  • Page 1 P A I N T S P R A Y I N G E Q U I P M E N T ENGLISH...
  • Page 2 Due to a constant product improvement programme, the factory reserves the right to modify technical details mentioned in this manual without prior notice. This manual is to be considered as an English language translation of the original manual in Italian. The manufacturer shall bear no responsibility for any damages or inconveniences that may arise due to the incorrect translation of the instructions contained within the original manual in Italian.

  • Page 3: Table Of Contents

    ONLY USE THIS MACHINE FOR USAGE SPECIFICALLY MENTIONED IN THIS MANUAL. Thank you for choosing a LARIUS S.R.L. product. As well as the product purchased, you will receive a range of support services enabling you to achieve the results desired,...

  • Page 4: Working Principle

    DALì WORKING PRINCIPLE The LARIUS DALÍ unit is defined as an “electric diaphragm a vacuum. The product is sucked up, pushed towards the pump outlet and sent to the guns through the flexible hose . A hydraulic pump”. An electric diaphragm pump is used for high pressure valve on the hydraulic case head allows setting and checking paint spraying without air (known as “airless”).

  • Page 5: Description Of The Equipment

    DALì DESCRIPTION OF THE EQUIPMENT POS. POS. Description Description Carriage LARIUS AT 250 gun Electric / combustion motor Fast clean High pressure manometer Tools box Setting valve Recirculation valve Hydraulic oil filling cap Recirculation pipe connection Hydraulic body Feed tube connection...

  • Page 6: Transport And Unpacking

    Unpack the machine and verify if there has been PERLY. any damage due to transportation. In case of damage, call immediately LARIUS and the Shipping Agent. All the notices about possible damage or • ALWAYS FOLLOW THE INSTRUCTIONS ABOUT SAFETY anomalies must arrive timely within 8 days at least from AND THE REGULATIONS IN FORCE.

  • Page 7: Setting-Up

    DALì CONNECTION BETWEEN PUMP, FLEXIBLE HOSE AND Electrical safety precautions SPRAY GUN BEFORE USING THE EQUIPMENT. • Check the "ON/OFF" switch is on the "OFF" position before • ALWAYS USE THE FLEXIBLE HOSE SUPPLIED WITH connecting the cable to the mains. STANDARD KIT.
  • Page 8 DALì Should anyone use an extension cable • Check the mains voltage corresponds to the equipment’s rating (F1). between the tooling and the socket, it must have the same characteristics as the cable supplied (minimum diameter of the wire 2.5 ) with a maximum length of 50 mt.
  • Page 9 DALì • Lift the suction pipe and dip it into the solvent tank (F5). • Point the gun at a container keeping the trigger pressed (so as to drain the oil inside) till a clean solvent comes out. Now, release the trigger. •...

  • Page 10: Working

    DALì WORKING START OF THE PAINTING OPERATIONS Use the tooling after performing all the SETTING UP operations • above described. • Make sure the product recycles from the return tube (G4). • Dip the suction pipe (G1) into the product tank. •...

  • Page 11: Cleaning At The End Of The Work

    DALì CLEANING AT THE END WORK • Reduce pressure to the minimum (turn counterclockwise the pressure control knob (H1) ). • Press the ON/OFF switch (H2) placed on the box of the • Make sure the solvent recycles the washing fluid from the electric motor, to stop the equipment.

  • Page 12: Routine Maintenance

    DALì ROUTINE MAINTENANCE TOP UP HYDRAULIC OIL CLEANING THE COMPRESSION VALVE With each start up, check the hydraulic oil level by looking through When the compression valve (I3) must be removed, clean it with the gauge (I1) on the side of the hydraulic body. If necessary, use specific solvents depending on the type of paint used and refit all “AGIP OSO 46 type hydraulic oil”...

  • Page 13: Lwarning Plate

    Clean the motor cooling fan protection guard (I6) periodically to ensure the best cooling. WARNING PLATE Apparecchi per verniciatura Paint spraying units ATTENZIONE WARNING UTILIZZARE GRUPPI ELETTROGENI USE POWER UNITS WITH CON ALTERNATORE ASINCRONO ASYNCHRONOUS ALTERNATOR http: www.larius.com e-mail larius@larius.com...

  • Page 14: Mproblems And Solutions

    DALì PROBLEMS AND SOLUTIONS Problem Solution Cause The equipment does not start • Check the correct connection to the • • Lack of voltage; power supply; • Check the extension cable; • Considerable drops in mains voltage; • Ensure the ON-OFF switch is on the •...

  • Page 15: Ncorrect Procedure Of Decompression

    DALì CORRECT PROCEDURE OF DECOMPRESSION • Insert the gun clamp (N1). • Move the ON/OFF switch (N2) to the OFF position (0) to stop the equipment. • Set the valve (N3) at its minimum pressure setting (turn anticlockwise). • Disconnect the power supply cable (N4). •...

  • Page 16: Ocomplete Hydraulic Body

    DALì COMPLETE HYDRAULIC BODY...
  • Page 17 DALì Pos. Code Description Pos. Code Description 18925 Electric motor mono-phase 220V 18931 Identification plate 110V 60Hz 50Hz complete 18932 Petrol identification plate 18926 Electric motor mono-phase 110V 18933 Identification plate 380V 50Hz 60Hz complete 34020 Rivet 18924 Electric motor three-phases 380V 32007 Oil inspection window 50Hz complete...

