  • Page 1 User's Manual For WiPG-1500S (January 14) Version: 1...

  • Page 2: Table Of Contents

    Table of Contents VERVIEW ACKAGE ONTENTS USB T OKEN ONTENTS HYSICAL ETAILS IGHT UICK NSTALLATION PG-1500 S TART TANDBY UICK UIDE EATURE CONS (UST/U EMOTE OUCH ONTROL ONFERENCE ONTROL IRECT UNCTION NDER ROJECTING I FOR INDOWS UPPORT INDOWS HONE INDOWS NSTALL THE APPLICATION TART THE APPLICATION UICK...
  • Page 3 8.10.14 OWER ANAGER 8.10.15 ONNECT 8.10.16 USB P OKEN 8.10.17 PPLICATION TO DESKTOP 8.10.18 8.10.19 BOUT 8.10.20 I FOR NSTALL THE APPLICATION TART THE APPLICATION UICK ONNECT ONNECT TO ETWORK ONNECT TO ECEIVER EVICE OGIN NTERFACE ROJECTION OGIN CODE 9.10 9.10.1 ECEIVER NFORMATION...
  • Page 4 10.4.3 ETWORK ETUP 10.4.4 OSD S ETUP 10.4.5 LIDES ETUP 10.4.6 HANGE ASSWORDS 10.4.7 ESET TO EFAULT 10.4.8 IRMWARE PGRADE 10.4.9 EBOOT YSTEM 10.4.10 OGOUT 10.5 LIDES AFETY 11.1 OMPLIANCE...

  • Page 5: Overview

    Overview WiPG-1500 is a spectacular wireless presentation device which connects multi-platform devices (Windows/Mac/Pad/Smartphone/AirPad) for engaging interactive presentations by supporting finger-touch technology, virtual whiteboard and Win 7/8 HID conformable remote devices. WiPG-1500 Highlight Features: Icon Feature Description DoWiFi Wireless presentation for Windows and Mac ...

  • Page 6: Key Features

    Plug&Show: launching the projection application from a USB Token without  installation. Extra USB tokens with the PlugandShow function can be easily created in the wePresent software. High performance 4-to-1 Quadrant Screen Projection  Support up to 64 concurrent login users ...

  • Page 7: Package Contents

     and GateKeeper HDMI and VGA dual video interfaces  WiFi AP and AP-Client mode Make WiPG-1500 a part of your wired or  wireless network. Allowing internet access to all connected users and presentation from network computers. WiFi 802.1b/g/n ...

  • Page 8: Physical Details

    Physical Details Front Panel  Power Button and LED USB Port Description Power Button and LED Power on/off button. LED Indicator: System Loading(Red), Ready(Green) USB Port (Front) 2 USB ports for USB mouse and keyboard...
  • Page 9 Rear Panel  VGA Connector Audio Jack HDMI RJ-45 Antenna USB Port Antenna Power Jack Description Antenna WiFi Antenna USB Port (Rear) USB port for USB IWB device (HID type) RJ-45 10/100M RJ-45 port VGA Connector VGA connector HDMI HDMI Connector Audio Jack Audio Jack (3.5mm) Power Jack...

  • Page 10: What You Might Need

    Bottom Side  Screw hole Reset Button (Optional kit for Wall Mount) Description Screw Hole Screw Hole for Wall Mount Kit Reset Button Press reset button and power on the device to execute Hardware Reset. What You Might Need Projector/display with VGA/HDMI interface ...

  • Page 11: Quick Installation

    2) Connect the power adaptor to WiPG-1500 device and press the power button to turn on WiPG-1500 device. System will be ready when the LED light turns to green.  It will show the default standby screen as below when system is ready.

