- Page 1 WiPG 1600 User Guide For more information Sales: sales@wePresentWiFi.com © wePresent 2016 www.wePresentWiFi.com Support: help@wePresentWiFi.com WIPG-1600-USER-GUIDE-01...
-
Page 2: Table Of Contents
SNMP Setup OSD Setup Web Slides Setup 7.10 Certification Setup 7.11 Change Passwords 7.12 Reset to Default 7.13 Fireware Upgrade 7.14 Reboot System 7.15 Logout 7.16 Webslides Wall Mount For more information Sales: sales@wePresentWiFi.com © wePresent 2016 www.wePresentWiFi.com Support: help@wePresentWiFi.com WIPG-1600-USER-GUIDE-01... -
Page 3: Overview
Overview WiPG-1600 is a wireless presentation system which connects multiple devices on any platform (Windows/Mac/iOS/Android/Chromebook) for engaging interactive presentations. It supports touchscreens and USB HID compatible remote devices, such as a mouse or wireless keyboard. ICON FEATURE DESCRIPTION MirrorOp for Windows and Mac MirrorOp for Windows and Mac • Win: 7/8/10... - Page 4 Extended desktop support for both Windows and Mac • Security features such as a randomized 4-digit login code, HTTPS and AES 128-Bit data encryption. • Supports both HDMI and VGA for single or concurrent video output. © wePresent 2016 WIPG-1600-USER-GUIDE-01...
-
Page 5: Package Contents
Package Contents Package Contents • wePresent WiPG-1600 • Power Adapter (DC +5V, 2.6A) • Quick Installation Guide • Wall Mount Kit • Warranty Card • CE DoC Physical Details Front Panel Front Panel DESCRIPTION Power Button Power on/off bottom... -
Page 6: Rear Panel
The USB port can only supply up to 5V/0.5A to USB touch device and USB drive. Bottom Side Bottom Side DESCRIPTION Screw Hole Screw Hole for Wall Mount Kit Hold power and reset buttons simultaneously to Reset Button restore device to factory defaults. © wePresent 2016 WIPG-1600-USER-GUIDE-01... -
Page 7: What You Might Need
(Optional, for UMT feature) Quick Installation Connect the power adapter to WiPG-1600 and press the power button to turn the unit on. System will be ready when the LED light turns from red to blue. Default standby screen shown as below when system is ready. Insert the speaker cable to WiPG-1600 audio jack for audio output (optional for HDMI output, but required when using VGA output). -
Page 8: Quick Guide
WiPG-1600 Start/Standby Page 6.1 Quick Guide The device will show the startup screen as shown as well as the wePresent device information and function icons. Default Standby Screen 6.2 Conference Control Mode Click to enable conference control mode and users will be unable to present to the display without moderator approval . -
Page 9: Sender List
WiPG-1600 Start/Standby Page 6.3 Connected User List Click on the “User List” button to show all connected users. Moderator can select user to present from list. 6.4 Setup Click on Setup icon to view firmware version, resolution information, and calibrate the touchscreen display (if connected). © wePresent 2016... -
Page 10: Remote Touch Control (Umt)
Windows 7, 8, 10 and Mac are supported for touchscreen and mouse events. The USB port on WiPG-1600 can supply up to 5V/0.5A power. An additional power supply is required if the attached HID device requires more power. -
Page 11: Conference Control
Please select your operating system, Windows or Mac, and execute the installation program. Note: Please disable the “Smart Screen Filter” on IE browser; otherwise file may not be downloaded. Download the Device Profile on your Windows or Mac laptop, copy/paste the .wipg profile. The wePresent utility will launch automatically, and automatically connect to the wePresent device. 7.2 Conference Control Select the “Conference Control” function, the current connected user list can be found on this page. -
Page 12: Admin
Moderator can “stop” the projecting or remove theuser anytime. Uncheck “Allow control from this page only” and the centralized control will be disabled. User can project their screen to WiPG-1600 freely. Moderator can log out from the conference control mode by clicking on the “Logout” on the upper right corner. -
Page 13: System Status
Wire MAC address: wire MAC address Connection Status: • Projecting status: “Waiting for projecting” or “Projecting” • Total Users: It shows how many users login to wePresent WiPG-1600. • Code: shows current Code Date and Time: • Date: Current date. -
