2.2.2 Interface

WIFI antenna
RJ-45 Ethernet
Port
Audio output
RJ-45 以太网口
出口
LAN : RJ-45/10-100 Base T
DC5V : 5V/2A Power supply
I/O PINS: 1)Output(GND) 2)Output (+5V) 3)Alarm input 4)Input (GND) (you can see
For more information)
RESET BUTTON: Press and hold down the RESET BUTTON for 5 seconds.Release the
power button
and IP camera will be reset back to the factory default parameter

2.3 PC System Requirements

System configuration requirements: ( Example for view four IP Camera )
CPU: 2.06GHZ or above Memory: 256M or above
Network Card: 10M or above Display Card: 64M or above memory
Recommendable Operating System: Windows2000 ，Windows XP，VISTA,WIN7
Support web browser: IE. FireFox. Google etc .
Figure 1.2
Figure 1.3
IPCAM User Manual
I/O Alarm input/output
DC5V Power adapter
port
3.5.6
