Summary of Contents for Vibe Slick a2
- Page 1 Power Amplifier Instruction Manual To ensure maximum performance and safety, please follow this manual. Please retain the manual for future reference after installation...
-
Page 2: Table Of Contents
OWNERS MANUAL Thank you for purchasing this VIBE amplifier. It will provide you with a lifetime of trouble free usage providing you follow a few simple guidelines. CONTENTS Mounting Guidelines......Connections........... Setup Section........Applications..........7,8 Trouble shooting........Specification........... 10 Warranty..........10 Accessories.......... -
Page 3: Mounting Guidelines
Mounting Guidelines Your VIBE amplifier is designed with a swift installation routine in mind. Please mount the amplifier in a dry location on a solid surface. NEVER mount the amplifier upside down, this will cause the amplifier to over heat and will eventually damage the amplifier. - Page 4 Ground Cable ● The ground cable needs to carry the same current as the power cable. At least an 8 gauge cable should be used. ● The amplifier ground should be connected directly to the chassis of the vehicle, to bare metal. ●...
- Page 5 1. Low Level Output A daisy chain output For connection to another amplifier with a low level input using only a single RCA output from the source (headunit). 2. Low Level Input For connection to any source (head unit) with a low level output. This is your RCA output from the source (headunit) Gain Control Used to match the input signal of the source to the amplifier.
-
Page 6: Setup Section
By using the crossovers correctly you will not only lengthen the life of your speakers but you will also get better performance from them. To optimise your setup seek the advise of a professional installation engineer or visit your local VIBE audio dealer. -
Page 9: Troubleshooting
Check that the negative wire is connected to the ground terminal on the amplifier. ✓ Ensure that the correct rated fuse is fitted: VIBE SLICK a2 –15 amp x 2, Distorted Sound ✓ Check the gain control is not set at too high If the speakers sound distorted turn down the gain until the sound is clear. -
Page 10: Specification
Specification RMS Power @ 13.8v DC Power @ 4 Ohms 2 x 100 WRMS Power @ 2 Ohms stereo 2 x 160 WRMS Power @ 4 Ohms bridged 1 x 325 WRMS Minimum speaker impendence 2 Ohms THD Distortion 0.08% IMD Distortion 0.08% Frequency Response... -
Page 11: Accessories
ACCESSORIES Accessories can be ordered separately from the VIBE website www.vibeaudio.co.uk Only available in the UK If out side uk please contact your dealer or distributer from the VIBE website GT - 2V Terminal Flat Y - Interconnect Power 8 Wiring Kit Power 4 Wiring Kit Our gold plated binding post speaker This 8 AWG kit includes a 60 amp AGU... - Page 12 Limited Warranty All VIBE products carry a full twelve months warranty, valid from the date of the original receipt / proof of purchase. In order to validate this warranty, the warranty card should be returned to VIBE within seven days of the original purchase date. The original receipt and packaging should also be retained for this twelve month period.
