAK PROFESSIONAL DCS Photo Desk (DCS Photo Desk) ....28 KODAK PROFESSIONAL DCR File Format Module (DCR File Format Module) .
- Page 4 Table of Contents IR Filter ..............39 Anti-aliasing Filter .
- Page 5 Attaching the DCS 645 to the Camera Body ....... . .
- Page 6 Table of Contents Configuring Your Camera ..........68 Choosing a Language .
- Page 7 Table of Contents Connecting to the AC Adapter ..........81 Conserving Batteries .
- Page 8 Caring for Your DCS 645 ........
- Page 9 Unsupported Features ..........119 Unsupported or Partially Supported Features (CONTAX 645) ......119 Unsupported or Partially Supported Features (MAMIYA 645AF, MAMIYA 645AFD) .
-
Page 10: About This Manual
CONTAX 645 Contents Back Throughout this manual, your digital camera back is referred to as the DCS 645 unless a particular model is referenced. The term “camera” refers to the camera body with attached DCS 645. The manual does not describe the following:... -
Page 11: Introduction
Thank you for purchasing the DCS 645. The DCS 645 is interchangeable with the camera body’s film magazine, letting you use the camera for digital or film photography. You can use the DCS 645 in portable mode or connected to a computer. Next Index... -
Page 12: Features
Overview Features 16 Megapixel imager (4080 x 4080 pixels) Untethered burst rate: 1 image / 1.8 seconds, burst depth: 8 images (varies depending on camera body image content and type of COMPACTFLASH Card) ISO 100 - 400 Removable IR filter Image Display LCD provides image thumbnails and status of digital features Composite video output jack for viewing... -
Page 13: When Connected To A Macintosh
Overview System Requirements In addition to items included with the DCS 645, your camera body and its accessories, the following items are required: When in Portable Mode COMPACTFLASH Cards Card reader (to move image files to your computer after a photo session) -
Page 14: When Connected To A Pc
If your PC does not have IEEE 1394 ports, you need an OHCI compliant IEEE 1394 card with a free port. IEEE 1394 cable 256 MB of RAM KODAK PROFESSIONAL DCS Camera Manager and DCS Photo Desk Contents Next Index... -
Page 15: Contents Back Next Index
Capture Workflows Capture Workflows This section outlines two general workflows to help you manage images captured on your DCS 645. The workflows may vary between studio sessions and between different types of photography jobs on locations. While there is no simple workflow that will work satisfactorily in all situations, the workflows presented here may be helpful to you. -
Page 16: Capture Workflow When The Camera Is Not Connected To A Computer
Capture Workflows Capture Workflow when the Camera is Not Connected to a Computer Occasional Device & Media Capture & Evaluate Capture Images Transfer Images Preparation Verification Test Images Edit Contents Next Index Back... -
Page 17: Device And Media Preparation
(two or three dozen), you may want to format it (page 66) you will be using so that the full capacity of the card is available and the DCS 645 Recover Card feature (page 67) Insert each CF card... -
Page 18: Capturing And Evaluating Test Images
Before your photo session begins, and a few times during a session, you should capture and evaluate images to be sure that the lighting and camera setup are producing the desired results. Image Attribute DCS 645 Tool Exposure Appearance of image on Image LCD Histogram Display mode exposure information about the overall image. -
Page 19: Occasional Verification
Image LCD using one of several Display modes Connected video monitor Image LCD is disabled when this is in use) Remove the CF card from the DCS 645 and plug it into a laptop computer. View the images using the included software. Next... -
Page 20: Transferring Images
Capture Workflows Transferring Images When the photo session is complete, insert the CF Card in a card reader connected to your computer. You can then open, edit, transfer, copy, archive, and save images using one of several included software applications or send them to a lab. -
Page 21: Editing Images
Capture Workflows Editing Images Several software applications are included on the software CDs. This manual contains a short description of each application. The following table suggests acquire and editing applications, depending on your editing needs and experience: Acquire / Editing Solutions Software DCR File Format Module (page 29) - Page 22 Capture Workflows Third Party Solution Kodak allows third party vendors to develop solutions using a KODAK PROFESSIONAL Software Developer Kit (SDK). Refer to the Web site http://www.kodak.com/go/drg. Contents Next Index Back...
