- Page 1 Original Instructions Read instructions fully before operating this tool ERF298MSW ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW...
- Page 2 General Safety Rules Additional Specific Safety Rules Safety Rules For Charger Battery Pack Care Labels and Symbols Mitre Saw Overview Specification Functional Description Operation Maintenance Environmental Protection ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW ERBAUER 24V 165MM SINGLE BEVEL SLIDING MITRE SAW...
- Page 3 Congratulations on your purchase of a quality power tool from Erbauer Ltd. This product should give you reliable service for your peace of mind this power tool does carry a 24-month guarantee, the terms of which are detailed below. If this product develops a fault within the guarantee period contact your retailer.
-
Page 4: Safety Instructions
11 Do not abuse the cord - Never yank the cord to disconnect it from the socket. Keep the cord away from heat, oil and sharp edges. ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW... - Page 5 - This electric tool complies with the relevant safety rules. Repairs should only be carried out by qualified persons using original spare parts, otherwise this may result in considerable danger to the user. ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW...
-
Page 6: Health Advice
Kickback is the result of saw misuse and/or incorrect operating procedures or conditions and can be avoided by taking proper precautions as given below. ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW... - Page 7 An unprotected, coasting blade will cause the saw to walk backwards, cutting whatever is in its path. Be aware of the time it takes for the blade to stop after switch is released. ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW...
- Page 8 17. Select saw blades in relation to the material to be cut. 18. Check the maximum depth of cut. 19. When sawing long work pieces, always use extra support to provide better support, and use clamps or other clamping device ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW...
-
Page 9: Carrying Your Mitre Saw
4. Before moving the saw tighten the slide lock knob, mitre handle and bevel lock knob to guard against sudden movement. ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW... - Page 10 Place the saw on a secure stationary work surface and check the saw over carefully. Check particularly the operation of all the machines safety features before commissioning or operating the machine. SAFETY RULES FOR YOR ERBAUER BATTERY CHARGER WARNING! READ AND UNDERSTAND ALL OF THESE INSTRUCTIONS. SAVE THESE INSTRUCTIONS FOR FUTURE OPERATOR USE.
- Page 11 40°C (104°F). Allow to cool down after charging. Charging is at its most efficient when carried out between 18-24 2. Only use the battery charger supplied with your Erbauer machine. Other chargers may be dangerous. 3. Always protect the battery terminals when the battery pack is not used. Cover the terminals with a heavy insulation tape to ensure that a short circuit cannot occur.
- Page 12 - Do not change the laser light assembly with a different type. Repairs must be carried out by the laser manufacturer or an authorised agent. ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW...
-
Page 13: Specific Safety Rules And Symbols
Do not throw into water or expose to rain Only use genuine Erbauer replacement saw blades. Unauthorised blades may be dangerous! Keep saw blades securely fastened. Check the blade flanges for debris before installing any new blade. Do not use dull, broken or damaged blades. Check the blade regularly for condition and wear. - Page 14 RH OVERVIEW OF MITRE SAW Fig 1 ERBAUER 24V 165MM SLIDING BEVEL MITRE SAW SPECIFICATION 1. SLIDE CARRIAGE LOCK KNOB 2. SAFETY HEAD RELEASE LEVER 3. POSITIVE STOP LOCKING LEVER 4. MITRE LOCK HANDLE 5. MITRE LOCK HAND-WHEEL 6. SAW HEAD LOCK PIN 7.
- Page 15 Fig 2 ERBAUER 24V 165MM SLIDING BEVEL MITRE SAW SPECIFICATION 9. DUST BAG OUTLET 10. TABLE TOP 11. ON/OFF TRIGGER SWITCH 12. TRIGGER SWITCH SAFETY LOCK BUTTON 13. LASER SWITCH 14. RETRACTABLE SAFETY GUARD 15. HOLD DOWN CLAMP 16. CARRY HANDLE 17.
