Installation Requirements; Cabling Requirements - ASL INTERCOM VAR8 Installation Manual

1.1

Installation Requirements

•
The VAR8 unit.
•
A 19-inch standard rack wired and configured with V400 amplifier mainframes, and wiring for
power supply, signal monitoring, CAN bus, and RS232 and RS485 cabling as appropriate.
•
A small flat-bladed screwdriver.
•
Large pozidrive screwdriver.
•
Cable termination tools - cutters/strippers etc. to suit cable type.
1.1.1

Cabling Requirements

The following cabling is recommended within the equipment rack. For pinout refer to
5), and for cabling connector refer to Section
1. DC power supply cabling:
Standard cable rated for 3A.
Recommended type: BELDEN 8205LSHF.
2. Audio input:
Twisted pairs, individually screened.
Recommended type: BELDEN 8451 LSHF.
The rack and field cabling should be as described in the diagram shown in
3. A/B audio outputs on Interface Expansion Board (EXP8):
Twisted pairs, individually screened.
Recommended type: BELDEN 8451 LSHF.
The rack and field cabling should be as described in the diagram shown in
4. Audio and data network cabling (on VAR8 with Network Interface Card):
Twisted pairs with overall foil screen.
Recommended type: FS cables 2407 POFYH.
The Upstream side of the network connection is isolated RS485. To maximise the benefits of this,
the rack and field cabling should be as described in the diagram shown in
5. Other cabling:
Overall screened.
Recommended type: BELDEN LS0H.
The rack and field cabling should be as described in the diagram shown in
6. Audio outputs on RJ45 (see signals and pinout in
Cabling: overall foil screened.
Recommended type: CAT5 STP or FTP LS0H
The rack and field cabling should be as described in the diagram shown in
The use of screened cables where specified is necessary for EMC compliance. Also for
!
!
EMC compliance, rack and field cabling should be according to the specified diagram.
VAR8 / Variants - Installation Guide
"2 Connections" (page 12).
Table
Issue: 01 complete, approved
Page 6 of 22
Figure
Figure
Figure
Figure
1, page 13):
Figure
Figure 1 (page
3.
3.
2.
3.
3.
