  • Page 1 User Guide Universal Vehicle Kit...

  • Page 2: Table Of Contents

    Table of Contents Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Introduction .

  • Page 3: Compatibility

    Compatibility This Universal Vehicle Kit is compatible with the following Dock & Play Radios: SiriusXM: • Onyx Plus • Edge • Onyx • Onyx EZ • XpressRCi • XpressRC • XpressR Sirius: • Sportster 5 • Starmate 8, 5, 4, 3 • Stratus 7, 6, 5...

  • Page 4: Introduction

    Features Thank you for purchasing the Universal Vehicle Kit! Your Universal Vehicle Kit has everything you need to use your compatible SiriusXM Dock & Play Radio in another vehicle . • Add Satellite Radio to an additional vehicle: No need for a second subscription .

  • Page 5: Safety And Care Information

    Introduction Safety and Care Information IMPORTANT! Self installation instructions and tips are provided for your convenience . It is your responsibility to determine if you have the knowledge, skills, and physical ability required to properly perform an installation . SiriusXM shall have no liability for damage or injury resulting from the installation or use of any SiriusXM or third party products .
  • Page 6 Introduction WARNING! • Opening the case may result in electric shock . • Make sure that you insert the PowerConnect Power Adapter’s plug all the way into the vehicle’s cigarette lighter or power adapter socket . • If you are using PowerConnect as your audio connection option, it is advisable not to insert a multi-outlet adapter into the same vehicle cigarette lighter or power adapter socket to simultaneously power other devices .

  • Page 7: What's In The Box

    Introduction What’s in the Box? XM & SiriusXM Sirius Radio Dock Adapter Radio Dock Adapter Power Connect™ Vehicle Dock Aux In Cable Dash Mount Vent Mount and Extended Vent Clamps Magnetic Mount Power Connect Alcohol Screws (4) Antenna Power Adapter Preparation Pads TIP! For other accessories you can add to your Vehicle Kit –...

  • Page 8: Powerconnect Vehicle Dock

    Introduction PowerConnect Vehicle Dock Color-Coded Connections The color-coded PowerConnect Vehicle Dock makes it simple to connect . Just match the colors on the cable ends to the colors on the dock to see what goes where . Side View Right Left AUDIO AUDIO (Green)
  • Page 9 Introduction Wire Guide The PowerConnect Vehicle Dock has a channel across the back to help organize the wires connected to the dock . If you need to bring a wire from one side of the dock to the other side, utilize the wire guide channel to keep the wires tidy . Rear View Wire Guide Channel...

  • Page 10: Vehicle Installation

    Vehicle Installation Step 1: Insert the Radio Dock Adapter Into the Dock You’ll need to insert the Radio Dock Adapter that is compatible with your Radio into the Vehicle Dock . 1. Locate the Radio Dock Adapter that is compatible with your Radio . If you have an XM or SiriusXM Radio: If your Radio is branded as XM* or SiriusXM*, select the Radio Dock Adapter marked XM &...
  • Page 11 Vehicle Installation 2. Orient and place the Radio Dock Adapter that you selected into the Vehicle Dock . Be sure the adapter is centered, and is seated all the way down into the dock . 3. Once the adapter is seated correctly in the Vehicle Dock, gently press the top of the adapter against the dock with your finger until it clicks into place .
  • Page 12 Vehicle Installation Dock, use your fingernail to gently press down on the top of the adapter, and then use a long thin object such as a paper clip, a screw driver, or something similar to pry the adapter away until it releases from the dock . Then lift the adapter up and out of the dock .

  • Page 13: Step 2: Choose A Location For Your Radio

    Vehicle Installation WARNING! DO NOT attempt to install this Vehicle Kit while driving . Park your vehicle in a safe location before beginning installation . Step 2: Choose a Location for Your Radio When installing the PowerConnect Vehicle Dock in your vehicle, choose a location where it will not block your vision, interfere with the controls, or obstruct the air bag .
  • Page 14 Vehicle Installation Option 1 - Dash Mount Option 2 - Dash Mount Option 3 - Dash Mount Option 4 - Dash Mount...
  • Page 15 Vehicle Installation Option 5 - Vent Mount Option 6 - Vent Mount...

