Flight Manual SL 200 Book 1
d) Fuel tanks (1. 19.) – check the following:
- Fuel amount and refueling
- Fuel tank attachments tightness (visually on the bottom side of fuel tank, additional fuel tanks – if are installed – and
interconnection between main and additional tanks)
- Fuel tank fi ller caps seals
- Free passage of fuel tank ventilation
e) Wings (1. 5. 6. 7. 8. 15. 16. 17. 18. 19.) – check the following:
- Leading edge and whole wing facing
- Winglets riveting
- Pitot tube – right wing only (free passage, condition and direction)
- Nuts and split pins on the main and rear wing attachment point (after removing covering strip)
f) Ailerons (6. 7. 16. 17.) – check the following:
- Ailerons, bolts clearance, free motion in whole range of fl ap positions
- Nuts tightness on attachment, clearaces and bolt security locks
- Aileron control, angled lever, pull-rod forks and joint points security locks
