Elba INDUCTION BUILT-IN COOKTOP Instructions For The Use - Installation Advices page 26

CONNECTION/REPLACEMENT
THE POWER SUPPLY CABLE
Important! This
connected to the electricity supply only
by an authorised person.
Turn the cooktop over and unhook the
terminal board cover by inserting a
screwdriver into the two hooks "A" (fig. 5.1).
Open the cable gland by unscrewing screw
"F" (fig. 5.2), unscrew the terminal screws.
The supply cable, of suitable type and
section, is connected to the terminal board
following the diagram in fig. 5.3.
FEEDER CABLE SPECIFICATIONS
220-240V~
Type H05RR-F
Type H05V2V2-F
(**) Connection with wall box connection
WARNING: If the power supply cable is
damaged, it must be replaced only by
an authorised service agent in order to
avoid a hazard.
26
cooktop must
3 x 2,5 mm
2
3 x 2,5 mm
2
OF
be
Fig. 5.1
(**)
(**)
Fig. 5.2
220-240 V
L
Fig. 5.3
E E arth
N Neutral
L Live
N
E
F