  • Page 16: Step 3: Install The Dash Or Vent Mount

    Vehicle Installation Step 3: Install the Dash or Vent Mount Follow the instructions on the next several pages for the mounting method you have selected . NOTE! The PowerConnect Vehicle Dock included with the this Vehicle Kit is compatible with the T-slot style Dash and Vent Mounts . If you have an existing Dash Mount or Vent Mount in your vehicle, you can continue to use it with this dock, and skip this step .
  • Page 17 Vehicle Installation necessary for your particular vehicle . When the orientation is correct, tighten the knob . Dock Mounting Plate Knob Adhesive Foot 4. Attach the Adhesive Mount to the PowerConnect Vehicle Dock using the 4 provided screws . If you plan to use the wire guide channel across the back of the Vehicle Dock to organize the wires, do not fully tighten the screws .
  • Page 18 Vehicle Installation Installing the Vent Mount: IMPORTANT! To make the cable connections easier, wait until after you have connected all the cables to the dock before you attach the Vent Mount to a vent . Extended Vent Clamps 1. Locate a vent with horizontal louvers sturdy enough to hold your PowerConnect Vehicle Dock and Radio .
  • Page 19 Vehicle Installation 3. Attach the Vent Mount to the PowerConnect Vehicle Dock using the 4 provided screws . If you plan to use the wire guide channel across the back of the Vehicle Dock to organize the wires, do not fully tighten the screws . If not, tighten the screws .

  • Page 20: Step 4: Mount The Magnetic Mount Antenna

    Vehicle Installation Step 4: Mount the Magnetic Mount Antenna Mount the Magnetic Mount Antenna on the outside of your vehicle, on a horizontal surface that will always face the sky . The antenna contains a strong magnet which will stick to any metal part of your vehicle, but will not damage the vehicle .
  • Page 21 Vehicle Installation SUV: We recommend mounting the antenna at the rear of the roof as shown . Convertible: We recommend mounting the antenna at the leading edge of the trunk as shown . Pickup Truck: We recommend mounting the antenna just above the front windshield as shown .
  • Page 22 Vehicle Installation 3. Place the antenna in the location you selected . Follow the Tips and Cautions shown on the next several pages . TIP! Mount the antenna on the roof (for most vehicles) or trunk (for convertibles) where it has a clear view of the sky in all directions .
  • Page 23 Vehicle Installation CAUTION! Don’t mount the antenna inside the vehicle, for example, on the dashboard . CAUTION! Don’t mount the antenna on any of the vehicle’s front, back or side pillars . CAUTION! Don’t mount the antenna close to a roof rack . Adjust the rack so it’s further away from the antenna or move the antenna closer to the center of the roof .
  • Page 24 Vehicle Installation CAUTION! Don’t mount the antenna close to another antenna . Mount it at least 3 inches away .