-
Page 23: Capture Workflow When The Camera Is Connected To A Computer
Capture Workflows Capture Workflow when the Camera Is Connected to a Computer Device and Media Connect to Start Software Preparation Computer Capture & Evaluate Occasional Capture Images Edit Test Images Verification Contents Next Index Back... -
Page 24: Connecting To A Computer And Power Supply
Capture Workflows Connecting to a Computer and Power Supply Connect the DCS 645 to your computer and power supply (page 78) Use the included AC adapter power supply. Alternatively you can use a battery (page 57) but the AC adapter provides an unlimited source of power. -
Page 25: Device And Media Preparation
Capture Workflows Device and Media Preparation To help ensure a successful session: Calibrate your monitor and printers regularly, for example, weekly. Set up folders on your computer to hold images as they are captured. Name according to studio needs or procedures. Contents Back Capturing and Evaluating Test Images... -
Page 26: Occasional Verification
Captured images appear on the computer monitor when you are running DCS Camera Manager (page 28) (page 28) Editing Images Refer to Help for KODAK PROFESSIONAL DCS Capture Studio or KODAK PROFESSIONAL DCS Photo Desk. Next Index and DCS Photo Desk... -
Page 27: Kodak Professional Dcs Capture Studio (Dcs Capture Studio)
For complete information, refer to the Help for each application. Images captured on the DCS 645 are saved in a proprietary .DCR format. The included software lets you open .DCR images and save them in a variety of formats. -
Page 28: Kodak Professional Dcs Camera Manager (Dcs Camera Manager)
Using the Included Software KODAK PROFESSIONAL DCS Camera Manager (DCS Camera Manager) Platforms: WINDOWS and MACINTOSH When using the DCS 645 connected to a WINDOWS computer, you must use DCS Camera Manager. When using the DCS 645 connected to a MACINTOSH computer, you must use either DCS Camera Manager or KODAK PROFESSIONAL DCS Capture Studio. -
Page 29: Kodak Professional Dcr File Format Module (Dcr File Format Module)
Using the Included Software KODAK PROFESSIONAL DCR File Format Module (DCR File Format Module) Platforms: WINDOWS and MACINTOSH The DCR File Format Module can be installed as a plug-in to ADOBE PHOTOSHOP. You can then open .DCR camera images directly into ADOBE PHOTOSHOP. -
Page 30: Managing Color
Both software applications work with images captured on a variety of KODAK PROFESSIONAL digital cameras. This section provides an overview of how to best use the color management tools with the DCS 645. It also describes RGB setup in ADOBE PHOTOSHOP. Contents Next Index... -
Page 31: Dcs Capture Studio
If there is none, a default profile is used. Default Source Profile—It is recommended that you choose “DCSPB Daylight Source Correction” to represent how the DCS 645 interprets color in daylight illuminant. Tungsten and Fluorescent are also available. Default Look Profile—Choose “Kodak Professional Product”... - Page 32 Using the Included Software Exposure and Tone Tools Proper use of this tool is critical to image quality. Neutral Reference—To ensure that there is no color cast in a neutral area in an image, click “Enable” then click a gray area of the image. Profiles—Change Camera and Look profiles, if needed.
-
Page 33: Dcs Photo Desk
Using the Included Software Composition Tools These tools let you prepare images for output by cropping, sharpening, and selecting an output profile. Noise Reduction Tools Using these tools you can reduce noise in the following ways: Low—Reduces statistical noise (compares the brightness of pixels in relation to their neighbors and corrects small variations in the image structure) -
Page 34: Setting Up Color In Adobe Photoshop
Using the Included Software Setting up Color in ADOBE PHOTOSHOP When you edit DCS 645 images in ADOBE PHOTOSHOP (not included), you can define the most appropriate RGB color space. ProPhoto RGB is the default RGB color space in both DCS Photo Desk and DCS Capture Studio. -
Page 35: Overview
About the DCS 645 Overview About the DCS 645 Rear Back Contents Front (Attaches to Camera Body) Menu button Tag button Cancel button OK button Four-way switch Battery Release button DCS Pro Back * For your images to be sharp and in focus, you... -
Page 36: Sides
About the DCS 645 Sides DCS 645 Release button Serial Debug port Power port IEEE 1394 port Video Output port Back Contents Next Index Card Busy LED COMPACTFLASH Card slot Card door (open) Card Eject button... -
Page 37: Imager
About the DCS 645 Imager The imager converts light into electrical charges when you capture an image. Its specifications are: Horizontal pixels: Vertical pixels: Total pixels: Horizontal active area (mm): Vertical active area (mm): The imager is located behind the IR or... -
Page 38: Masked Focus Screen
Therefore, an apparent focal length magnification or telephoto effect appears in the captured image. Remove your existing camera focus screen and install the included DCS 645 focus screen. Follow the instructions included with your camera body for changing a focus screen. Back... -
Page 39: Anti-Aliasing Filter
IR Filter A removable IR filter (page 40) the DCS 645. This filter, which is installed in front of the imager, filters out infrared light and helps protect the imager’s coverglass. For your images to be sharp and in focus, you must use either an IR filter or an anti-aliasing filter. -
Page 40: Removing An Ir Or Anti-Aliasing Filter
Contents Inserting a Filter Insert the two tabs at the left side of the filter into the slots on the DCS 645. Gently press the right side of the filter into place until it is latched. Store the unused filter in the pocket of the... -
Page 41: How The Image Lcd Works
About the DCS 645 Image LCD The two-inch diagonal Image LCD on the DCS 645 can be used to review images and change digital settings. When a video monitor (page 121) Image LCD turns off. (Pressing the OK, Cancel, or Menu buttons... -
Page 42: Turning The Image Lcd On And Off
About the DCS 645 Turning the Image LCD On and Off Press the OK button to turn on the Image LCD. Press the Cancel button to turn off the Image LCD. If the LCD is not in Display mode, press the Cancel button again. -
Page 43: Menu Bar
About the DCS 645 Menu Bar The Menu bar is turned off when any Display mode (page 99) is active. It appears when you press the Menu button. The Menu bar appears on the Image LCD and contains icons which access various digital functions. -
Page 44: Menus
About the DCS 645 Menus Many DCS 645 functions can be accessed through the menus on the Image LCD. Some menu screens have OK and Cancel choices. To implement these choices, press the OK or Cancel buttons DCS 645. Making a Menu Selection... - Page 45 About the DCS 645 Menu Hierarchy Next Index Back Contents...
