MEGA TRI38 SYSTEM
tion also allows you to use your fixtures as spot lights. The MEGA TRI38
SYSTEM has 3 DMX modes: 6 Channel mode, 12 Channel mode, and a
15 Channel mode. See pages 12-15 for each modes' DMX traits.
1. This function will allow you to control each individual fixture's traits
with a standard DMX 512 controller.
2. To run your fixture in DMX mode press the MODE button until
"d-P.X" is displayed. "X" represents the current displayed DMX chan-
nel mode. Use the UP or DOWN buttons to select your desired
DMX channel mode. See the next page for the DMX Channel Modes.
3. Once you have chosen your desired DMX Channel mode press the
SETUP button to set your DMX address. Use the UP or DOWN but-
tons to adjust the DMX address.
DMX Channel modes:
• To run the 6 Channel Mode, press the MODE button until "d-P.X"
is displayed. Press the UP or DOWN buttons until "d-P.1" is dis-
played. This is the 6 Channel DMX Mode.
• To run the 12 Channel Mode, press the MODE button until "d-P.X"
is displayed. Press the UP or DOWN buttons until "d-P.2" is dis-
played. This is the 12 Channel DMX Mode.
• To run the 15 Channel Mode, press the MODE button until "d-P.X"
is displayed. Press the UP or DOWN buttons until "d-P.3" is dis-
played. This is the 15 Channel DMX Mode.
4. Please see pages 12-15 for DMX values and traits.
5. After you have chosen your desired DMX Channel mode and
address plug in the fixture via the XLR connections to any standard
DMX controller.
ADJ RC4 (Remote Control) On/Off:
This function is used to activate and deactivate the ADJ RC4 (Remote
Control). When this function is activated you can control the fixture
using the ADJ RC4. Please see page 11 for controls and functions.
1. Plug the fixture in and press the MODE button until "AUTO" is dis-
played.
2. Press the SET UP button until "Ir.XX" is displayed. "XX" represents
either "on" or "oF".
3. Press the UP or DOWN buttons to either activate the remote func-
tion (On) or deactivate it (Off).
ADJ Products, LLC - www.adj.com - MEGA TRI38 SYSTEM User Manual Page 9
Operating Instructions MEGA TRI38 SYSTEM
Master-Slave Configuration:
This function will allows you to link units together to run in a Master-Slave
mode. In Master-Slave operation one unit will act as the controlling unit
and the others will react to the controlling units built-in programs. Any
unit can act as a Master or as a Slave however, only one unit can be pro-
grammed to act as the "Master."
Master-Slave Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the unit.
Use standard XLR data cables to link your units together. Remember
that the Male XLR connector is the input and the Female XLR con-
nector is the ouput. The first unit in the chain (master) will use the
female XLR connector only. The last unit in the chain will use the
male XLR connector only.
2. Set the "Master" system to your desired mode of operation.
3. On the "Slave" system, press the MODE button until "Slav" is dis-
played. Once "Slav" is displayed connect the "Slave" system to the
"Master." The "Slave" system will now follow the "Master".
MEGA TRI38 SYSTEM
The wireless foot controller has 4 different functions. To activate the
foot controller press any pedal once.
BLACKOUT - Pressing this pedal will blackout the fixture.
SOUND - This pedal activates sound active mode.
PROGRAM - This pedal will activate program mode and cycle
through programs 2-12 with each press of the pedal.
COLOR - This pedal activates color macro mode and each press of
this pedal switches to the next color. There are 32 colors to choose
from.
ADJ Products, LLC - www.adj.com - MEGA TRI38 SYSTEM User Manual Page 10
