Designing Touch Panel Pages
Use the PROPERTIES operation bar to assign properties to external pushbuttons. The BUTTON
options and VARIABLE TEXT features within the Properties page do not appear. Although the
Border and Color sections of this page appear, they are of no use to external pushbuttons since they
do not appear on-screen.

Creating a Bargraph and Joystick

Bargraphs are level monitors and adjustable level controls. These levels can be configured to adjust
and monitor audio outputs and lighting levels. Before starting, make sure to connect the touch panel
to your Controller; otherwise, the bargraph may not work properly.
Bargraphs and Joysticks only function on VPN-CP touch panels.
Joysticks are vertical and horizontal direction controllers you can use for camera for pan and tilt
control.

Adding a bargraph or joystick button

Create a new button using the ADD operation bar in the BUTTON menu.
1. Press BUTTON in the Edit bar to open the BUTTON menu.
2. Press PROPERTIES in the BUTTON menu to open the PROPERTIES operation bar.
3. Press any button to open the Button Properties page.
4. Press BUTTON TYPE to open the BUTTON TYPE menus. Choose a button type to open its
Button Properties page.

Setting Bargraph and Joystick Properties

Use the Button Properties page to set channel, level, and button colors. Refer to Setting the variable
text code section on page 10 and Setting the channel code section on page 9 for further information.
Refer to Setting the button colors for channel-off conditions section on page 10for more
information on colors for channel-off conditions.
You are able to position the joystick crosshair in the Button Properties page.

Setting the level code

Level buttons set the device and number codes for the touch panels.
Joysticks use two level numbers. The first is for the X-axis and the second is for the
Y-axis. You only need to specify the first level.
1. Press DEV to open a keypad and set the device number.
2. Enter 1, 2, 3, or 4 in the keypad.
3. Press ENTER to save the device number, close the keypad, and return to the Button Properties
page.
4. Press NUM to open a keypad and set the level number assigned to the device.
12 ViewPoint Wireless Touch Panels