-
Page 16: Technical Data
(taking account of all parts of the operating cycle such as the times when the tool is switched off and when it is running idle in addition to the trigger time). ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW... -
Page 17: Getting Started
1. Clamping System – the design of this machine allows for the use of a top clamp which can be fitted either side of the blade in the sockets incorporated into the fence. Additional accessories can be obtained by contacting your local dealer (or Erbauer Power Tools). -
Page 18: Installing Or Removing A Blade
(Fig. 3) 6. Using the supplied Hex-headed spanner release Fig 3 the arbor screw to remove the blade. (Fig. 4) Note: The arbor screw has a left hand thread. Fig 4 ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW... - Page 19 16. Check the operation of the guard mechanism. Warning: Ensure the blade guard is fully functional before using the machine. Note: Spacers and spindle rings should not be used with this machine and/or blade ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW...
- Page 20 2. Plug the charger into a suitable power socket. The red LED will illuminate. 3. Slide the Erbauer 24V battery pack into the docking port of the charger while squeezing the buttons located on either side of the battery casing.
-
Page 21: Installing Or Removing The Battery Pack
To remove the Battery Pack, simply press the two locking buttons with your finger and thumb and slide the Battery Pack from the handle. ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW... -
Page 22: Hold Down Clamp
‘dry run’ with the cutting head set to the required bevel and mitre angle. 5. When satisfied that the blades path is unobstructed tighten the two screws and replace the battery. ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW... -
Page 23: The Laser Guide
• The laser beam shall not be deliberately aimed at personnel and shall be prevented from being directed towards the eyes of a person. ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW... -
Page 24: Preparing To Make A Cut
• Do not change the laser module assembly with a different type. • Repairs to the laser module must only be conducted by Erbauer Power Tools or their authorised agent. 2. RELEASING THE SAW HEAD a) Gently press down on the cutting handle. -
Page 25: Body And Hand Position
Secure with clamps if necessary. b) Grasp the saw handle. c) Turn on the saw using the trigger switch and allow the blade to reach full operating speed. Fig 13 ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW... -
Page 26: Slide Cutting
8. Push the cutting head to the full rear position after each cut. 9. Release the trigger to switch off the saw. Allow the blade to come to a complete halt before moving hands or removing the workpiece. ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW... -
Page 27: Mitre Cutting
8. When the cut is completed, release the trigger switch and allow the saw blade to come to a complete halt, before removing the workpiece or your hands from the saw. ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW... -
Page 28: Compound Cutting
5. When cutting is complete re-adjust the depth stop so that the cutting head can be locked in the down position by the head latching pin. 6. Return the depth stop plate to its original position. ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW... -
Page 29: Cutting Bowed Material
MAINTENANCE & ADJUSTMENTS PRECISION SETTING OF ANGLES Warning: Before making any adjustments, or carrying out maintenance to the saw, make Fig 19 sure that it is disconnected from the mains supply. ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW... - Page 30 Loosen the locknut b) Using a suitable hex key screw the 90 adjustment screw clockwise or counter Fig 21 clockwise until correct alignment has been achieved. (Fig 22) c) Retighten the locknut. Fig 22 ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW...
-
Page 31: Aligning The Laser
2) Plug saw into outlet and turn on the laser beam and line it up with the pattern line. 3) Lower saw blade to pattern line and if blade is not flush with the pattern line, adjustment may be necessary ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW... - Page 32 Any maintenance must be carried out with the machine switched off and disconnected from the mains power supply. All motor bearings in this machine are lubricated for life. No further lubrication is required. ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW...
-
Page 33: Plug Replacement
AMP fuse must be fitted. ENVIRONMENTAL PROTECTION Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW... -
Page 34: Declaration Of Conformity
Standards and technical specifications referred to: EN55014-1: 2006 EN55014-2/A2:2008 EN61000-6-3: 2007 EN61029-2-9: 2002 EN61029-1: 2009 EN60335-1 EN60335-2-29 EN50366 EN61000-3-2 EN61000-3-3 Authorised Signatory Date: 30/09/2010 Signature: Name Peter Harries Erbauer (UK) Ltd Quality Manager ERBAUER 24V 165MM SINGLE BEVEL MITRE SAW...