  • Page 12: Ipg-1500 Start /Standby

    WiPG-1500 Start/Standby Page Quick Guide / User-List When there is any new user connected to WiPG-1500, the user name will be show on the user-list area. WiPG-1500 allows multiple user connection. See below image for detail. Feature Icons 1) You can also click on the feature Icons on the right hand bottom to view the Quick Guide for each highlight feature.
  • Page 13 Apps.（See below image） (3) SidePad: Click on SidePad icon , it describes WiPG-1500 support SidePad feature which allow users control the projecting screen on PC or Mac via iPhone/iPad or Android devices. If your Smartphone has QR code scan App, you can scan the QR code image on the screen with your Smartphone which will lead you to the corresponding place to download all the available Apps.（See below image）...
  • Page 14 (4) WebSlides: Click on WebSlides icon . It describes WiPG-1500 support WebSlides feature which can broadcast slides to audience’s web browser through network. (5) UST/UoIP: Click on UST icon . It describes WiPG-1500 support UST(Universal Single Touch) which can support standard single touch device without installing driver, and UoIP(USB over IP) which support standard HID device through network.

  • Page 15: Remote Touch Control (Ust/Uoip)

    Remote Touch Control (UST/UoIP) WiPG-1500 can support standard Win7/8 compatible HID touch device. By connecting the HID touch screen/IWB device, users can control the standby screen, direct draw and the projecting screen remotely from the Touch Screen/IWB device.

  • Page 16: Conference Control Mode

    Conference Control Mode 1) Click to enable conference control mode. 2) Click to disable conference control mode. Direct Draw 1) Click on the “direct draw” button on the start page to enter “direct draw” function page. You can make the free drawing on device screen through Mouse, AirPad, Touch Screen or IWB device.
  • Page 17 Description Minimize all Pen menu bar. Click to open up the entire pen menu. Go back to wePresent home standby screen. Clear all of the drawing/writing on the screen. Erase part of drawing/writing. Select the pen color. (Red, Green, Blue) Select the size of the pen.

  • Page 18: Pen Menu Function Under Projecting Mode

    Click this button to enable conference control mode. Click this button to disable conference control mode. Minimize all Pen menu bar. Click to fold up or extend the pen menu. 、 Click to open up the entire pen menu. Home, Go back to wePresent home standby screen.
  • Page 19 Clear all of the drawing/writing on the screen. Erase part of drawing/writing. Select the color and size for Pen mode. (Red, Green, Blue) Select the size of the pen. (Small, Medium, Big) Enable the magnifier function. Change to Mouse mode for remote control function. Change to Pen mode for drawing/writing function.

  • Page 20: O W I F I For Windows

    8.1 Install the application 1) Make sure your PC WiFi is enabled already, and connect your PC to wePresent WiPG-1500 box through WiFi. You can find the WiFi name of your WiPG -1500 box information on the start/standby page. 2) Launch your browser and enter the Device Host Name (SSID) or IP address in the browser.

  • Page 21: Start The Application

    4) When the download is completed, follow the wePresent WiPG Setup wizard to execute the software. (Make sure your Wifi have connected to WiPG-1500-xxx and your PC’s personal firewall allows wePresent WiPG-1500 software to pass through.) 8.2 Start the application...

  • Page 22: Quick Connect

    (you can find the information on the standby screen or start screen) and press the “Connect” button to connect this WiPG-1500 directly. 2) If you want to connect to another WiPG-1500 receiver, please press the “Rescan” button. 8.4 Connect to WiFi Network 1) WiPG-1500 application will search the available WiFi Network and list the WiPG-1500 WiFi Device.
  • Page 23 2) You can press the “Refresh” button to search again or press the “All” button to list all available WiFi Network name. 3) If you don’t like to change the WiFi Network and want to keep the connection to current network, you can press the “Skip” button.

  • Page 24: Connect To Receiver Device

    8.5 Connect to Receiver Device 1) WiPG-1500 application will search and list the WiPG-1500 receiver Device. You can select the target receiver device and press “OK” button to connect the selected receiver device. 2) You can press the “Refresh” button to search again.

  • Page 25: Login

    8.6 Login 1) When connecting to a “Code” protection enabled WiPG-1500 receiver, you have to enter the “Code” and press the “Connect” button to login the receiver. (You can find the CODE from the OSD standby screen or right-upper corner of start...

