ARTF MODEL COMES PRE BINDED!
The process of frequency bind for DSSS series 2. 4 GHz R/ C system
Place the transmitter and the receiver close to each other within one ( 1) meter.
Please do not press the frequency bind switch when the Transmitter at work mode,
or else your device will not work!
1. plug the short- circuit plug into the Receiver
in the position of BATT. Connect the ESC to
receiver for electricity supply, which results to
the indicator light glitters.
3. the indicator light of the receiver will light,
which indicates that the frequency bind is
successful.
5. Press frequency bind button again to get it
rebound. After the indicator light flashes for a
few seconds, it turns green, the transmitter
get into working mode.
2. Press the frequency bind button, then turn on
the transmitter's power.
4. Unplug the short-circuit, the indicator light glitters.
6. The indicator light turns bright again,
which means that the radio system can
work normally now.
