- Page 1 WIRELESS LAN USB 2.0 ADAPTER USER´s GUIDE (DN-70031)
- Page 2 © All rights reserved. All trade names are registered trademarks of respective manufacturers listed. This manual may not be copied in any media or form without the written consent of original maker.
-
Page 3: Table Of Contents
Information To User ..........……..i 1. Introduction ............…… 1 2. Wireless LAN Basics ..........……. 3 3. IP ADDRESS ............……. 4 4. Install Driver/Utility ..........……. 5 5. Wireless Network Configuration ........……… 8 5.1 Utility Icon ............8 5.2 Client Mode (Default Setting)........9 5.3 AP and Wizard Setup.......... -
Page 4: Information To User
INFORMATION TO USER Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 5 REGULATORY INFORMATION WLAN 11b/g Adapter must be installed and used in strict accordance with the instructions. This device complies with the following radio frequency and safety standards. USA - Federal Communications Commission (FCC) This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: 1.
- Page 6 EU Countries Not intended for use None. Potential restrictive use France: Only channels 10,11,12, and 13 The channel identifiers, channel center frequencies, and regulatory domains of each 22-MHz-wide channel are shown in following Table. Channel Center Regulatory Domains Identifier Frequency North Japan ETSI...
- Page 7 Thank you for your purchase of the WLAN Mini USB Adapter. Featuring wireless technology, this wireless networking solution has been designed for both large and small businesses, and it is scalable so that you can easily add more users and new network features depending on your business scale.
-
Page 8: Install Driver/Utility
BEFORE YOU START 1. Confirm Box Contents CONNECTING YOUR WLAN USB ADAPTER TO PC Quick Start Guide Connect your WLAN USB dongle to your PC. Install driver. GETTING TO KNOW WIRELESS LAN USB ADAPTER LED turns on when POWER is applied to the WLAN Mini USB Adapter. LED is blinking when PC is sending data through WLAN Mini USB Adapter. -
Page 9: Infrastructure Wireless Lan
Wireless LAN network defined by IEEE 802.11b/g standard committee could be configured as : Ad Hoc wireless LAN. Infrastructure wireless LAN. Ad Hoc network is a group of PCs installed with wireless LAN cards, this group of PCs is called a BSS (Basic Service Set). PCs in this group can use their wireless LAN cards to communicate with each other, but can not connect to the Internet. - Page 10 To use the WLAN Mini USB Adapter with a computing device, the WLAN Mini USB Adapter must be equipped with an USB 2.0 Interface. All drivers and supporting software for the WLAN Mini USB Adapter must be installed and configured first. Ask your system administrator for the following information, which you may need to provide during driver installation : Your Wireless Client Name.
- Page 11 The installation & driver CD will automatically activate the autorun installation program after you insert the disk into your CD drive. Step 1 : Insert the installation & driver CD into your CD-ROM. Installation program will prompt language setup. Pickup the Setup Language you would like to use and click Next...
- Page 12 Step 4 : Click Finish to complete installation. Driver Setup without WHQL ( Optional ) Chipset vendor may provide the driver without WHQL. Please refer the following steps to setup. Step 1 : Plug the USB adapter into the USB port of your PC. Choose “No, not this time”.
- Page 13 Step 3 : Windows will detect USB device and copy driver to windows system. Step 4 : Windows will install USB driver to system folder and click Finish complete installation..
-
Page 14: Utility Icon
WLAN USB Adapter uses its own management software. All functions controlled by users are provided by this application. When you insert the WLAN USB Adapter into the USB port of your PC, a new icon should appear in the Windows System Tray automatically 5.1 Utility Icon ... - Page 15 5.2.1 GENERAL SETTING Once USB device is plugged, double click on that icon and the configuration window will pop up as shown. It shows the current connected network. The signal strength and link quality are displayed also. The bar graph displays the quality and strength of the link between the node and its Access Point.
- Page 16 5.2.3 AVAILABLE NETWOEK SETTING Click Available Network tab and it will show all available networks that radio can reaches. Select proper SSID & BSSID you want to connect. Click Refresh button to force and rescan available networks currently. Select one of SSIDs, and click Add to Profile to create profile that can...