  • Page 26: Main User Interface

    Login Code Menu 8.7 Main User Interface Minimize the window Close the window Control Area for Screen Status Indicator Projection Feature 8.8 Screen Projection 1) Click the “Play” button for full or “1,2,3,4” for split screen projection, you can project the main screen on to the display immediately. Click the “Pause” button, you can freeze you projection screen, and click the “Stop”...

  • Page 27: Login Code

    Note: When projecting in full screen projection, if another user is clicking on the play button, the new user’s screen will replace the previous user’s screen for projection. When projecting in Quad view mode, if another user is clicking on the selected screen button(#1, #2 , #3, #4 ), the new user’s screen will replace the previous user’s screen for projection.

  • Page 28: Show Receiver Information

    2) You can click on the below function for extending menu to choose one to suit your needs. function Select Projection Desktop Projection Quality Projection Mode Resolution Setting Projection Aspect Ratio 3) The below items are checked as default setting. You can uncheck them to suit your needs.

  • Page 29: Launch Sidepad

    8.10.4 Launch SidePad Introduction: SidePad is an application to allow the user to connect Pad/Smartphone (Android and iOS), PC, and display/projector via WiPG-1500 device. User can then control the projecting PC via Pad/Smartphone. Please refer to the below image for more information.

  • Page 30: Launch Webslides

    Note: Webslides is not available when Quad view is in use. 1) Presenter: Make sure your PC/Mac is connected to WiPG-1500 box and click on “Launch Webslides”, when the function is on, the item will be checked on the main menu.
  • Page 31 Note The WiPG-1500 logged-in user is not identical to WebSlides user, and they both consume the wireless bandwidth for device connection. If there are more than 10 users logged into WiPG-1500, it is recommended to connect WiPG-1500 to company network through Ethernet or bridge WiPG-1500 to a router due to wireless bandwidth concern.

  • Page 32: Select Projection Desktop

    This typically can be verified by checking whether it can enable the extended screen through physical VGA cable, if yes, then it should work with wePresent software. 8.10.7 Projection Quality 1) Click on “Projection Quality”, choose “Normal” for faster projection speed with lower screen image quality, and “Best”...

  • Page 33: Resolution Settings

    8.10.10 Projection Aspect Ratio 1) Click on “Projection Aspect Ratio”, choose “Keep aspect ratio” to keep the original aspect ratio if the desktop resolution is different from WiPG-1500 output resolution, or choose “Fit full screen” to project the screen to full screen.

  • Page 34: Advanced Screen Capture

    8.10.12 Advanced Screen Capture 1) Click on “Advanced Screen Capture”, you will be able to see tip windows and other layered windows (include the main UI) on the connected display. However, the mouse cursor may blink from time to time when you are projecting your PC screen! ...

  • Page 35: Auto Power Manager

    8.10.16 Make USB PnS Token 1) Click “Make USB PnS Token” to make a USB wePresent WiPG-1500 Token, you can insert a USB and follows the wizard to make the Token. After completion, you can plug the USB to any PC to do the projection without installing the wePresent WiPG...

  • Page 36: Copy Application To Desktop

    8.10.17 Copy Application to desktop 1) Click on “Copy Application to desktop”, it will copy the application to your desktop immediately. 8.10.18 Hot Key 1) Click on “Hot Key” to display the available Hot Key definition. 8.10.19 About 2) Click on “About” to show system information. It includes product model name, Application version, IP address and other information.

  • Page 37: Exit

    8.10.20 Exit 1) Click on “Exit” to exit this application. It will stop current playing status and shut down the application immediately.

  • Page 38: O W I F I For Mac

    DoWiFi for Mac Install the application 1) Make sure your PC WiFi is enabled and connect your PC to wePresent WiPG-1500 box through WiFi. 2) Launch your browser and enter the IP address on browser. You can find the IP address and Host Name (SSID) on the projector/display screen.

  • Page 39: Start The Application

    Start the application 1) Click on wePresent WiPG-1500 icon from Application folder to execute the application. 2) It will start to search wePresent WiPG-1500 receiver automatically.

