1. Package Contents • wePresent WiPG-1000P Box • wePresent USB Token • Power Adapter (DC +5V, 2.6A) • 2 WiFi Antennas • Quick Installation Guide • Wall Mount Kit • Warranty Card • CE DoC 2. USB Token Contents • MirrorOp Installer for Windows •...
Page 3
WiPG-1000P • Rear Panel Antenna WiFi Antenna USB Port (Rear) USB Port for USB IWB Device (HID Type) RJ-45 10/100M RJ-45 Port VGA Connector HDMI HDMI Connector Audio Jack Audio Jack (3.5mm) Power Jack Power Jack (5V/2.6A) • Bottom Side...
WiPG-1000P 4. What You Might Need • Projector/Display with VGA/HDMI Interface • Windows or Mac PC/Laptop • Apple iPhone, iPad or iPod Touch • Android Phone or Tablet • Speaker (Optional, for Audio Projection Feature) • USB Mouse and Keyboard (Optional, for Remote Desktop Feature) •...
Page 5
• 6.1 Install the application 1) Make sure your PC is WiFi-enabled, and connect your PC to the wePresent WiPG-1000 box through WiFi. You can find the WiFi network name (SSID) of your WiPG-1000 box on the standby screen of the projector/display . [Default SSID is...
Page 6
WiPG-1000P 3) Download the wePresent software (i.e. “MirrorOp”) for “Windows 7/8/10”, and follow the Setup Wizard to install the software. (You can also install the “MirrorOp” software from the USB token directly.) Make sure the software is not blocked by your firewall.
Page 7
USB token directly. (You can find the MirrorOp application in the USB drive.) It will start to search for the wePresent WiPG-1000 receiver automatically. Click on the WiPG-1000 device and enter the login code...
Page 8
7.1 Install the application Make sure your Mac is WiFi-enabled, and connect your Mac to the wePresent WiPG-1000 box through WiFi. Open your browser, and enter the IP address of your WiPG- 1000 box in the address bar of the browser. You can find the IP address on the standby screen of the projector/display.
Page 9
DMG file with a MirrorOp icon Drag the MirrorOp icon into the Applications folder. • 7.2 Start the application 1) Click on the MirrorOp icon from the Applications folder to execute the application. 2) It will start to search for the wePresent WiPG-1000 receiver automatically.
Page 10
WiPG-1000P 3) Click on the WiPG-1000 device and enter the login code shown on the display. 4) Click the “PLAY” button to start the screen sharing.
WiPG-1000P 8. Safety Information < Federal Communications Commission (FCC) Statement > • This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 12
WiPG-1000P approved by the party responsible for compliance could void the user’s authority to operate the equipment. < FCC RF Radiation Exposure Statement > • This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Page 13
WiPG-1000P Canada This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device.
Page 14
WiPG-1000P fonctionnement tel que décrit dans ce manuel. La réduction aux expositions RF peut être augmentée si l’appareil peut être conservé aussi loin que possible du corps de l’utilisateur ou que le dispositif est réglé sur la puissance de sortie la plus faible si une telle fonction est disponible.
Page 15
WiPG-1000P . This radio transmitter (9393B-WP1KP16) has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.