Page 14: Device Setup
Choose <SNTP/NTP Server Synchronization> or <Disable> to specify the time server or disable this feature. • <Time Zone>: Specify the time zone. “SharePod Pairing” option: • External Wi-Fi Access Point information can be input here, then will copy to SharePod device when pairing is executed. © wePresent 2016 WIPG-1600-USER-GUIDE-01... -
Page 15: Network Setup
<DHCP Server Setup> Auto-Configuration When the wePresent WiPG-1600 system is connected to a LAN that already has a DHCP server, the wePresent WiPG-1600 uses an IP address assigned by the server. When the wePresent WiPG-1600 system is connected to a LAN that does not have a DHCP server, the wePresent WiPG-1600 becomes the DHCP server in the network. -
Page 16: Snmp Setup
Web Management 7.7 SNMP Setup • Enable or disable SNMP V3 service • User Name: configure the user name to manage this device through SNMP • Auth Password: configure the Auth password • Priv Password: configure the Priv password • Trap Destination: configure the trap receiver IP <Apply >: Press “Apply” button after configuration, and follow the reboot instruction when applicable. <Cancel>: Press button to abort action. © wePresent 2016 WIPG-1600-USER-GUIDE-01... -
Page 17: Osd Setup
The image should be in PNG format, and no larger than 5MB. (Recommended resolution: 1920x1080) Change Screen Saver Logo • <Reset to default>: Restore to default image. • <Image File Upload>: Enter or browse to the file name and upload the customized image. The image should be in PNG format and no larger than 500kB. (Recommended resolution: 192x192) © wePresent 2016 WIPG-1600-USER-GUIDE-01... - Page 18 Connection Info: Show or hide the overlay connection info. • Font Color: Adjust the font color of system information. • Screen Saver Settings: Enable or disable the screen saver and configure the idle time (minutes). (default is 5 mins) <Apply >: Press “Apply” button after configuration, and follow the reboot instruction when applicable. <Cancel>: Press button to abort action. © wePresent 2016 WIPG-1600-USER-GUIDE-01...
-
Page 19: Webslides Setup
LAN, rather than accessed wirelessly, due to bandwidth concerns. <Apply >: Press “Apply” button after configuration, and follow the reboot instructions when applicable. <Cancel>: Press button to abort action. 7.10 Certification Setup “Certification Setup” option can generate the self-signed certification for the web server on this device. <Apply >: Press “Apply” button after configuration, and follow the reboot instructions when applicable. <Cancel>: Press button to abort action. © wePresent 2016 WIPG-1600-USER-GUIDE-01... -
Page 20: Change Passwords
NOTE: Factory settings can also be restored with the reset button, found on the bottom of the hardware, by using the following instructions. Press [Reset] button and hold. Turn on wePresent WiPG-1600. Press for 10 seconds and release[Reset] button. Unit will restore to factory default settings. -
Page 21: Firmware Upgrade
A warning message and countdown will appear on the screen. Upgrading firmware may take a few minutes. When it completes, a message will appear to inform you. If no such message appears, try refreshing the webpage. It is not unusual to lose connection to the wePresent during the upgrade. The unit will prompt you to restart the hardware. Please note that device configurations will be restored to factory settings. •... - Page 22 Web Management WARNING: Do not power off the wePresent WiPG-1600 while firmware upgrade is in progress, otherwise the unit will be damaged and must be returned to the vendor for repair. © wePresent 2016 WIPG-1600-USER-GUIDE-01...
-
Page 23: Reboot System
Web Management 7.14 Reboot System To reboot your wePresent from the Admin Web Panel, click the “Reboot” entry at the bottom of the options list on the left-hand side. 7.15 Logout Click on “Logout” on the upper right corner to logout of the administration webpage and return back to the web management front page. -
Page 24: Wall Mount
Wall Mount Remove rubber from the bottom side Insert the mounting screw on wePresent device Attach the mounting bracket on the wall with the screw © wePresent 2016 WIPG-1600-USER-GUIDE-01...
