Ipcam IP Camera User Manual page 49

IPCAM User Manual
2) login the Camera homepage as Administration and enter "DDNS Service Settings"
page input the name, password and Host(details: 3.5.4) .Then click <SUBMIT> and
reboot Device.
3) Re-login the Camera homepage and enter"DDNS Service Settings"page to check the
DDNS Status is DynDns Succeed or not.
4) Enter"UPnP Settings"page,the UPnP Status should be UPnP Succeed.If the status
is not Succeed, you may enter "Basic Network Settings" page to change Http Port
(details: 3.5.2). Then click <SUBMIT> and reboot Device.
5) Re-login the Camera homepage to check and make sure the DDNS Status and UPnP
Status is Succeed.
Figure8.0
6) You only need to enter the domain name(domain name+Port number
http://reotest1.dyndns.org:8999) in the IE address bar ,the browser will visit the IP
Camera.Wait for several minutes and the IP Camera will dial up to access the Internet
automatically, and the communication with the DDNS server is established successfully.
In the way, the user can access the IP Camera from a WAN by using the DDNS domain
name.
If the gateway settings and DDNS settings have been completed,ener the DDNS
dynamic domain name(for example, (http://reotest1.dyndns.org:8999) ,do not add www.)
in the address bar of the IE to access the IP Camera.If multiple IP Cameras are
connected to the same router,enter DDNS dynamic domain + port number(for example,
http://reotest1.dyndns.org:90) ) in the address bar of the IE to access different IP
Cameras.
You will view the pictures as below:
49 / 67
