THE COMMUNITY ENTASYS COLUMN ARRAY
ENT‐FR
ENTASYS Full‐Range Column
Three-Way, Full-Range
200 Hz – 20 kHz
66 Driver elements:
LF: (6) 3.5"
MF: (18) 2.35"
HF: (42) 1" x 1"
(configured as six 1" x 7" Compact Ribbon Emulators™)
600 Watts continuous, 1500 Watts program, 12 ohms
Available nominal coverage pattern:
120˚ x 12˚ or 120˚ x 6˚
Sensitivity: Curved (12˚V): 93dB, Straight: (6˚V): 95dB
Maximum SPL: Curved (12˚V): 120 dB,
Straight: (6˚V): 122 dB
Vertical coverage angle varies by system configuration,
frequency and listener distance.
Community ENTASYS Application Guide - Page 2
ENT‐LF
ENTASYS Low Frequency Column
Low Frequency driver array for added directivity
control and output level
200 Hz – 1.6 kHz
LF: (6) 3.5"
600 Watts continuous, 1500 Watts program,
12 ohms
Sensitivity: 90 dB
Maximum SPL: 116 dB
Variable vertical coverage based on the number of units
arrayed.
