Eneo NXD-2012PTZ1080 B User Manual

1/2.8” network dome, ptz, 12x, day&night, 4.8~57.6mm, 1920x1080, 24vac, ip66
Hide thumbs Also See for NXD-2012PTZ1080 B:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Full Manual
EN

User Manual

1/2.8" Network Dome, PTZ,
12x, Day&Night, 4.8~57.6mm,
1920x1080, 24VAC, IP66
NXD-2012PTZ1080 B

Advertisement

Table of Contents
loading

Related Manuals for Eneo NXD-2012PTZ1080 B

Summary of Contents for Eneo NXD-2012PTZ1080 B

  • Page 1: User Manual

    User Manual 1/2.8” Network Dome, PTZ, 12x, Day&Night, 4.8~57.6mm, 1920x1080, 24VAC, IP66 NXD-2012PTZ1080 B...

  • Page 2: Explanation Of Graphical Symbols

    WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EX- POSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH THE VENTILATION GRILLS OR OTHER OPENNINGS ON THE EQUIPMENT. CAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).

  • Page 3: Fcc Compliance Statement

    FCC COMPLIANCE STATEMENT FCC INFORMATION: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commer- cial environment.

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings, Install in accordance with the manufacturers in- structions.

  • Page 5: Table Of Contents

    Contents 1 Introduction 1.1 Components ........1.2 Key Features .

  • Page 6: Introduction

    1 Introduction The network camera supports the network service for a sensor image with progressive scan, which can be monitored on a real-time screen regardless of distances and locations. By us- ing its dedicated program, many users are able to have an access to the network camera at once or a single user can monitor various network cameras at the same time.

  • Page 7: Key Features

    1.2 Key Features Brilliant video quality The network camera offers the highly efficient H.264 video compression, which drasti- cally reduces bandwidth and storage requirements without compromising image qual- ity. Motion JPEG is also supported for increased flexibility. Dual or Triple Streams The network camera can deliver dual or triple video streams simultaneously at full frame rate in all resolutions up to Full-HD (1920 x 1080p) using Motion H.264 and JPEG.

  • Page 8: Installation

    2 Installation 2.1 Installation The dome camera is for use in surface or pendent mounting applications, and the mounting member must be capable of supporting loads of up to 10 lb (4.5 kg). (Pendent mounting must use pendent mount accessory.) The dome cameras mounting bracket should be attached to a structural object, such as hard wood, wall stud or ceiling rafter that supports the weight of the dome camera.
  • Page 9 CAUTION: Before installing mounting bracket to surface pre-adjust the four mounting screws ”A” on the base of the dome camera to best match the mounting bracket locked position. Unscrew the locking screw on the side of the dome’s base and fit the tab of the mounting bracket into the locking slot.

  • Page 10: Heater Kit Installation

    2.1.2 Heater Kit Installation 1. Assemble the Heater board to two bossed with screws. Take a reference ”B” in the bottom case as below. 2. Place the Heater in the slot ”A”. Heater cable should be placed away from the Main board.

  • Page 11: Basic Configuration Of Camera System

    2.2 Basic Configuration of Camera System Connector Wire Color Description 24VAC or 12VDC+ 3-pin terminal block WHITE 24VAC or 12VDC- PINK ALARM INPUT 1 GRAY ALARM INPUT 2 GREEN ALARM INPUT 3 6-pin terminal block BLUE ALARM INPUT 4 BROWN YELLOW ALARM OUTPUT Ethernet, RJ-45 port compatible with...

  • Page 12: Micro-Sd Card Insertion

    2.3 Micro-SD Card Insertion User can install and change Micro-SD card as shown in the following picture. 1. Open the Micro-SD card cover. 2. Install or change Micro-SD card. 3. Tightly close the Micro-SD card cover to ensure waterproofness.

