Gas cooktops

Installation instructions

CG302L and CG604L models
User guide
and
NZ AU

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CG302L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Elba CG302L

  • Page 1: Installation Instructions

    Gas cooktops Installation instructions CG302L and CG604L models User guide NZ AU...
  • Page 3: Table Of Contents

    Contents Safety and warnings Installation instructions Introduction Using your cooktop Care and cleaning Troubleshooting Warranty and service Important! SAVE THESE INSTRUCTIONS The models shown in this user guide may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country, please visit our local website listed on the back cover or contact your local Fisher &...
  • Page 4: Safety And Warnings

    Safety and warnings WARNING! Cut Hazard Beware of sharp edges when handling stainless steel appliances. Failure to use caution could result in injury or cuts. WARNING! Electrical Shock Hazard Before carrying out any work on the electrical section of the appliance, it must be disconnected from the mains.
  • Page 5: Electrical Requirements

    Safety and warnings No combustible material or products should be placed on this product at any time. Do not spray aerosols in the vicinity of this product while it is in operation. Installation must be carried out according to the manufacturer's instructions. Incorrect installation may cause harm and damage to people, animals or property, for which the manufacturer accepts no responsibility.
  • Page 6 Safety and warnings Safety and warnings Operation WARNING! Hot Surface Hazard This appliance becomes hot during use. Do not touch the cooktop components, burners, trivets, pan supports or the base when hot. Before cleaning, turn the burners off and make sure the whole cooktop is cool. Failure to follow this advice may result in serious injury.
  • Page 7: Important Safety Instructions

    Safety and warnings Safety and warnings Important safety instructions Operation Household appliances are not intended to be played with by children. Children, or persons with a disability which limits their ability to use the appliance, should have a responsible person to instruct them in its use. The instructor should be satisfied that they can use the appliance without danger to themselves or their surroundings.
  • Page 8: Installation Instructions

    65 °C above ambient. To comply with this requirement satisfactorily, fix 5 mm-thick ceramic tiles to the surface or attach fire-resistant material to the surface and cover with sheet metal (minimum thickness 0.4 mm). CG302L CG604L Fig. 1 Product and cutout dimensions...
  • Page 9 Installation instructions Installation clearances and protection of combustible surfaces shall comply with the current local regulations e.g. AS/NZS 5601.1 - Gas Installations code. CG302L CG604L Fig. 2 Clearances CG302L Spacer Double-sided CG604L Adhesive tape Fig. 3 Mounting the base clearance spacers...
  • Page 10 Fasten the brackets “A” to the appropriate socket holes, without tightening the screws “B” for the moment. CG604L CG302L Fig. 4 Fastening the installation brackets Fastening the cooktop Spread the sealing material “C” out along the edge of the cutout, making sure that the junctions overlap at the corners.
  • Page 11 For Natural gas, connect the gas supply to the gas pressure regulator which is supplied with the appliance (Fig. 6). Adjust the regulator to obtain a test point pressure of 1 kPa (with both burners operating at the maximum for model CG302L; with the two semi-rapid burners operating at the maximum for model CG604L).
  • Page 12 Natural Gas Test point Pressure [kPa] 2.75 Model and burner Injector Gas consumption Injector Gas consumption orifi ce diameter [mm] [MJ/h] orifi ce diameter [mm] [MJ/h] CG302L Semi-rapid (front) 1.12 6.30 0.70 6.30 Rapid (rear) 1.45 10.40 0.91 10.80 CG604L Auxiliary (right front) 0.85...
  • Page 13 Installation instructions Converting to a different gas type Important! The conversion procedure must be carried out only by an authorised person. This appliance is suitable for use with Natural gas or LPG (check the “gas type” sticker attached to the appliance). To convert from one gas type to another, you need to replace the injectors, and then adjust the minimum burner setting.
  • Page 14 Installation instructions Adjusting the minimum burner setting When changing from one type of gas to another, the minimum valve output must also be correct, considering that in this position the flame must be about 4 mm long and must re- main lit even when the knob is turned quickly from the maximum to the minimum position.
  • Page 15 Installation instructions CG302L Wiring diagram Ignition switch Ignition coil Terminal block Spark electrode Fig. 11 Wiring diagram (CG302L) CG604L Wiring diagram Ignition switches group Ignition coil Terminal block Spark electrode Fig. 12 Wiring diagram (CG604L)
  • Page 16: Introduction

    About your new cooktop Thank you for buying an ELBA by Fisher & Paykel gas cooktop. Once it is installed and ready to use, you will want to know everything about it to make sure you get excellent results right from the start.
  • Page 17: Using Your Cooktop

    Using your cooktop Control knobs The knobs control the flow of gas through the valve. (closed valve) HIGH Burner indicator Fig. 15 Control knob Using the burners Press the selected burner’s knob down gently and turn it anti-clockwise to HIGH The ignitors on all the burners will spark.
  • Page 18 Using your cooktop If a burner does not light Turn the control knob to (OFF) and wait at least 1 minute before trying again. This is to allow the gas to disperse. If after trying again the burner still does not light, check that: the cooktop is plugged in and the power supply is switched on there is no power failure in your home or neighborhood the gas is turned on...
  • Page 19 Using your cooktop If there is a power failure You can still use your cooktop. Light the burners by holding a match close to the side of the burner and turning the control knob to HIGH . Wait until the flame is burning evenly before adjusting. If the flame is accidentally extinguished The flame failure protection will automatically cut the gas supply to the burner off.
  • Page 20: Cooking Guidelines And Cookware

    Make sure the size of the pan matches the size of the burner. A small pot on a large burner is not efficient. The following table shows the minimum and maximum saucepan base diameters that may be used on each burner: Model and burner Minimum Diameter Maximum Diameter CG302L Semi-rapid (front) 12 cm* 20 cm Rapid (rear) 22 cm...
  • Page 21 Fig.20 Using the wok stand Small pan support This pan support is to be placed on top of the front (CG302L models) or right front (CG604L models) burner when using a small diameter pan, in order to prevent it from tipping over.
  • Page 22: Care And Cleaning

    Care and cleaning Important! Before any cleaning or maintenance, always: turn all burners off switch the power to the cooktop off at the wall make sure that the cooktop and its parts are a safe temperature to touch. General advice Clean the cooktop regularly—do not let stains become burnt on.
  • Page 23 Care and cleaning How? Important! What? How often? Remove the parts that you wish to clean. Make sure you keep the Burner See the Figs. following for illustrations of notches of the flame spreaders parts, pan supports, removable burner parts. clear.
  • Page 24 Care and cleaning Replacing the burner parts correctly Semi-rapid, rapid, and auxiliary burners Flame spreader Probe Fig.22 Correct positioning of semi-rapid, rapid, Ignitor and auxiliary burner parts Triple-ring wok burner (CG604L models only) Fit the flame spreader to the housing as shown by the arrow in Fig.23 following. Make sure the burner is not able to rotate.
  • Page 25: Troubleshooting

    Troubleshooting Problem Possible solutions A burner does not light. Check that the power to the cooktop is switched on at the wall and there is no power failure. Check the gas supply valve is turned on and the supply to the house is working.
  • Page 26: Warranty And Service

    Warranty and service Before you call for service or assistance ... Check the things you can do yourself. Refer to the installation instructions and your user guide and check that: Your product is correctly installed. You are familiar with its normal operation. If after checking these points you still need assistance or parts, please refer to the Service &...
  • Page 28 Copyright © Fisher & Paykel 2013. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your Dealer to ensure this booklet correctly describes the product currently available.