-
Page 46: Displaying The Status Screen
- DCS 645 Battery level f - Current image format - full frame, horizontal, or vertical g - Appears if the DCS 645 is connected to a computer Capture Studio or DCS Camera Manager software is not running... -
Page 47: Digital Buttons
About the DCS 645 Digital Buttons The Four-way switch and the Menu, OK, Tag, and Cancel buttons activate the digital functions. Four-way Switch Press the left or right side to: Navigate through images Navigate the Menu bar Move the Region of Interest box (Zoom... -
Page 48: Quick Guide For Using The Image Lcd And Digital Buttons
About the DCS 645 Quick Guide for Using the Image LCD and Digital Buttons The digital buttons take on different functions, depending on the current state of the Image LCD. Turn on the Image LCD: Select a highlighted menu option:... -
Page 49: Serial Debug Port
About the DCS 645 Ports Serial Debug port Power port IEEE 1394 port Video Output port Back Contents Serial Debug Port For factory use only. Do not insert any plugs into this port. Power Port The included AC adapter or a third party battery is connected here. -
Page 50: Assembling The Camera
Assembling the Camera Do the following before using your camera. Verify that your computer meets system requirements (page 13). Attach the DCS 645 to the camera body (page 51). Connect the following cables, as needed: IEEE 1394 cable (page 78) -
Page 51: Attaching The Dcs 645 To The Camera Body And Connecting Accessories
The Basics Attaching the DCS 645 to the Camera Body and Connecting Accessories Attaching the DCS 645 to the Camera Body To remove the body cap, rotate the DCS 645 Release button to the left and press, then pivot the top of the cap away from the DCS 645. - Page 52 Position the slot at the bottom of the DCS 645 in the locating hook on the camera body and gently press the top of the DCS 645 onto the camera body.
-
Page 53: Disconnecting The Dcs 645 From The Camera Body
Disconnecting the DCS 645 from the Camera Body Place the camera on a table or other flat surface. If the DCS 645 is being powered by battery, remove the battery. If the DCS 645 is being powered by AC adapter, disconnect the AC adapter. -
Page 54: Image Files
The Basics Image Files Images captured using the DCS 645 are saved in a proprietary file format with a .DCR extension. You must use one of the following included software packages to convert the .DCR files to a format such as JPEG or TIFF before you can open, view, or print them using other image editing or processing applications. -
Page 55: Storing Images
Storing Images Images are stored on either a COMPACTFLASH Card (page 62) inserted in the DCS 645 or on the computer hard drive. Refer to the included DCS Capture Studio, DCS Camera Manager, or DCS Photo Desk software Help for instructions on storing images on the computer. -
Page 56: Power Supply
Power Supply Use the included AC adapter when the DCS 645 is connected to a computer. Use the DCS 645 battery or AC adapter when the DCS 645 is not connected to a computer. AC Adapter An 8VDC AC adapter is included with the DCS 645. -
Page 57: Attaching A Battery
The Basics Battery A Battery kit is included with the DCS 645. This includes a DCS 645 battery, a battery charger, and an AC adapter for the battery charger. You must charge a battery before using it for the first time (page 61). -
Page 58: Removing A Battery
The Basics Removing a Battery CAUTION: Hold the battery with one hand or place the camera on a flat surface while removing the battery so it does not drop and become damaged. Press the Battery Release button to remove the battery. Contents Back Next... -
Page 59: Checking Battery Status
The Basics Checking Battery Status Check the Battery icon on Status screen in the Image LCD. Always check the battery status at the following times: When loading a new battery After lengthy storage If the shutter does not release In cold weather Before an important assignment Contents Back... -
Page 60: Battery Charger
(-68°F to 140°F) Charging temperature range: 0°C to 45°C (32°F to 113°F) CAUTION: Use only the DCS Pro Back 645 Series battery charger to charge a DCS 645 battery. Using a different charger can damage the battery or the charger. -
Page 61: Charging Batteries
The Basics Charging Batteries Plug the cable from the charger’s AC adapter into the battery charger port. Select the appropriate included international power cord and plug the AC adapter into a wall outlet. Insert one or two batteries in the slots in the battery charger. -
Page 62: Compactflash (Cf) Cards
The Basics COMPACTFLASH (CF) Cards The DCS 645 has a slot for a solid state or IBM MicroDrive COMPACTFLASH+ Type II Card. When the camera is connected to a computer and DCS Capture Studio is running, images are saved to the computer, regardless of whether a card is present. -