  • Page 25: Step 5: Route The Magnetic Mount Antenna Cable

    Vehicle Installation Step 5: Route the Magnetic Mount Antenna Cable Before you begin routing the antenna cable, read these general instructions for how to route and hide the antenna cable . Then route your antenna cable according to the instructions which follow for your specific type of vehicle . Use a blunt plastic putty knife, a credit card, a plastic knife, or a similar blunt tool to lift the rubber window moulding...
  • Page 26 Vehicle Installation Route cable out from under rear windshield moulding and tuck into weatherstripping around trunk opening Avoid sharp bends by running cable through Pull weatherstripping weatherstripping for several inches from trunk opening Tuck cable into weatherstripping. Route cable through weather- stripping several inches to avoid sharp bends Pull cable out of weatherstripping...
  • Page 27 Vehicle Installation Bring cable out of weatherstripping and into trunk Route cable along trunk wall and into cabin through gap or conduit, along existing wiring harness Route cable along trunk wall and into cabin...
  • Page 28 Vehicle Installation Use a blunt plastic putty knife or similar blunt tool to lift edge of interior trim and tuck cable Route cable under under trim. Continue trim or upholstery towards front of vehicle Continue routing cable under trim or carpet towards front of vehicle Route cable from trunk under interior trim, into...
  • Page 29 Vehicle Installation Continue routing cable under carpet or console to radio location Coil excess cable under Pull carpet carpet or mat or mat back Bring cable out from trim Bring cable out from trim and route under carpet to dashboard or console TIP! Always be careful to include enough slack in your cable to accommodate open doors or trunk lids .
  • Page 30 Vehicle Installation Sedan/Coupe With the Antenna Placed at the Rear of the Roof: 1. Feed the antenna cable from the antenna underneath the rubber molding around the rear window . Use a blunt plastic putty knife or similar blunt tool to lift the rubber molding around the rear window and tuck the antenna cable underneath the molding .
  • Page 31 Vehicle Installation 5. Bring the cable out from the trim near the front of the cabin and route it under the carpet toward the dashboard or console . Coil any excess cable in a hidden location, such as under the carpet, keeping it away from any vehicle pedals or controls .
  • Page 32 Vehicle Installation Sedan/Coupe With the Antenna Placed at the Front of the Roof: 1. Feed the antenna cable from the antenna underneath the rubber molding around the windshield . Use a blunt plastic putty knife or similar blunt tool to lift the rubber molding around the windshield and tuck the antenna cable underneath the molding .
  • Page 33 Vehicle Installation SUV: 1. Feed the antenna cable underneath the rubber weather stripping of the rear tailgate window/door and route the cable along the rear hatch . Lift the weather stripping from the opening and tuck the cable inside it, then replace the weather stripping .
  • Page 34 Vehicle Installation Convertible: 1. Bring the antenna cable from the antenna into the trunk at the front edge of the trunk lid . Keep any bends in the cable loose . Tape or tie the cable along the inside of the trunk lid to the trunk lid hinge strut . 2.
  • Page 35 Vehicle Installation Pickup Truck: 1. Use a blunt plastic putty knife or similar blunt tool to lift the rubber molding around the windshield and tuck the antenna cable underneath it . 2. Continue tucking the cable underneath the windshield molding around the windshield to the lowest corner .

  • Page 36: Step 6: Connect The Magnetic Mount Antenna And Powerconnect Power Adapter

    Vehicle Installation Step 6: Connect the Magnetic Mount Antenna and PowerConnect Power Adapter 1. Plug the Magnetic Mount Antenna into the silver ANT connector at the side of the PowerConnect Vehicle Dock . AUDIO 2. Insert the PowerConnect Power Adapter into your vehicle’s cigarette lighter or power adapter socket .

  • Page 37: Step 7: Connect The Audio

    Vehicle Installation Step 7: Connect the Audio To play audio through your vehicle’s stereo or FM radio, decide on one of the following audio connection options: • Option 1: Best: Use the provided Aux In Cable if your vehicle’s stereo system has an auxiliary input connection or jack .
  • Page 38 Vehicle Installation Option 1: Aux In Cable Installation Instructions 1. Plug one end of the Aux In Cable into the green AUDIO connector at the side of the PowerConnect Vehicle Dock . AUDIO 2. Plug the other end into the auxiliary input jack connection of your vehicle’s stereo system .
  • Page 39 Vehicle Installation signal strength . The Satellite and Terrestrial bars show the strength of the signal being received . If the signal reception is good, exit the Antenna Aiming or Signal Indicator screen 866-635-2349 and continue with step 8 . siriusxm.com 8.
  • Page 40 Vehicle Installation Option 2: Cassette Adapter Installation Instructions 1. Plug the Cassette Adapter into the green AUDIO connector at the side of the PowerConnect Vehicle Dock . AUDIO 2. Insert the Cassette Adapter into the vehicle’s cassette deck . You may need to turn on your menu PLUS vehicle’s stereo system in order to do so .
  • Page 41 Vehicle Installation signal strength . The Satellite and Terrestrial bars show the strength of the signal being received . If the signal reception is good, exit the Antenna Aiming or Signal Indicator screen 866-635-2349 and continue with step 8 . siriusxm.com 8.
  • Page 42 Vehicle Installation Option 3: PowerConnect Installation Instructions 1. If you are using the vent mounting method, attach the Vent Mount to the vent . menu PLUS alerts 2. Insert your Radio into the dock . t-mix t-scn NOTE: Your Radio may be a different model than the b / # Radio shown here .
  • Page 43 Vehicle Installation channel that has only static or silence on it, until you reach 107 . 9 . 5. Pick the first FM channel on your list from step 4 . Turn on your vehicle’s FM radio (if you have not already done so) and tune it to this FM channel . You should only hear static or silence .
  • Page 44 Vehicle Installation for you, work down the list of FM channels until you find one with which you are satisfied . Each time, you will need to tune your vehicle’s FM radio 99. 3 menu jump direct MATCH FM CHANNELS to the FM channel and then set your satellite Radio to transmit on the same FM channel (steps 5 &...
  • Page 45 Vehicle Installation Option 4: FM Direct Adapter (FMDA) Installation The FMDA needs to be installed by a professional installer . Professional installation can help improve your Radio’s reception and significantly reduce the visibility of wires . To learn more, check with the retailer where you bought your Radio .

