In this chapter, sample code demonstrating the implementation of the CAN communication interface
is provide. This is the foundation for Softing PCI CAN.

Opening the CAN Communication Channel

Code 2: Opening the CAN Communication Channel
char ch_name[256];
sprintf_s(ch_name, 256, "CAN-ACx-PCI_%d", ch);
INIL2_initialize_channel(&hCAN[ch-1], ch_name);
L2CONFIG L2Config;
L2Config.fBaudrate = 1000.0;
L2Config.bEnableAck = 0;
L2Config.bEnableErrorframe = 0;
L2Config.s32AccCodeStd = 0;
L2Config.s32AccMaskStd = 0;
L2Config.s32AccCodeXtd = 0;
L2Config.s32AccMaskXtd = 0;
L2Config.s32OutputCtrl = GET_FROM_SCIM;
L2Config.s32Prescaler = 1;
L2Config.s32Sam = 0;
L2Config.s32Sjw = 1;
L2Config.s32Tseg1 = 4;
L2Config.s32Tseg2 = 3;
L2Config.hEvent = (void*)-1;
CANL2_initialize_fifo_mode(hCAN[ch-1], &L2Config);
