Do not tilt the processor or shift it into place, doing so may dam-
age the sensitive contacts.
5. Check that the orientation notches and the connection 1 indicator are properly
fitted to the socket body.
6. Close the soket:
- Close the load plate.
- Press gently on the load plate and engage the load lever.
- Secure the load lever under its retention tab.
7. Remove the heatsink from its packaging materials.
8. Place the heatsink on the processor socket.
- Ensure that the fan cable(s) are on the closest side to the fan(s) header(s)
on the motherboard.
- Align the screws with the screwholes on the motherboard.
- Make sure that the heatsink is completely level with the motherboard.
Check the following:
■
No cables are trapped or interfere with the screws.
■
The screws are perpendicular to the heatsink.
9. Secure the heatsink:
- Hold the heatsink to prevent it from tilting, and tighten the screws.
10. Connect the fan cable(s) to the header(s) on the motherboard.
11. Secure the excess cable with a tie-wrap to ensure that the cable does not
interfere with fan operation or make contact with other components.
12. Replace the front panel.
13. Replace the left side cover.
Caution
Caution
See "Replacing the Front Panel" on page 212.
See "Replacing the Left Side Cover" on page 210.
