Sierra Wireless AirLink LS300 Quick Start Manual

®
AirLink LS300 Quick Start Guide
This guide provides instructions for quickly getting your Sierra Wireless
For more information refer to the:
• AirLink LS300 User Guide
™
• ALEOS Confi guration User Guide
Both are available for download from the Sierra Wireless web site (www.sierrawireless.com/Support/Downloads).
STEP 1 Install the SIM Card (Does Not Apply to CDMA Devices)
1 Remove the rear panel access cover.
2 Slide the SIM card into the SIM card holder.
Note the location of the notched corner for correct alignment.
3 Re-attach the cover.
STEP 2 Connect and Turn On the Device
NOTE: If you want to confi gure all your devices at the same time using AirVantage
register your devices before applying power.
1 Connect the RF antenna.
3 If required by your application,
connect the RS-232 port and/or the
USB port.
5 Connect the power cable to the device.
The device starts automatically, as indicated by the fl ashing LEDs.
© 2013 Sierra Wireless All Rights Reserved
2
Page 1
PN 2400272 Rev. 1
®
LS300 device confi gured and connected.
® Management Service, follow the instructions on page 2 to
If required, connect the GPS and/or the diversity antenna (recommended).
®
4 Connect a Windows computer to the device with an Ethernet cable.