  • Page 46: Troubleshooting

    Troubleshooting The Vehicle Kit has been designed and built to be trouble-free, but if you experience a problem, try this: • Check that all connections are firm and secure . • Make sure the vehicle power socket is clean and free of corrosion . • Make sure you have connected the Vehicle Dock as described in this User Guide .
  • Page 47 Troubleshooting If you see this on the screen: Try this: Channel Off Air • The channel you’ve selected is not currently broadcasting . Tune to another channel . Loading or • Your Radio is acquiring audio or program Acquiring Signal information . This message usually goes away in a few seconds .
  • Page 48 Troubleshooting If this happens: Try this: No audio when using the Aux In Cable • Check all cables between your Radio and your or Cassette Adapter vehicle’s stereo system for a firm and secure connection . • Ensure you have selected the proper input source on your vehicle’s stereo system .
  • Page 49 Troubleshooting If this happens: Try this: No audio when using PowerConnect • Check that your Radio and your vehicle’s FM or FMDA radio are tuned to the same FM channel . • Check that the FM transmitter in your Radio is On . Refer to your Radio’s User Guide (go to www . siriusxm .ca/help/user-guides) for instructions .

  • Page 50: Product Specifications

    Product Specifications System Power Requirements: 9-16 V DC, 500 mA (max) Operating Temperature: -4°F to +140°F (-20°C to +60°C) Audio Output: 1 .0 V rms (max) PowerConnect Vehicle Dock Dimensions: 4 . 1 in (width) x 1 .8 in (height) x 1 . 1 in (depth) 105 mm (width) x 46 mm (height) x 28 mm (depth) Weight (without adapter): 1 .4 oz (40 g)

  • Page 51: Patent And Environmental Information

    Patent and Environmental Information Patent Information It is prohibited to, and you agree that you will not, copy, decompile, disassemble, reverse engineer, hack, manipulate, or otherwise access and/or make available any technology incorporated in this product . Furthermore, the AMBE™ voice compression software included in this product is protected by intellectual property rights including patent rights, copyrights, and trade secrets of Digital Voice Systems, Inc .

  • Page 52: Ic Statement

    IC Statement Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device . For product available in the Canada market, only channel 1~11 can be operated . Selection of other channels is not possible .

  • Page 53: Copyrights And Trademarks

    © 2015 Sirius XM Canada Inc . “SiriusXM”, the SiriusXM logo, channel names and logos are trademarks of Sirius XM Radio Inc . and are used under license . “NFL” and the NFL Shield design are trademarks of the National Football League .
  • Page 54 siriusxm .ca Sirius XM Canada Inc . 135 Liberty St . - 4th floor Toronto, Ontario, M6K 1A7 1-877-438-9677 © 2015 Sirius XM Canada Inc . SXDV3UG E 141210a...