  • Page 18: Pdalì Petrol - Dalì Liner

    DALì DALÌ PETROL - DALÌ LINER...
  • Page 19 DALì Pos. Code Description Pos. Code Description 18260 Complete gearbox – petrol membrane 18267 Bearing version 18344 Screw B+C+D 18340 Complete gearbox kit – Dalì petrol 95114 Washer version with trolley 18268 Hydraulic flange 18347 Complete Dalì liner kit 81009 Dowel 4415 Motor...

  • Page 20: Qcomplete Colour Body

    DALì COMPLETE COLOUR BODY VERTICAL VERSION...
  • Page 21 DALì Pos. Code Description Pos. Code Description 18951 Vertical colour body 33021 Shutter guide 33033 Valve assembly 33022 Spring 33026 Gasket 33023 Washer 33027/2 Ball seat 33024 33027/1 Valve housing 33025 Seal sleeve 33028 Ball 18922 Recirculation valve assembly 33029 Spring seat 33012 Washer...
  • Page 22 DALì HORIZONTAL VERSION Pos. Code Description Pos. Code Description 18915 Standard colour body 33018 Gas-ring 33033 Valve assembly 33019 Conical shutter 33026 Gasket 33020/1 Spear valve seat 33027/2 Ball seat 33020 Valve body 33027/1 Valve housing 33021 Shutter guide 33028 Ball 33022 Spring...

  • Page 23: Rhigh Pressure Gun "At 250

    DALì HIGH PRESSURE GUN "AT 250" Components Pos. 5 - 11023 - Linkage 11005/3 Ball 11204/1 Ball housing 11205/2 Spring 11205/4 Linkage 11205/5 Sleeve 11205/6 Ring sleeve 11205/7 Bushing Pos. Code Description Pos. Code Description Nozzle Super Fast Clean 11027 Nut M3 See table* 18270...

  • Page 24: Ssuction System

    DALì SUCTION SYSTEMS Pos. Code Description 85009 Suction systems 85010 Suction tube 16609 Recirculation tube 18096 Spring 85012 Filter of suction...

  • Page 25: Ttrolley

    DALì TROLLEY ELECTRIC MOTOR Pos. Code Description 18911 Trolley assembly 95159 Plug 18912 Handle 18914 Bushing 18902 Split pin 18913 Trolley frame 37218 Pneumatic wheel 91047 Washer 12454 Feet 12473 Plug...
  • Page 26 DALì COMBUSTION MOTOR Pos. Code Description 12355 Trolley assembly 12454 Foot 12710 Trolley base 37218 Pneumatic wheel 91047 Elastic washer 84007 Split pin 12711 Trolley handle 12473 Plug...

  • Page 27: Uaccessories

    DALì ACCESSORIES Art. 11250: AT 250 1/4" Code 270: FILTER 100 MESH Art. 11200: AT 250 M16x1,5 Code 271: FILTER 60 MESH PISTON GUNSTOCK FILTERS Code 147: HIGH PRESSURE GAUGE M16x1,5 Code 11039: Green (30M) - Code 11038: White (60M) Code 150: HIGH PRESSURE GAUGE GJ 1/4"...
  • Page 28 DALì HIGH PRESSURE HOSE 3/8" - M16x1,5 max pressure 425 bar ANTISTATIC HOSE 3/16" - M16x1,5 max pressure 210 bar Code 18063: 7,5 mt Code 6164: 5 mt Code 18064: 10 mt Code 55050: 7,5 mt Code 18065: 15 mt Code 35018: 10 mt ANTIPULSATIONS 1/4"...
  • Page 29 DALì GUN EXTENSION Art. 153: cm 30 -Art. 153: cm 40 Art. 155: cm 60 - Art. 158: cm 80 - Art. 156: cm 100 PLA 1/4” + BASE SUPER FAST-CLEAN Art. K11420-K11425-K11430: cm 130-180-240 PLA M16x1,5 + BASE SUPER FAST-CLEAN Art.
  • Page 30 DALì DALÌ VERSIONS HORIZONTAL WITHOUT ACCESSORIES Ref. 18900: 220V / 50 Hz Ref. 18920: 110V / 60 Hz Ref. 18955: 380V / 50 Hz Ref. 18956: Petrol HORIZONTAL WITH ACCESSORIES Ref. 18957: 220V / 50 Hz Ref. 18958: 110V / 60 Hz Ref.
  • Page 31 L’innovazione. Quella vera. PAINT SPRAYING EQUIPMENT...
  • Page 32 MIRO' Rif. 21500 GIOTTO Rif. 12450 MANUFACTURER: 23801 CALOLZIOCORTE - LECCO - ITALY - Via Antonio Stoppani, 21 Tel. (39) 0341/62.11.52 - Fax (39) 0341/62.12.43 E-mail: larius@larius.com - Internet http://www.larius.com DIRECT LINE CUSTOMERS TECHNICAL SERVICE Tel. (39) 0341/621256 Fax (39) 0341/621234...