Page 63: Ejecting A Cf Card
The Basics Ejecting a CF Card Open the Card door. CAUTION: The Card Busy LED flashes when images are being accessed. Do not remove the card when the LED is flashing. Doing so could destroy all image files on the card. Contents Back Press the Eject button. -
Page 64: Selecting A Folder
The Basics Selecting a Folder This procedure applies only when you are working in portable mode or using DCS Camera Manager with appropriate options selected. When DCS Capture Studio is running, images are saved on the computer. Use DCS Capture Studio or DCS Camera Manager to select folders on the computer. -
Page 65: Accessing Images On A Cf Card
CF Card or copy them from the card to a folder on the computer’s hard drive. If DCS Camera Manager is installed on your computer, you can copy the image files directly from the tethered DCS 645 to the computer’s hard drive. from the DCS Next... -
Page 66: Formatting A Cf Card
The Basics Formatting a CF Card Occasionally you may need to format a CF Card if it was formatted incorrectly or if the data on the card becomes corrupted. If you have used a CF Card for several sessions (for example, two or three dozen), you may want to format it on the camera you will be using so that the full capacity of the card is available. -
Page 67: Recovering Data On A Cf Card
The Recover Card feature lets you recover image files recently deleted from a CF Card. Files can be recovered if: The card was formatted using a DCS 645 The images were captured using a DCS The files have not been overwritten... -
Page 68: Configuring Your Camera
Configuring Your Camera Configuring Your Camera Choosing a Language You can choose the language in which text appears in the Image LCD. At this time, you can choose between English and Japanese. Highlight the Menu icon (page 43) choose Language from the drop-down menu (page 44). -
Page 69: Setting The Date And Time
Setting the Date and Time A date and time stamp is associated with each image file. Inside the DCS 645, a battery maintains the date and time for up to 14 days. The battery is recharged when the camera is powered. If this battery loses its charge, you must reset the date and time. -
Page 70: Displaying The Properties Menu
Configuring Your Camera Setting Camera Properties You can change the following camera properties: Delay before Battery Save mode activation (page 71) Delay before the Image LCD display turns (page 71) Long exposure processing Default folder for image capture Video format (page 74) In addition, you can view the total number of camera actuations... -
Page 71: Setting Battery Save Onset
Configuring Your Camera Setting Battery Save Onset When the DCS 645 is powered by battery and you don’t touch any controls during the specified Battery Save Onset time, it enters Battery Save state. You can change the onset time from 1:00:00 to 23:59:59 (HH:MM:SS). -
Page 72: Long Exposure
Configuring Your Camera Long Exposure The Long Exposure property reduces accumulated pattern noise in long exposure images. Long Exposure Processing is applied immediately after image capture. As a result, there is a greater lag time between exposures, thereby reducing "burst" mode capture rate and depth. -
Page 73: Total Actuations
Configuring Your Camera Total Actuations You can determine the number of images captured by the DCS 645 from the time of its manufacture. Display the Properties menu Select Total Actuations. The total number of images captured appears. Contents Back Use Folder01 You can change the CF Card’s default image... -
Page 74: Video Format
Configuring Your Camera Video Format You can specify the video standard used to view images on an external monitor NTSC - North America (default) PAL - Europe and Asia Display the Properties menu Select Video Format. Choose NTSC or PAL on the Video Format screen. -
Page 75: Using Job Tracker
Configuring Your Camera Using Job Tracker This feature lets you enter Job Tracker data using DCS Photo Desk or DCS Capture Studio, load the data from a CF Card into camera memory, then include it in image headers. The data follows the International Press Telecommunication Council (IPTC) standard. -
Page 76: Loading Job Tracker Data From A Cf Card
Configuring Your Camera Loading Job Tracker Data from a CF Card Choose Load from Card from the Job Tracker Data menu. Choose a Job Tracker file from the Load Job Tracker Data menu. The file is loaded from the CF Card to your camera. -
Page 77: Using The Camera Connected To A Computer
Before You Begin Using the Camera Connected to a Computer Getting Started Using the Camera Connected to a Computer To start using your camera connected to a computer, do the following. It is not necessary to turn off the computer. Assemble the camera (page Install the included software, as needed... -
