Connecting your ESI phone

Use the diagram (below) to connect your ESI phone. The diagram represents the panel on the phone's

underside.

Note: The "Top of phone" and "Bottom of phone" references in this diagram shows the correct vertical

orientation of the phone — i.e., the part with the display is the top.

Handset

Line cord

to wall

Note: Use the wall mount hook (located under the handset) when the phone is in the furthest upright position.

A.4

12-Key Digital Feature Phone

24-Key Digital Feature Phone

•

Connects like a basic phone.

•

Handset plugs into right-side jack.

•

Line cord plugs into left-side jack.