  • Page 13: Connections

    2.4 Connections Connecting the Network Connect a standard RJ-45 cable to the network port of the camera. Generally a cross- over cable is used for directly connection to PC, while a direct cable is used for con- nection to a hub. Connecting Alarms –...

  • Page 14: Network Connection & Ip Assignment

    2.4.1 Network Connection & IP assignment The eneo scanning device tool is used to locate all eneo network cameras in a local network. The tool does not need to be installed with a setup program. The program exe-file can be started directly from the CD with a simple double click to use the program.

  • Page 15: Operation

    3 Operation The network camera can be used with Windows operating system and browsers. The rec- ommended browsers are Internet Explorer, Safari, Firefox, Opera and Google Chrome with Windows. NOTE: To view streaming video in Microsoft Internet Explorer, set your browser to allow ActiveX controls.

  • Page 16: Access From The Internet

    3.2 Access from the internet Once connected, the network camera is accessible on your local network (LAN). To access the network camera from the Internet you must configure your broadband router to allow incoming data traffic to the network camera. To do this, enable the NAT traversal feature, which will attempt to automatically configure the router to allow access to the network cam- era.

  • Page 17: Live View Page

    3.4 Live View Page The Live View page comes in several screen modes: 1920x1080, 1280x1024, 1280x720(960), 1024x768, 704x480(576), 640x480(360) and 320x240. Users are allowed to select the most suitable one out of those modes. Adjust the mode in accordance with your PC specifications and monitoring purposes.
  • Page 18 The Full Screen button causes the video image to fill the entire screen area. No other windows will be visible. Press the ’Esc’ button on the computer keyboard to cancel full screen view. The Manual Trigger button activates a pop-up window to manually start or stop the event.

  • Page 19: Playback

    3.5 Playback The Playback window contains a list of recordings made to the memory card. It shows each recording’s start time, length, the event type used to start the recording, calendar and time slice bar indicates if the recording is existed or not. The description of playback window follows.
  • Page 20 (3) Time Chart Display an hour-based search screen for the chosen date. If there is recording data, a blue section will be displayed on a 24-hour basis. If you select a particular hour in the chart, a yellow square on the hour will be displayed. (4) Speaker Control Bar Use this scale to control the volume of the speakers.

  • Page 21: Network Camera Setup

    3.6 Network Camera Setup This section describes how to configure the network camera. Administrator has unrestricted access to all the Setup tools, whereas Operators have access to the settings of Basic Configuration, which are Live View, Video & Image, Audio, Event, Dome Configuration, and System.
  • Page 22 1) Users User access control is enabled by default. The administrator can set up other users, by giving user names and passwords. It is also possible to allow anonymous viewer login, which means that anybody may access the Live View page, as described below: The user list displays the authorized users and user groups (levels): User Group Authority...
  • Page 23 2) Network The network camera supports both IP version 4 and IP version 6. Both versions may be enabled simultaneously, and at least one version must always be enabled. When using IPv4, the IP address for the network camera can be set automatically via DHCP, or a static IP address can be set manually.
  • Page 24 3) Video & Image User can setup and change setting of individual video stream in this page. Please refer to ”Video & Image Basic” for more details about Video & Image setup. 4) Audio The network camera can transmit audio to other clients using an external microphone and can play audio received from other clients by attaching a speaker.

  • Page 25: Live View

    5) Date & Time User can set time directly or assign time server to get the current time, as well as determine Date & Time format in this page. Please refer to ”System Date & Time” for more details about Date & Time setup. 3.6.2 Live View Video Input Mode: –...

