is still load balanced across all servers associated with VMware virtual machines without the VLB Agent return
value. You can still also add servers and associate virtual machines with them, as long as the VMware login
information on the tab is correct (see "Enabling Equalizer VLB" on page 296).
VLB
1. Log into Equalizer using an account that as
2. Click in the left frame, and then select the
Equalizer
3. Click the
disable VLB
4. Click to save your settings.
commit

Associating a Server with a Virtual Machine

Note – This section applies to VLB Advanced only. VLB Basic automatically associates servers defined on
Equalizer with VMware Virtual Machines by IP address. That is, when you add a server to a cluster with VLB
probing enabled, VLB Basic determines if there is a VMware virtual machine with the same IP address, and if so
makes the association automatically. The server Virtual Machine tab is not present on systems with VLB Basic.
Before you can associate a server with a virtual machine, VLB Agents must be enabled for the cluster, as described
in the previous section. Associations are established either when a server is added to a VLB cluster, or later by
editing an existing server's configuration:
1. Do one of the following:
• If you are adding a new server to a VLB cluster, enable the Virtual Machine check box on the
dialog, and click
Server
button to query VMware.
• To associate an existing Equalizer server with a virtual machine, click the server name in the left frame and
open the
Virtual Machine
VMware.
2. If the query is successful, a list of available vitrual machines is displayed. Choose the virtual machine you want
to associate with the Equalizer server definition and click the
selection to work, VLB must be enabled as described in the section "Enabling Equalizer VLB" on page 296.)
You can add both virtual machines and non-virtual machines (physical servers) to a VLB cluster. The non-virtual
machines will be load balanced without any VLB server agent value.
Similarly, you can mix virtual and non-virtual machines as servers in a non-VLB cluster. The virtual machines will
be load balanced as if they were physical servers, using no VMware data.
Finally, whether you are using VLB as the probe method for the cluster or not, you can use servers which are
associated with virtual machines within Smart Control Events, and these servers will be monitored and controlled as
specified in the events.

Smart Control Event Examples Using VLB

VLB Advanced provides VLB-specific extentions to the Smart Events feature -- additional functions are provided
that let you query a VMware configuration for status information and perform VMware specific operations, such as
powering down a virtual server. See the section "Configuring Smart Events" on page 161 for a complete list of
supported actions and triggers.
Equalizer Installation and Administration Guide
add/del
button near the bottom of the tab.
(>). On the following screen, click the
Next
tab in the right frame. Click the

Associating a Server with a Virtual Machine

permission on global parameters.
tab in the right frame.
VLB
Associate with Virtual Machine
Associate with Virtual Machine
button. (Note that in order for VM
Associate
Add New
button to query
