Summary of Contents for Art-Tech F-14 "TOMCAT" JET

  • Page 1 F -14 Instruction manual...

  • Page 2: Table Of Contents

    Spare parts list..................14 中 文 说 明................... 15-26 ★.说 明书内容如 有需要任何修改,不需另 行 通知,艾 特有 最 终 修改 权 ★. Other notice is not required if there is any changes on the manual ART-TECH keeps the final right of modification 2010.3...

  • Page 3: Brief Introduction

    WWW.ART-TECH.COM Brief introduction Thank you for purchasing F-14 "TOMCAT" JET Radio Controlled Model Aeroplane. This model use EPO style foam, which makes the model incredibly strong and durable even in a crash, the optimized structure which is simple but also has the advanced function of sweeping the wings which is easy to set up and maintain.

  • Page 4: Statement

    3. The user bears full responsibility for proper operation and use of this model. Art-Tech and any of its distributors can not...

  • Page 5: Charging Method And Cautions

    WWW.ART-TECH.COM Charging method and cautions Li-Po battery(balance changer) ATI-0910 Li-Po battery(balance changer) specifications 12V D Power supplier Specifications: Input voltage: DC 10V~15V Output voltage: DC 7.4V & 11.1V (to 2 or 3 cell Li-Po battery) Charging current: 0.3A~1.0A (can be continuously adjusted) Indicator state: Green: Charge complete &...

  • Page 6: Safety Instruction Of Li-Po/Ni-Mh Battery

    WWW.ART-TECH.COM Safety Instruction of Li-Po/Ni-MH battery 1. Do not disassemble or reconstruct the battery. 2. Do not short-circuit the battery. 3. Do not use or leave the battery nearby the fire, stove or heated place (more than 80℃). 4. Do not immerse the battery in water or sea water, do not get it wet.

  • Page 7: Functions For Control Set

    WWW.ART-TECH.COM Functions for control set ModeⅠ Antenna Handle sweepback Dual Rate(D/R) adjustment trim switch Trim Switch Dual Rate main wing(D/R) Trainer switch sweepback adjustment switch (D/R) Switch Elevator down Throttle Max Left Right Rudder Rudder Aileron Aileron left right Elevator up...

  • Page 8: Receiver

    WWW.ART-TECH.COM Receiver SPECIFICATIONS AND PARAMETERS Operating voltage: 4.8V~5.2V Current drain: ≤40mA Antenna Weight: 12g Dimension: 44mm*23mm*15mm Channel: 6CH Adjacent channel rejection: ≥-85dBm Output channels Operating Manual for the radio control system Components to the R/C system: transmitter, receiver, servo, speed controller...

  • Page 9: The Process Of Frequency Bind For 2.4Ghz R/C System

    WWW.ART-TECH.COM ARTF MODEL COMES PRE BINDED! The process of frequency bind for DSSS series 2. 4 GHz R/ C system Place the transmitter and the receiver close to each other within one ( 1) meter. Please do not press the frequency bind switch when the Transmitter at work mode, or else your device will not work! 1.

  • Page 10: Assembly Of F-14 "Tom Cat

    WWW.ART-TECH.COM Assembly of F-14 "Tom Cat” 2．Strip of the double-sided tape from the wire channel 1．Take out the fuselage and main wing, then remove the cover on the back of the fuselage. were the aileron servo wire goes, connect the aileron servos then press down the cables into the wire channels.
  • Page 11 WWW.ART-TECH.COM 9．Take out two stabilizer control steel wires.。 1 0．Insert one end of the stabilizer control steel wire to the middle hole of the servo arm, but the experienced pilot can choose the hole according to their own experience. 1 1．Instal the ball buckle of the stabilizer control 12．stabilizer assembled...

  • Page 12: Adjustment Step Of F-14 "Tom Cat

    WWW.ART-TECH.COM 18．completed F-14 TOM CAT after assembly. Adjustment step of F-14 "TOM CAT" 1 .Turn on the transmitter, make sure the throttle is on the 2.Make sure the main wing control servo works normally, lowest position, connect the flight battery to the ESC then move the switch on the right of the transmitter upward, put it into the battery box.

  • Page 13: Tips For Flying

    WWW.ART-TECH.COM The reticle on the side of the fuselage. 7 .Put the elevator trim switch in the middle position, then 8. Hold the fuselage tightly, move the throttle joystick slowly, make sure the middle line of the elevator corresponds to make sure the duct fan work properly.

  • Page 14: Center Of Gravity Check

    WWW.ART-TECH.COM Center of Gravity Check Check the CG of the model before flying. The proper CG position should be between 577~580mm like below picture. The possible problems and solutions Phenomenons Problems Solutions 1. Battery is not fully charged. 1. Charge the battery.

  • Page 15: Spare Parts List

    WWW.ART-TECH.COM 附 件 部 分 No: 51017 No:51027 No.:51037 Fuselage set Main wing set Tail wing set No: 3F024 No:33012 No:51047 Li-poly battery( 11 . 1 V, 2 2 0 0 mAh) Brushless ESC(20A) Ducted fan No:51067 No: 3I011 No:51057...

  • Page 16: 中 文 说 明

    WWW.ART-TECH.COM...