  • Page 26: Video & Image

    3.6.3 Video & Image 1) Basic Sensor Setting: – Capture mode: User can select sensor capture mode between 30 fps and 60 fps in full-HD reso- lution. If 60fps is selected, Stream 3 is disabled and hidden from the window. In other words, the camera provides triple stream at 30 fps and dual stream at 60 fps.
  • Page 27 – Resolution: This enables users to determine a basic screen size when having an access through the Web Browser or PC program. The screen size control comes in seven modes like 1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 704x576, 704x480, 640x480, 640x360 and 320x240. Users can change the selected screen size anytime while monitoring the screen on a real-time basis.
  • Page 28 2) Auto Focus Mode: Determines focus operation method. – Auto: Auto Focus is always active. – Manual: User can manually focus the camera when camera is not moving. Auto Focus becomes active when camera moves and about 5 seconds after movement stops.
  • Page 29 3) Webcasting The live video of the camera can be streamed to a website. User can copy and paste the HTML code generated on the screen to the website page code, where user wants to display live video. NOTE: To use webcasting service, the Enable Anonymous viewer login option must be checked.
  • Page 30 4) Camera Setup In this page, user can setup Exposure Control, White Balance Control, Image Appearance, and Day & Night control. Video Preview: User can check the setting via video preview pop-up window...
  • Page 31 Exposure Control 1. Mode: Determines exposure mode between automatic and manual. For auto- matic mode, at least one of Shutter and Iris should be set to automatic. For manual mode, both Shutter and Iris become fixed. 2. Max. gain: Sets maximum gain if Mode is automatic. 3.
  • Page 32 Image Appearance User can setup image related controls. 1. User can either use slide bar or type in number for items in 1. 2. User can select individual function and level. NOTE: Defog function cannot be used in conjunction with WDR. Day &...
  • Page 33 5) OSD This camera provides two OSD’s (on screen display) on each stream, title and date & time. User can drag green ”OSD Title” and ”Date & Time” to the desired position and check at preview window. Video Preview: User can check the position of OSD on actual video via preview pop- up window.

  • Page 34: Audio

    3.6.4 Audio The network camera can transmit audio to other clients using an external microphone and can play audio received from other clients by attaching a speaker. The Setup page has an additional menu item called Audio, which allows different audio configurations, such as full duplex and simplex.
  • Page 35 – Output volume: If the sound from the speaker is too low or high it is possible to adjust the output gain for the active speaker attached to the network camera. When the settings are complete, click Save button to save the settings, or click Reset button to clear all of the information you entered without saving it.