Page 78: Connecting The Camera To The Computer And Power Supply
Using the Camera Connected to a Computer Connecting the Camera to the Computer and Power Supply Connect the DCS 645 to a computer and a DCS Pro Back 645 battery or AC adapter. Connecting to a Computer In addition to included accessories, you need a 6-pin plug to 4-pin plug IEEE 1394 cable. -
Page 79: Powering Your Camera
Using the Camera Connected to a Computer Powering Your Camera Turn on the camera body. The DCS 645 activates within 5 - 6 seconds after the AC Adapter or battery starts providing power. If you turn on the Image LCD, it turns off... -
Page 80: Using The Camera In Portable Mode
Using the Camera in Portable Mode Getting Started To start using your camera in portable mode (not connected to a computer), do the following: Assemble the camera (page Insert a DCS 645 battery or connect the AC adapter (page 81). Insert a CF Card (page 62). -
Page 81: Connecting To A Power Supply
Using the Camera in Portable Mode Connecting to a Power Supply When you are working in portable mode, you can use either a DCS 645 battery or the included AC adapter (page 56). Connecting to the AC Adapter Plug the AC adapter into the Power port on the DCS 645. -
Page 82: Battery Save State
Using the Camera in Portable Mode Battery Save State To conserve the battery’s charge, the DCS 645 enters Battery Save state if no DCS 645 controls are touched for a specified period of time. When this happens, the Image LCD and DCS 645 buttons become inactive. -
Page 83: Overview
This section describes operations specific to the DCS 645. Capture images using the Shutter Release button on the camera body. Refer to the User’s Manual for your CONTAX 645, MAMIYA 645AF, or MAMIYA 645AFD. Refer also to the list of features that are not supported... -
Page 84: Image Format
Before You Begin Capturing and Processing Images Image Format The DCS 645 has a square imager that captures images in a square format. You can change this format, if needed. The new format is applied to subsequently captured images. The Masked Focus screen... -
Page 85: Intervalometer
Capturing and Processing Images Intervalometer The DCS 645 has an Intervalometer that automatically captures a sequence of images at specified intervals over a specified time period. You might use the Intervalometer to capture a flower bud opening or for unattended surveillance. -
Page 86: Intervalometer Options
Capturing and Processing Images Intervalometer Options Frame Count Screen: Description: Specifies the number of frames to capture Range: 1-9999 frames Default: 10 frames Contents Back Interval Specifies the interval Specifies the delay between image before onset of the captures Intervalometer function 3 seconds to 23:59:59 1 second to 23:59:59... -
Page 87: Setting Iso
Capturing and Processing Images Setting ISO The DCS 645 supports an ISO range of 100 to 400 at 1/3 stop intervals. The factory default is ISO 100. ISO determines the sensitivity of the imager to light. Increasing or decreasing the ISO increases or decreases sensitivity. -
Page 88: Accessing White Balance
Capturing and Processing Images White Balance The DCS 645 offers both Preset and Click White Balance functionality. There are five Preset options: Auto, Daylight, Tungsten, Fluorescent, and Flash. Choose the setting which represents the dominant type of lighting present when the image was captured. -
Page 89: Click Balance
Capturing and Processing Images Click Balance When you use Click Balance, your clicking of a neutral area in an image helps neutralize color shifts. The neutral areas of subsequent images will have RGB values that are approximately equal. Choosing an Image for Click Balance For Click Balance, choose an image with a MACBETH color chart, a gray card or white card, or a neutral area. - Page 90 Capturing and Processing Images Performing the Click Balance Operation Choose Click Balance from the White Balance menu. Press the OK button to use the current image. A zoomed version of the current image appears with a moveable eyedropper. Contents Back Press any side of the Four-way switch to move the eyedropper over a neutral area.
- Page 91 Capturing and Processing Images Using the Click Balance Menu Choose Click Balance from the White Balance menu. Press the Menu button to display the Click Balance menu. Contents Back Do one of the following: Select a Click Balance setting. Delete a Click Balance setting. Load a Click Balance setting from a CF Card Save a Click Balance setting for reuse...
- Page 92 Back Loading a Click Balance Setting You can load a Click Balance setting that has been saved to a CF Card using KODAK PROFESSIONAL DCS Photo Desk. (A maximum of 10 settings can exist in camera memory.) Choose Load From Card from the Click Balance menu.
