DFI 865pe infinity User Manual page 7

1.2.3 USB Power Power Select
If you are using the Wake-On-USB Keyboard function for 2 USB ports,
the 5VSB power source of your power supply must support ≥1.5A.
If you are using the Wake-On-USB Keyboard function for 3 or more
USB ports, the 5VSB power source of your power supply must sup-
port ≥2A.
1.3 Rear Panel I/O Ports
PS/2
Mouse
PS/2
K/B
865pe infinity 74740410 1.pmd
Parallel
COM USB 1-2 USB 3-4
S/PDIF-in
S/PDIF-out
7
Quick Setup Guide
3
2
USB 1-4
1
(JP1)
1-2 On: VCC
(default)
USB 5-8
1 2 3
(JP4)
1-2 On: VCC
(default)
RJ45
Mic-in
IEEE
LAN
1394
Line-out
1
3
2
1
2-3 On: 5VSB
1 2 3
2-3 On: 5VSB
Line-in
Center/Bass
Rear out