  • Page 36: Event

    3.6.5 Event 1) Event In On Boot This is used to trigger an event every time the network camera is started. Select ”Enable on boot” to activate the On Boot event. Enter the Dwell time the event lasts from the point of detection, 1-180 seconds. When the settings are complete, click Save button to save the settings, or click Reset button to clear all of the information you entered without saving it.
  • Page 37 Alarm In This camera provides 4 Alarm In ports and user can set each ports individually. Each Port can be given as Normally Open or Normally Close state, and their Normal state can be configured. In order to use an alarm port, check the desired ”Enable alarm port #” first. Type: Choose the type of alarm to use from the drop-down list, NO (Normally Open) or NC (Normally Closed).
  • Page 38 Manual Trigger This option makes use of the manual trigger button provided on the Live View page, which is used to start or stop the event type manually. Alternatively, the event can be triggered via the product’s API (Application Programming Interface). Select ”Enable manual trigger”...
  • Page 39 Network Loss This is used to trigger an event every time the network connection is failed. Select ”Enable network loss” to activate the Network Loss event. Select a dwell time for how long the event will last from the point of detection. When the settings are complete, click Save button to save the settings, or click Reset button to clear all of the information you entered without saving it.
  • Page 40 Tampering This is used to trigger an event when camera tampering occurs, for example, obstruct the camera with foreign material or move camera direction using external force. Select ”Enable tampering” to activate the Tampering event. Dwell time: Determine how long the event will last from the point of detection. Event time: Time duration from tampering detection to tampering event trigger.
  • Page 41 The network cameras provide basic and advanced VCA(Video Content Analysis) functions depend on models. The basic VCA has ”Line Detector” and ”Field Detector,” and the ad- vances VCA has additional ’Absent” detection and Tracking functions. Video Content Analysis Setting Check Enable video content analysis box to use a VCA function. –...
  • Page 42 – Detection Rule: User can assign up to 3 different rules for each preset position. Line Detector Once selected, a red line appears on the video preview window. Drag and drop the line at the desired position. User can change the length and the slope by dragging each end of the line.
  • Page 43 Face Detector This is used to detect a human face in the scene and makes a bounding box for the detected face. Select ”Enable face detector” to activate the Face Detector. Set threshold for detectio sensitivity. When the settings are complete, click Save button to save the settings, or click Reset button to clear all of the information you entered without saving it.
  • Page 44 2) Event Out SMTP(E-Mail) The network camera can be configured to send event and error email messages via SMTP (Simple Mail Transfer Protocol). SMTP (E-Mail) Setting: Select ”Enable” to activate the SMTP operation. – Sender: Enter an email address to be used as the sender for all messages sent by the network camera.
  • Page 45 SMTP (E-Mail) Test: User can check the SMTP setting via a sample email. – Receiver: Enter an email address and click the Test button to test that the mail servers are functioning and that the email address is valid. When the settings are complete, click Save button to save the settings, or click Reset button to clear all of the information you entered without saving it.
  • Page 46 FTP & JPEG When the network camera detects an event, it can record and save images to an FTP server. Images can be sent as e-mail attachments. Check the ”Enable FTP” box to enable the service. FTP Setting – Server: Enter the server’s IP address or host name. Note that a DNS server must be specified in the TCP/IP network settings if using a host name.
  • Page 47 – Additional suffix: Add either a date/time suffix or a sequence number, with or without a maximum value. When the settings are complete, click Save button to save the settings, or click Reset button to clear all of the information you entered without saving it.
  • Page 48 Alarm Out When the network camera detects an event, it can control external equipment connected to its alarm output port. Enable alarm out: If selected, the output becomes activated for as long as the event is active. Type: Select a type of NO (Normally Open) or NC (Normally Closed). When the settings are complete, click Save button to save the settings, or click Reset button to clear all of the information you entered without saving it.
  • Page 49 Audio Alert When the network camera detects an event, it can output a predefined audio data to external speaker. Check the ”Enable audio alert” box to enable the service. Audio Alert Setting To use the audio alert with the network camera, an audio data file made by user must be uploaded from your PC.
  • Page 50 PTZ Preset When the camera detects an event, you can move the camera to a predefined preset posi- tion. Check the box to enable the service and return to the Home position once the event has ended. When the settings are complete, click Save button to save the settings, or click Reset button to clear all of the information you entered without saving it.
  • Page 51 Record When the network camera detects an event, it can record the video stream onto the Micro SD Memory (not supplied) or NAS (Network Attached Device) as a storage device. Check the ”Enable Record” box to enable the service. Record Setting –...
  • Page 52 – SD: Built-in SD card. – CIFS: A file format for a NAS device. – NFS: A file format for a NAS device. NOTE 1: Common Internet File System (CIFS) is a remote file access protocol that forms the basis for Windows file sharing, network printing, and various other network services.
  • Page 53 XML Notification When the network camera detects an event, Notification server is used to receive notification messages as a type of XML data format. Check the box to enable the service. XML Notification Setting: – Notification server URL: The network address to the server and the script that will handle the request.
  • Page 54 Boost The Boost feature is used in conjunction with event detection. When this feature is turned ON, the Frame rate and Bit rate in the boost condition can be set to a different value than the ones in the normal condition field. When an event is detected, the camera will boost the Frame rate and Bit rate from the normal condition to this boosted level for the duration of the event.
  • Page 55 Notification Server When the network camera detects an event, the Notification Server is used to receive up- loaded image files and/or notification messages. Check the box to enable the service. Notification Server Setting: – Type: User can select message transmission type among HTTP, HTTPS, TCP, and UTP.
  • Page 56 3) Event Map The event map allows you to change the settings and establish a schedule for each event trigger from the network camera; up to a max. 15 events can be registered. Click the Add button to make a new event map; a popup window displays as below. To change an existing event, select that event and click the Modify button;...
  • Page 57 General: Enter the name for a new event map. Event In: Select an event type in the drop-down list. Event Out: – E-mail: Select the email addresses you want to notify via email that an event has occurred. – FTP: Select checkbox beside FTP to record and save images to an FTP server when an event has occurred.