-
Page 93: Long Exposure
Capturing and Processing Images Saving a Click Balance Setting You can perform a Click Balance operation on the current image (page 90) then save the settings for reuse. Choose Save (Image number) from the Click Balance menu. Press the OK button. The saved setting replaces the last Click Balance setting saved on the camera. -
Page 94: Processing Images
Capturing and Processing Images Processing Images The DCS 645 supports background image processing that produces JPEG or TIFF RGB files which can be opened directly by many applications and browsers. The choices for processed files are JPEG Good, Better, and Best, and TIFF RGB. JPEG Best files have the least compression, JPEG Good have the most. -
Page 95: Changing Processing Settings
Capturing and Processing Images Choice Images Processed Turns off Processing (if it was on) This is the default. Tagged Images All tagged images on card Tagged in folder All tagged images in selected folder All in Folder All images in selected folder All on Card All images on card Change Settings... - Page 96 Capturing and Processing Images The following screens appear, depending on your choice: Processing Screen Settings Original DCR File Type Contents Back Defaults Underlined Save Saves the DCR image (default). Delete Deletes the DCR image after the processed JPEG file has been saved. It is recommended that you do not choose this option unless you are certain you will not need the original file.
- Page 97 Capturing and Processing Images Processing Screen Settings Resolution Noise Reduction Contents Back Defaults Underlined 100% Aspect ratio is unchanged. Height and width are the same as the original image. Aspect ratio is unchanged. Height and width are reduced to two-thirds. Aspect ratio is unchanged.
- Page 98 Capturing and Processing Images Processing Screen Settings Look Sharpening Level Contents Back Defaults Underlined Portrait Applies a lower contrast tone scale with more detail in the highlights and shadows. Product Applies a higher contrast, more vibrant tone scale. None No sharpening is applied to the finished image. High Applies a sharpening algorithm when the image is processed.
-
Page 99: Selecting A Display Mode
Using the Image LCD Using the Image LCD Reviewing Images You can review images on the active CF Card (page 62) in one of five Display modes: Single Image mode (page 101) Zoom mode (page 101) Histogram mode (page 103) Multiple Image mode (page 104) Delete mode... -
Page 100: Navigating Through Displayed Images
Before You Begin Using the Image LCD Navigating through Displayed Images Press the left or right side of the Four-way switch to navigate through images in the selected folder within the selected Display mode. This works in all Display modes except Zoom mode (page 101) when the Region of... -
Page 101: Single Image Display Mode
Using the Image LCD Single Image Display Mode The thumbnail for the current image appears with the Status bar (page 106) at the left. Zoom Display Mode The thumbnail for the current image appears with a Region of Interest box and crosshairs (page 102). - Page 102 Using the Image LCD Zooming With the Region of Interest box enabled, (page 101) press the OK button. There are three zoom levels. The first actuation zooms to 1:4 (one pixel displayed for every four in the image), the second to 1:1, and the third returns to the un-zoomed 1:16.
-
Page 103: Histogram Display Mode
Using the Image LCD Histogram Display Mode When Histogram mode is active, the active image, its histogram, and the following information appear: Image name Active folder number/name Date and time of image capture Shutter speed Aperture Exposure mode Exposure compensation Back Contents Interpreting a Histogram... -
Page 104: Multiple Image Display Mode
Using the Image LCD Multiple Image Display Mode Four image thumbnails appear with the Status (page 106) at the left. The current image is highlighted. Thumbnails may appear with varying image formats (page 84) as each thumbnail is displayed in its selected image format. Back Contents Next... -
Page 105: Image Delete Display Mode
Press the OK or Cancel button in response to the confirmation screen. (The Cancel button dismisses the screen without deleting the image.) A feedback screen appears for two seconds or until you manipulate a button on the DCS 645. Next Index... -
Page 106: Location Bar
Using the Image LCD Status Bar When image thumbnails are displayed in Single Image or Multiple Image Display mode a Status bar appears at the left of the display. It contains some or all of the following information. Folder # Tag - if image tagged Image number... -
Page 107: Deleting Groups Of Images
Using the Image LCD Deleting Groups of Images You can delete groups of images using a Main menu option. You can also delete single images using Image Delete Display mode To Delete Groups of Images Highlight the Menu icon (page choose Main Menu from the drop-down menu (page 44). -
Page 108: Overexposure Indicator
Using the Image LCD Display Contrast You can change the contrast and lighten or darken the images displayed on the Image LCD panel. Changing contrast does not affect the stored images, only the view of the images on the Image LCD. Highlight the Contrast icon Press the top or bottom of the Four-way switch to move the slider bar up to lighten, or down to... -
Page 109: Tagging Images
Using the Image LCD Tagging Images You can tag one or more images then delete untagged images on the camera. You can also select tagged images in DCS Photo Desk, then perform a variety of operations on the selected images. Select any Display mode except Delete mode (page 99). -
Page 110: Caring For Your Dcs 645
Clean the camera body as described in its User’s Manual. Cleaning the DCS 645 Turn the DCS 645 off and disconnect it from the computer. Using a lint-free cloth with light pressure, clean only the outside enclosures and the Image LCD panel. -
Page 111: Cleaning The Ir Or Anti-Aliasing Filter
Back Storing (page 40). These storage tips apply to the DCS 645. Store the camera body as described in its User’s Manual. If you have an IR or anti-aliasing filter not in use, store it in the pocket on the included body cap. - Page 112 Back When the DCS 645 is removed from the camera body, attach the body cap. Place the slot at the bottom of the DCS 645 in the locating post on the body cap, then press the body cap in place.
