Editing Port Settings - Coyote Point Systems E350GX Installation And Administration Manual

The port setting displayed in the mouseover popup are explained in the table below.
Port Status
Port Speed
Port Duplex
Autonegotiation
In Octets
Out Octets

Editing Port Settings

To edit the settings for any port, click on the port. A popup screen is displayed with the current parameters. Make
changes to the port parameters and click
across system reboots until saved using the
The parameters that appear on the
the port, which can be set to
When is set to
Autonegotiation
With set to
Autonegotiation
The actual negotiated speed and duplex depend on the outcome of the autonegotiation process between the port and
the device on the other end of the connection. This is the recommended setting for the majority of modern
networking devices, and is the default autonegotiation setting for all switch ports.
Equalizer Installation and Administration Guide
Displays Active if the port has an active link, No Link if not.
If the port is Active, this is the current port speed. If there is No Link, this is
the highest speed that can be negotiated, or the forced speed setting.
If the port is Active, this is the current port duplex setting. If there is No
Link, this is the highest duplex that can be negotiated, or the forced duplex
setting.
Can be one of the following: Full (full autonegotiation at all support speeds
and duplex settings), Select (autonegotiation at only selected speeds and
duplex setting), and Force Speed/Duplex (set the port to a particular
speed and duplex).
In Octets and Out Octets are the current count of bytes received and sent
(respectively) through this switch port -- this includes all traffic, including
broadcast traffic as well as traffic not destined for the Equalizer. Note that
these counters do not indicate the number of bytes sent and received
through the port since the last reboot. Each counter has a limit of 2
and when this limit is reached, the counter is restarted.
. Changes to port settings take effect immediately, but will not persist
Apply
button on the
commit
Configure switch port
, , or
Full Select Force Speed/Duplex
(the default setting), the popup looks like this:
Full
, Equalizer will advertise its full range of speed and duplex settings on this port.
Full
Switch Configuration
popup depend on the current
.
Managing Gigabit Switch Ports
32
- 1,
tab.
setting of
Autonegotiation
73