  • Page 58: Dome Configuration

    3.6.6 Dome Configuration 1) Preset If you need to view specific places routinely, you should program Presets. A Preset is a pro- grammed video scene with automatic pan, tilt, zoom and focus settings. Once programmed, clicking the Preset number or clicking the Go button in the PTZ Control Panel calls up that Preset automatically.
  • Page 59 2) Tour There are 8 programmable Tours. Each Tour consists of up to 100 Presets. Tour Setting: – Tour Number: The Tour number can be selected in the range 1 - 8. – Title: Up to 12 characters (Alphanumeric characters and space) –...
  • Page 60 Tour Position Setup: – Tour position: The Tour position can be selected in the range 1 - 100. – Preset number: Show the selected Preset number. – Dwell Time: Select the Dwell Time from 0 to 99 seconds. The default is 10 seconds.
  • Page 61 3) Pattern Pattern is a series of pan, tilt, and zoom movements programmed by administrator or op- erator. Up to 8 patterns may be programmed for the dome camera. Follow steps below to program the Patterns: 1. Click the Set button of desired Pattern number of Pattern Setting list, and move pan, tilt, and zoom using Control box.
  • Page 62 4) Home Function Camera goes to assigned function if there is no PTZ action during ”Waiting Time”. User can assign pre-programed Preset or Tour for function. Function: None / Preset / Tour Function No.: Select Preset or Tour number for Home Function. Waiting Time: 10 600 Seconds Function Use: Off / On...
  • Page 63 5) Motor Setup Motor Setup menu provides the pan and tilt speed of a camera. Motor Setting: – Proportional P/T: Select On or Off. – Max. Pan Speed: The maximum pan speed can be adjusted in the range 1 - 38. –...
  • Page 64 6) View Angle View Angle Setting: – Tilt angle limit: This option is designed to limit the view angle as there is some obstruction in zooming out on specific areas of the tilt angle. – Flip: Off: The dome camera moves until 90 vertically. Auto: When the camera reaches the floor directly above the moving object, it will stop.
  • Page 65 7) System Menu Dome Information: The system information provides essential information about the dome if service is required. The information cannot be modified. System Menu setting: User can set the camera in auto-calibration mode Origin Check: If you find the dome in the wrong position during operation, execute this origin check by clicking Origin Check button and the dome camera will return to the right position after the origin check operation.
  • Page 66 8) Privacy Zone Using privacy zones (masks), you can hide up to 12 unwanted scenes in a camera. The color of privacy zones is gray. Privacy Zone Setting: Following steps below to configure the privacy zones; 1. After aiming the camera (view direction and lens control) by using the Arrow and Zoom button in PTZ Control Panel, click Set cell of Set column at any inactive row to create privacy zone.

