05 Installation
Clearance
First measure the wall depth.
If installing into a new build application, we recommend that
the unit should be installed in the position below (option 1). If
installing into an existing wall sleeve which is located near to the
ceiling, the heatSava can be installed horizontally or vertically
(options 2-4).
Ceiling
Cover release
clips
Ceiling
SHOULD YOU ENCOUNTER ANY PROBLEMS INSTALLING THIS UNIT CALL
20mm
min
Option 1
Option 3
30mm
min
20mm
min
Option 2
Option 4
30mm
min