  • Page 40: Quick Connect

    (you can find the information on the standby screen) and press the “Connect” button to connect this WiPG-1500 directly. 2) If you want to connect to another WiPG-1500 receiver, please press the “Rescan” button. Connect to WiFi Network 1) WiPG-1500 application will search the available WiFi Network and list the WiPG-1500 WiFi Device.
  • Page 41 2) You can press the “Refresh” button to search again or press the “All” button to list all available WiFi Network name. 3) If you don’t like to change the WiFi Network and want to keep the connection to current network, you can press the “Skip” button.

  • Page 42: Connect To Receiver Device

    Connect to Receiver Device 1) WiPG-1500 application will search and list the WiPG-1500 receiver Device. You can select the target receiver device and press the “Connect” button to connect the selected receiver device. 2) You can press the “Refresh” button to search again.

  • Page 43: Login

    Login 1) When connecting to a “Code” protection enabled WiPG-1500 receiver, you have to enter the “Code” and press the “Connect” button to login the receiver. (You can find the CODE from the OSD standby screen or right-upper corner of start...

  • Page 44: Projection

    9.8 Projection 1) Click the “Play” button for full or split screen, you can project the main screen on to the display immediately, click the “Pause” button, you can freeze you projection screen, and click the “Stop” button to stop projecting your screen. Button Description Full Screen projection (Support audio...

  • Page 45: Login Code

    Login code Press on the login code, you can find the device IP address, SSID name on the up left corner and login code on the up right corner. The information will disappear after 30 seconds. When there are other users trying to login to the device, the information will pop up automatically for seconds and disappear again as well.

  • Page 46: Show Receiver Information

    3) The below items are checked as default setting. You can uncheck them to suit your needs. Item Advanced Screen Capture Send Audio to Display Auto Power Management Auto WiFi Connect 9.10.1 Show Receiver Information 1) Click on “Show Receiver Information”, it will display the Receiver Information, such as WiFi Name, IP Address and code on the upper corners of the projecting screen, and it will close automatically after 30 seconds.

  • Page 47: Launch Sidepad

    Android: Download “‘SidePad Receiver” from Google Play Store  iOS: Download “‘SidePad Receiver” from Apple Store.  Connect your Android device to WiPG-1500 device through WiFi and Launch “‘SidePad Receiver”  Click on “Launch SidePad” from the menu. In seconds, you shall see the PC desktop shown on the iOS/Andriod Device.

  • Page 48: Launch Webslides

    Note: Webslides is not available when Quad view is in use. 1) Presenter: Make sure your PC/Mac is connected to WiPG-1500 box and click on “Launch Webslides”, when the function is on, the item will be checked on the main menu.
  • Page 49 Note: The WiPG-1500 logged-in user is not identical to WebSlides user, and they both consume the wireless bandwidth for device connection. If there are more than 10 users logged into WiPG-1500, it is recommended to connect WiPG-1500 to company network through Ethernet or bridge WiPG-1500 to a router due to wireless bandwidth concern.

  • Page 50: Select Projection Desktop

    9.10.6 Select Projection Desktop 2) Click on the “Select Projection Desktop”, you can select to project the main screen or the extended screen. Note: It can only support Mac 10.7 and above. To use the extended screen, you have to install the SVS extended screen driver which can be found from the USB Token. 9.10.7 Projection Quality 2) Click on the “Projection Quality”, choose “Normal”...

  • Page 51: Projection Aspect Ratio

    9.10.10 Projection Aspect Ratio 2) Click on the “Projection Aspect Ratio”, choose “Keep aspect ratio” to keep the original aspect ratio if the desktop resolution is different from WiPG-1500 output resolution, or choose “Fit full screen” to project the screen to full screen.

  • Page 52: About

    9.10.14 About 1) Click on “About” to show system information. It includes product model name, Application version, IP address and other information. 9.10.15 Exit 1) Click on “Exit” to exit this application. It will stop current playing status and shut down the application immediate.

  • Page 53: Web Management

    Web Management 10.1 Home Page 1) Make sure your PC connect to wePresent WiPG-1500 box successfully. 2) Enter the receiver IP address on your browser; you can find the IP address on the projector/display screen. (Default IP is 192.168.100.10). 3) Your browser will lead you to the below page.