  • Page 67: System

    3.6.7 System 1) Information You can enter the system information. This page is very useful when you require device information after installation. Device Name Configuration: Enter the device name. Location Configuration: Enter the location information. You can enter up to four locations.
  • Page 68 2) Security Users User access control is enabled by default when the administrator sets the root password on first access. New users are authorized with user names and passwords, or the administrator can choose to allow anonymous viewer login to the Live View page, as described below: User Setting: Check the box to enable anonymous viewer login to the network camera without a user account.
  • Page 69 HTTPS For greater security, the network camera can be configured to use HTTPS (Hypertext Trans- fer Protocol over SSL (Secure Socket Layer)). Then all communication that would otherwise go via HTTP will instead go via an encrypted HTTPS connection. HTTPS Connection Policy: Choose the form of connection you wish to use from the drop-down list for the administrator, Operator and Viewer to enable HTTPS connection (set to HTTP by default).
  • Page 70 IP Filtering Checking the Enable IP address filtering box enables the IP address filtering function. Up to 256 IP address entries may be specified (a single entry can contain multiple IP ad- dresses). Click the Add button to add new filtered addresses. When the IP address filter is enabled, addresses added to the list are set as allowed or de- nied addresses.
  • Page 71 OpenVPN OpenVPN is a Virtual Private Network using OpenSSL authentication. User can set the camera in either Server mode or Client mode. OpenVPN Server Mode 1. Select Enable openVPN activates mode selection buttons. Choose Server mode, then Server Mode Configuration appears where you can configure Server Mode Settings.
  • Page 72 OpenVPN Client Mode 1. Select Enable openVPN activates mode selection buttons. Choose Client mode, then Client Mode Configuration appears where you can configure Client Mode Settings. 2. In Client Mode Configuration, you can setup Server URL, Protocol type, Port num- ber, LZO usage, and Renegotiation time.
  • Page 73 3) Date & Time Current Server Time This displays the current date and time (24h clock). The time can be displayed in 12h clock format (see below). New Server Time – Time zone Select your time zone from the drop-down list. If you want the server clock to automatically adjust for daylight savings time, check the box ”Automatically adjust for daylight saving time changes”.
  • Page 74 4) Network Basic IP Address Configuration: – Obtain IP address via DHCP: Dynamic Host Configuration Protocol (DHCP) is a protocol that lets network administrators centrally manage and automate the assignment of IP addresses on a network. DHCP is enabled by default. Although a DHCP server is mostly used to set an IP address dynamically, it is also possible to use it to set a static, known IP address for a particular MAC address.
  • Page 75 – Obtain DNS Server via DHCP: Automatically use the DNS server settings pro- vided by the DHCP server. – Use the following DNS server address to enter the desired DNS server by spec- ifying the following: Domain name: Enter the domain(s) to search for the host name used by the network camera.
  • Page 76 DDNS Internet DDNS (Dynamic Domain Name Service) When using the high-speed Internet with the telephone or cable network, users can operate the network camera on the floating IP environment in which IPs are changed at every access. Users should receive an account and password by visiting a DDNS service like http://www.dyndns.com/.
  • Page 77 Create a setting for sending and receiving an audio or video on a real-time basis. These settings are the IP address, port number, and Time-To-Live value (TTL) to use for the media stream(s) in multicast H.264 format. Only certain IP addresses and port numbers should be used for multicast streams.
  • Page 78 UPnP The network camera includes support for UPnP. UPnP is enabled by default, so the network camera is automatically detected by operating systems and clients that support this protocol. Enter a name in the Friendly name field. NOTE: UPnP must be installed on your workstation if running Windows XP. To do this, open the Control Panel from the Start Menu and select Add/Remove Programs.
  • Page 79 Quality of Service (QoS) provides the means to guarantee a certain level of a specified re- source to selected traffic on a network. Quality can be defined as a maintained level of bandwidth, low latency, and no packet losses. The main benefits of a QoS-aware network are: 1.
  • Page 80 – Automatic frame rate: Selected if not influenced by a network-related program or equipment without a limitation on the network bandwidth. When the settings are complete, click Save button to save the settings, or click Reset button to clear all of the information you entered without saving it.
  • Page 81 NAT (Port Mapping) A broadband router allows devices on a private network (LAN) to share a single connection to the Internet. This is done by forwarding network traffic from the private network to the outside, that is, the Internet. Security on the private network (LAN) is increased since most broadband routers are pre-configured to stop attempts to access the private network (LAN) from the public network/Internet.
  • Page 82 Zeroconf Zero configuration networking (zeroconf) is a set of techniques that automatically creates a usable Internet Protocol (IP) network without manual operator intervention or special config- uration servers. Zero configuration networking allows devices such as computers and printers to connect to a network automatically.
  • Page 83 Bonjour The network camera includes support for Bonjour. When enabled, the network camera is automatically detected by operating systems and clients that support this protocol. Click the check box to enable Bonjour. Enter a name in the Friendly name field. NOTE: Also known as zero-configuration networking, Bonjour enables devices to automat- ically discover each other on a network, without having to enter IP addresses or configure DNS servers.
  • Page 84 5) Language Select a user language. The language choices are English, Korean, French, Russian and Chinese. When the settings are complete, click Save button to save the settings, or click Reset button to clear all of the information you entered without saving it.
  • Page 85 6) Maintenance Maintenance: – Restart: The unit is restarted without changing any of the settings. Use this method if the unit is not behaving as expected. – Reset: The unit is restarted and most current settings are reset to factory default values.
  • Page 86 7) Support The support page provides valuable information on troubleshooting and contact information, should you require technical assistance. Logs: The network camera supports system and event log information. Click the Sys- tem Log button to get the system log data or the Event Log button to get information on events.
  • Page 87 – Networks Check: Click the Network Check button to get the information about the cameras network setting and traffic. You can see the pop-up window below. – Hardware Check: Click the Hardware Check button to diagnose the cameras hardware like video.