-
Page 113: Checking The Current Firmware Version
Caring for Your DCS 645 Firmware Firmware is the software program that runs within the DCS 645 and controls its operation. If a new firmware version becomes available, you can download it from the KODAK Web site and update the firmware within the DCS 645. -
Page 114: Updating Firmware
On a computer with Internet access, go to www.kodak.com, then choose Service and Support. Choose Cameras, Digital from the Professional Photography list, choose DCS 645, then choose Firmware and Host Software. Download the firmware to your computer. Insert a CF Card into the card reader attached to your computer. -
Page 115: Recycling
Caring for Your DCS 645 Recycling The DCS 645 contains lead and mercury. Disposal of lead and mercury may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or the Electronics Industry Alliance: www.eiae.org. -
Page 116: Differences Between The Mamiya 645Af And The 645Afd
There are two models of the MAMIYA 645AF film camera body. The original version is labeled 645AF on the body's left side, the newer version is labeled 645AFD. While both models function with the DCS 645, the 645AFD model has slightly better performance and interfaces better with the DCS 645. A comparison... - Page 117 Before You Begin Differences Between the MAMIYA 645AF and the 645AFD Settings / Metadata Shutter Aperture Compensation Exposure mode Focal length Get = DCS Camera Manager gets information from the camera body. Set = DCS Camera Manager can output to and set on the camera body.
-
Page 118: Specifications
16 million pixels (4080 x 4080) 2-inch diagonal LCD provides image thumbnail, adjustable contrast, and status of digital features Transfers images from the DCS 645 to a computer running DCS Capture Studio or DCS Camera Manager software DCS 645 battery 8VDC Approximately 1.7 pounds (with CF Card and body cap) -
Page 119: Unsupported Or Partially Supported Features (Contax 645)
Unsupported Features Unsupported Features Unsupported or Partially Supported Features (CONTAX 645) Unsupported: Shutter speeds greater than 1/4 second unless Long Exposure Processing is used ISO outside of the range 100 - 400 Multiple exposure Frame rate of 1.6 frame/second in continuous shoot (“C”... -
Page 120: Unsupported Or Partially Supported Features (Mamiya 645Af, Mamiya 645Afd)
645AFD model: Use the flash adapter SCA3952. Adjust the flash output by using the camera body’s flash exposure compensation function. Verify exposure using the DCS 645 histogram. 645AF model: Use the flash adapter SCA3951. If available, adjust the flash output by using the strobe’s exposure compensation function. -
Page 121: Using A Video Monitor
Using a Video Monitor Using a Video Monitor You can review images on an external video monitor. This provides a larger version of the image displayed on the Image LCD. When the external monitor is enabled, the Image LCD turns off. When you capture an image, it automatically appears on the connected video monitor. -
Page 122: Navigating Through Images
Using a Video Monitor Enabling Highlight the Menu icon (page 43) choose Main Menu from the drop-down menu (page 44). Choose External Video from the Main menu. Choose On from the External Video screen. A Video icon appears on the Menu bar. Back Contents Highlight the Video icon. -
Page 123: Electromagnetic Emissions
Overview Electromagnetic Emissions Japan This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective action. Taiwan Contents Next... -
Page 124: European Union (Eu)
Overview European Union (EU) Warning: This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. -
Page 125: Warnings And Cautions
Use only the power source type indicated on the name plate of the AC adapter. A line voltage outside this range can destroy the AC adapter and/or the DCS 645. Do not remove a CF Card from the camera, remove a battery pack, or disable the AC adapter while the Card Busy LED inside the Card door is blinking. - Page 126 This will prevent battery discharge, and/or damage due to battery leakage. Do not use the DCS 645 where it can come in contact with water. It is not waterproof or splash-resistant. 13).
-
Page 127: Glossary
DCS 645 Back Contents .DCR files Image files created by the DCS 645 which can only be opened using the included DCS Capture Studio or DCS Photo Desk software DCR File Format Module Included software application which can be installed as a plug-in to ADOBE PHOTOSHOP. - Page 128 An IEEE 1394 accessory that lets you connect a number of IEEE 1394 peripherals to a computer. To be compatible with the DCS 645, use a hub which conforms to the IEEE 1394 standard (hot pluggable, can send and receive...