  • Page 54: Conference Control

    2) Enter password and then press [Login]. (default password: moderator) 3) After login, you can see a User List on the screen which indicates all of the users connected to wePresent WiPG-1500 box. 4) The default setting is “allow control from this page only”. When this function is...
  • Page 55 Moderator can “stop” the projecting anytime. 6) Uncheck the “Allow Control from this page only”, it will disable the centralized control and user can project the screen to WiPG-1500 freely. 7) Moderator can log out from the conference control mode by clicking on the” log...

  • Page 56: Admin

    Wireless MAC address：wireless MAC address  Wire MAC address：wire MAC address Connection Status:  Projecting status: “Waiting for projecting” or “Projecting”  Total Users: It shows how many users login to wePresent WiPG-1500.  Code: It will show current Code...

  • Page 57: Device Setup

    10.4.2 Device Setup 1) Click on “Device Setup” option, it will show the device setting items,  Choose <VGA> or <HDMI> output option  <Resolution>: VGA: UXGA(1600*1500), WXGA+(1440*900), WXGA(1360*768, 1280x768, 1280x800) ,XGA(1024*768), and SVGA(800*600). The default value is XGA(1024*768). HDMI: 720p, 1080i, 1080p ...

  • Page 58: Network Setup

    The default setting of the wePresent WiPG-1500 box as DHCP server. When the wePresent WiPG-1500 box is connected to a LAN that already has a DHCP server, the wePresent WiPG-1500 box uses an IP address assigned by the server. When the wePresent WiPG-1500 box is connected to a LAN that does not have a DHCP server, the wePresent WiPG-1500 box becomes the DHCP server in the network.
  • Page 59 SSID Broadcast: The default value is “Enable”  Channel: You can set a fixed channel or allow auto selection. The “Auto” selection means after power on wePresent WiPG-1500, it will scan all of wireless channels and select one clear channel automatically. ...
  • Page 60 < SNMP V3>  Enable or disable SNMP V3 service  User Name: configure the user name to manage this device through SNMP  Auth Password: configure the Auth password  Priv Password: configure the Priv password  Trap IP: configure the trap receiver IP Note: For more information about SNMP V3, you can find it on USB token.

  • Page 62: Osd Setup

    10.4.4 OSD Setup 1) Click on “OSD Setup” option, you can: Change Standby Image  Type: Replace Logo Image: Replace logo image only. Replace entire standby image: Replace the whole standby image  <Reset to default>: Restore to default Logo image. ...

  • Page 63: Webslides Setup

    10.4.5 WebSlides Setup 1) Click on “WebSlides Setup” option, you can: Adjust Auto ReFresh Interval, or activate “Access Password Control” Please pay attention on the note for information. <Apply >: Press “Apply” button after configuration, and follow the reboot instruction when applicable.

  • Page 64: Reset To Default

    1) Click on “Reset to Default” option to restore factory default settings. <Apply>: Confirm and take action. *** You can also restore factory default setting from WiPG-1500 box reset button. You can find the reset button underneath the box. Please follow below procedures.

  • Page 65: Firmware Upgrade

    2) System Configuration Import and Export Export: Export the system configuration to a configuration file Import: Import the system configuration file to WiPG-1500 3) You can find the firmware version and release date here. 4) Firmware Upgrade A. Firstly, you have to get latest firmware image file from your vendor.

  • Page 66: Reboot System

    Warning: Don’t power off wePresent WiPG-1500 while firmware upgrade in progress, otherwise you will damage your box and have to return device to your vendor for fixing. 10.4.9 Reboot System 1) Click on “Reboot System” option, you can restart the system ...

  • Page 67: Webslides

    10.5 WebSlides 1) Press the “WebSlides” button to enter the WebSlides page. 2) Please refer to 8.10.5 Launch Webslides for more information.

  • Page 68: Safety

    Safety 11.1 Compliance IC Canada, Industry Canada (IC) Notices This Class B digital apparatus complies with Canadian ICES-003 and RSS-210. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