  • Page 88: Help

    3.7 Help The Help information window will be provided as a popup window so that users can open and read it without needing to log-in. It will offer a description of the setting and Help page so that users can manipulate the network camera without a reference to the manual.

  • Page 89: Resetting To The Factory Default Settings

    3.8 Resetting to the factory default settings To reset the network camera to the original factory settings, go to the Setup System Maintenance web page (described in ”System Maintenance” of Users Manual) or use the Reset button on the network camera, as described below: Using the Reset button: Follow the instructions below to reset the network camera to the factory default settings using the Reset button.

  • Page 90: Appendix

    4 Appendix 4.1 Troubleshooting Troubleshooting if problems occur, verify the installation of the network camera with the instructions in this manual and with other operating equipment. Isolate the problem to the specific piece of equipment in the system and refer to the equipment manual for further information.

  • Page 91: Alarm Connection

    4.2 Alarm Connection The following connection diagram gives an example of how to connect a network camera. 4.3 Preventive Maintenance Preventive maintenance allows detection and correction of minor that faults before they be- come serious and cause equipment failure. Every three-month, perform the following maintenance. 1.

  • Page 92: Product Specification

    4.4 Product Specification 12x Full-HD Mini-PTZ NETWORK CAMERA NXD-2012PTZ1080 B Model 4.8mm 57.6mm Lens 12x A/F Optical Zoom Angle of View 4.8mm - 64 2 (H) / 57.6mm - 5 9 (H) Image Sensor 1/2.8” SONY Exmor CMOS Min. Illumination Color: 0.5Lux, B/W: 0.1Lux...
  • Page 93 250mA(12W) @ PoE, Power Consumption 1.0A(12W) @ 12VDC or 24VAC Power Consumption (with Heater) 1.5A(22W) @ 24VAC Dimensions(D x H) 154mm x150mm (Bubble Diameter: 110mm) Weight w/o Package Approx. 1.6 kg for dome Weatherproof IP66 Pan Range 360 Endless Pan Speed Preset: Max.

  • Page 94: System Requirement For Web Browser

    4.5 System Requirement for Web Browser Operating System: Microsoft Windows OS Series CPU: Intel Core 2 Duo 2Ghz or higher, 1GB RAM or more, 10GB free disk or higher VGA: AGP, Video RAM 32MB or higher (1024x768, 24bpp or higher) 4.6 General Performance Considerations When setting up your system, it is important to consider how various settings and situations will affect performance.