- Page 129 Glossary Image format In the DCS 645, image format refers to cropping of images as they are captured. Choices are: 5x5, 4x5, and 5x4 Image LCD A two-inch diagonal LCD where you can view images and change settings on the DCS 645...
-
Page 130: Warranty
Kodak warrants your KODAK PROFESSIONAL DCS 645 internal electronics and mechanical assemblies to be free from defects in material and workmanship for 1 year from the day of purchase. Kodak warrants the Imager to be free from defects in material and workmanship for 4 years from the date of purchase. -
Page 131: Warranty Repair Coverage
If this equipment does not function properly during the warranty period due to defects in material or workmanship, Kodak will, at its option, either repair or replace the equipment without charge, subject to the conditions and limitations stated herein. Such repair service will include all labor as well as any necessary adjustments and/or replacement parts. - Page 132 Warranty Should you need to return equipment to Kodak, Kodak is not responsible for the loss or damage of equipment while in transport to a Kodak authorized service center. You may, at your option, choose to insure equipment for loss or damage with the carrier of your choice.
-
Page 133: Outside The United States
In countries other than the United States, warranty terms may be different. Unless a specific Kodak warranty is communicated to the purchaser in writing by Kodak, no warranty or liability exists even though defect, damage or loss may be by negligence or other act of Kodak. -
Page 134: How To Obtain Service
How to obtain service See your authorized Kodak dealer. If service is required, your Kodak dealer will instruct you to return the unit to the nearest service center for repair and will issue a return authorization number. When returning a KODAK PROFESSIONAL DCS 645 for repair, you should pack the unit in its original packing materials according to the repacking instructions located on the shipping container. - Page 135 Out-of-Warranty Support Options There will be a charge for out-of-warranty call incidents if you wish to speak to a Kodak support representative. A call incident is defined to include only those issues raised during the first telephone or e-mail contact.
- Page 136 Service maintenance agreements, which cover the repair and support of the DCS 645 and software are available. In North America, contact the regional Service Marketing group at 1-800-645-6325 No-charge options include: KODAK PROFESSIONAL World Wide Web site: http://www.kodak.com/go/support...
- Page 137 Firmware. See Firmware 113 Camera properties. See Properties 70 Cancel button 47 Capture software 24 CF Cards 62 Cleaning 110 DCS 645 110 IR or anti-aliasing filter 111 Click Balance Deleting a setting 92 Loading a setting 92 Performing 90...
- Page 138 Computer, Connecting to 78 Connecting AC adapter 81 Camera to the computer and power supply 78 DCS 645 to the camera body 51 Contrast, Changing on Image LCD 108 Date and time 69 DCR File Format Module 29 DCS 645...
- Page 139 Index Ejecting a CF Card 63 Electromagnetic emissions 123 Evaluating images When connected to computer 25 When not connected to computer 18 Features 12 Unsupported 119 Files, See Image files 54 Filters Anti-aliasing 39 IR 39 Firmware 113 Checking version 113 Updating 114 Focus screen 38 Folder01 as default 73...
- Page 140 Index Deleting groups of 107 Deleting one 105 Formatting 84 Reviewing 99 Storing 55 Included software 27 Inserting a CF Card 62 Intervalometer 85 Options 86 Introduction 11 IPTC data 75 IR filter 39 Cleaning 111 Storing 111 ISO 87 Job tracker 75 Job tracker data, Loading from Card 76 Contents...
- Page 141 Index In Zoom mode 102 OK button 47 Overexposure indicator 108 Pan/Zoom mode Enabling or Disabling the Region of Interest box 101 Panning 102 Zooming 102 Panning 102 PC Cards, See COMPACTFLASH Cards Portable mode 80 Ports and Jacks 49 IEEE 1394 49 Powering the camera In portable mode 81...
- Page 142 Managing color 30 Software CDs 27 Specifications 118 Status bar 106 Status screen 46 Storing images 55 Storing the DCS 645 111 Storing the IR or anti-aliasing filter 111 System requirements 13 Contents Back Tag button 47 Tagging images 109...
-
Page 143: Contents Back Next Index
Index Warnings and cautions 125 White Balance 88 Click Balance, See Click Balance 89 Workflow 15 When camera is connected to computer 23 When camera is not connected to computer 16 Zoom Display mode 101 Navigating through images in 102 Zooming 102 Contents Back... - Page 144 DCS Pro Back 645 DCS Pro Back 645 EASTMAN KODAK COMPANY Kodak Professional Division Rochester, New York 14650 www.kodak.com/go/professional © Eastman Kodak Company, 2002. TM: Kodak, Kodak Professional P/N 4E6141...
Need help?
Do you have a question about the 645 and is the answer not in the manual?
Questions and answers
