Instruction Manual
To ensure maximum performance and safety,
please follow this manual. Please retain the
manual for future reference after installation

Advertisement

loading
Need help?

Need help?

Do you have a question about the Slick a7 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vibe Slick a7

  • Page 1 Instruction Manual To ensure maximum performance and safety, please follow this manual. Please retain the manual for future reference after installation...
  • Page 2: Table Of Contents

    OWNERS MANUAL Thank you for purchasing this VIBE amplifier. It will provide you with a lifetime trouble free usage providing you follow a few simple guidelines. CONTENTS Mounting Guidelines......Connections........... Setup Section........5,6 Applications..........7,8 Trouble shooting........Specification........... 10 Warranty..........10...
  • Page 3: Mounting Guidelines

    Mounting Guidelines Your VIBE amplifier is designed with a swift installation routine in mind. Please mount the amplifier in a dry location on a solid surface. NEVER mount the amplifier upside down, this will cause the amplifier to over heat and will eventually damage the amplifier.
  • Page 4 Ground Cable ● The ground cable needs to carry the same current as the power cable. At least an 8 gauge cable should be used. ● The amplifier ground should be connected directly to the chassis of the vehicle, to bare metal. ●...
  • Page 5: Setup Section

    1. Low Level Input For connection to any source (head unit) with a low level output. This is your RCA output from the source (headunit). 2. High Level Input To be used when no RCA's are available. Use the provided loom to connect to closest speakers. The loom conector will only fit one.
  • Page 6: Setup Section

    Set Up Section To correctly set the gain control of the amplifier to match that of the source (headunit) use the following setup routine: Turn the gain control to minimum on the amplifier. Ensure the bass boost is set to 0 dB. On the headunit set all crossovers to flat and both bass and treble to zero.
  • Page 9: Troubleshooting

    Check that the negative wire is connected to the ground terminal on the amplifier. ✓ Ensure that the correct rated fuse is fitted: VIBE SLICK a7 –20 amp x 2, 15 amp x 2 Distorted Sound ✓ Check the gain control is not set at too high a level. If the speakers sound distorted turn the down the gain until the sound is clear.
  • Page 10: Specification

    Specification Model Slick a7 RMS power @ 13.8 vDC Power @ 4 ohms 1 x 300 WRMS Power @ 2 Ohms 1 x 600 WRMS Power @ 1 Ohm 1 x 1300 WRMS Minimum speaker impedance 1 ohm THD Distortion 0.1 %...
  • Page 11: Accessories

    ACCESSORIES Accessories can be ordered separately from the VIBE website www.vibeaudio.co.uk Only available in the UK If out side uk please contact your dealer or distributer from the VIBE website GT - 2V Terminal Flat Y - Interconnect Power 8 Wiring Kit...
  • Page 12 For the avoidance of doubt, VIBE does not limit its liability for death or personal injury to the extent...
