TPA-MHL-8R - Quick Start Guide
3.5
HDCP compliance testing for source devices
You can run HDCP compliance tests on MHL source devices in accordance with the
HDCP 1.2 Compliance Test Specification. This test requires TPA-MHL-8R and 882EA
with HDCP compliance test option.
For more details on the HDCP source compliance test feature of the User Guide for the
882EA Video Test Instrument available on the Quantum Data 882E product web page
at: www.quantumdata.com/products/882E.asp.
Source
MHL DUT
MHL Cable
HDMI Cable
Page 18
TPA-MHL-8R
EST
August 31, 2011
68-00224 - Rev. A4
882EA