- Page 17 Threshold. Once you change the value, click Apply button to save them. Also click Set Default button to apply them to default value. PS. Strongly recommend be careful to change Fragment, RTS Threshold if you’re not have wireless knowledge background. 5.2.5 Status Status page tab, shows all wireless, networking...
-
Page 18: Ap And Wizard Setup
5.3 AP and Wizard Setup 5.3.1 Wizard-1 Click Set Wizard menu to enter operation wizard. Click AP: Setup Access Point wireless network to configure Access Point parameters. Next to continue. Cancel to leave wizard page. 5.3.2 Wizard-2 Pick up Normal User (minimum settings) or Advanced User (minimum and wireless... - Page 19 users. Take WPA2-PSK/TKIP for example. Back to go previous. Next to continue. Cancel to close wizard. 5.3.4 Wizard-4 This page sets PASSPHRASE network key Security settings Back to go previous Next to continue. Cancel to close wizard. 5.3.5 Wizard-5 This page shows the settings.
-
Page 20: Ap Mode
5.3.5 Wizard-6 Select device that connects with internet. Back to go previous. Next to continue. Cancel to close wizard. 5.3.5 Wizard-7 Show all settings under AP mode. Click Finish to complete wizard setup. 5.4 AP Mode There are General, Advanced, Statistics and SoftAP pages to do configure SSID, channel, advanced wireless... - Page 21 Product Name Wireless LAN 11g USB Adapter Chipset RTL8187B Standard IEEE 802.11b, IEEE 802.11g Frequency Band 2.4GHz ~ 2.484GHz unlicensed ISM band IEEE 802.11b : DSSS Spread Spectrum IEEE 802.11g : OFDM IEEE 802.11b : DBPSK / DQPSK / CCK Modulation IEEE 802.11g : BPSK, QPSK, 16QAM, 64QAM IEEE 802.11b : 1, 2, 5.5, 11Mbps...
- Page 22 Symptom : The LED is off. Remedy : Make sure the PC Card is inserted properly. Otherwise contact your vendor. Symptom : The LED is always on not blinking. Remedy : Make sure that you have installed the driver from attached CD. Otherwise contact your vendor.
- Page 23 IEEE 802.11 Standard The IEEE 802.11 Wireless LAN standards subcommittee, which is formulating a standard for the industry. Access Point An internetworking device that seamlessly connects wired and wireless networks together. Ad Hoc An Ad Hoc wireless LAN is a group of computers, each with a WLAN adapter, connected as an independent wireless LAN.
- Page 24 Gateway A gateway is a hardware and software device that connects two dissimilar systems, such as a LAN and a mainframe. In Internet terminology, a gateway is another name for a router. Generally a gateway is used as a funnel for all traffic to the Internet.
- Page 25 with Static IP address, the network administrator manually assigns an IP address to each computer. Once a Static IP address is assigned, a computer uses the same IP address every time it reboots and logs on to the network, unless it is manually changed. Temporal Key Integrity Protocol (TKIP) The Temporal Key Integrity Protocol, pronounced tee-kip, is part of the IEEE 802.11i encryption standard for wireless LANs.
- Page 26 WEP’s problems are well-known, including an insufficient key length and no automated method for distributing the keys. WEP can be easily cracked in a couple of hours with off-the-shelf tools. Wireless LAN (WLAN) A wireless LAN does not use cable to transmit signals, but rather uses radio or infrared to transmit packets through the air.
- Page 27 have a different RTS threshold. RTS/CTS is used when the data packet size exceeds the defined RTS threshold. With the CSMA/CA transmission mechanism, the transmitting station sends out an RTS packet to the receiving station, and waits for the receiving station to send back a CTS (Clear to Send) packet before sending the actual packet data.
- Page 28 LANs. TKIP provides per-packet key mixing, a message integrity check and a re-keying mechanism, thus fixing the flaws of WEP. 802.1x Authentication 802.1x is a framework for authenticated MAC-level access control, defines Extensible Authentication Protocol (EAP) over LANs (WAPOL). The standard encapsulates and leverages much of EAP, which was defined for dial-up authentication with Point-to-Point Protocol in RFC 2284.
