2. Perform steps 7 through 9 under Capturing IR Functions – Standard Capture Mode three times,
or until the SEND LED lights to capture the HC function.
3. Press and release the UP and SEND pushbuttons at the same time to reset the IRIS unit to
default mode. The message nO (normal operation) briefly appears in the display to indicate
that the IRIS has returned to Standard Capture (or Verify) mode.

Capturing difficult functions using P5-P7 modes

If you cannot capture an HC function in the Standard Capture or Special modes, set the IRIS unit to
the P5–P7 modes:
1. Press and release the UP, DOWN, and SEND pushbuttons at the same time. The message P1
appears in the display. The IRIS unit is now in P mode.
2. Use the UP or DOWN pushbutton to select the appropriate P modes according to the
descriptions in the IRIS Display Characters and P3 - P7 Modes Settings table. Each P mode
setting toggles on and off. The display will show an On or Off message indicating the current P
mode setting. You can activate multiple P modes to capture an HC function.
3. Press and release the UP, DOWN, and SEND pushbuttons at the same time to toggle the
selected P mode to ON. The P modes are now set in the IRIS unit
4. Perform steps 7 through 9 under Capturing IR functions – Standard Capture mode three times.
IRIS display characters and P1–P7 mode settings
The following table lists the display characters and P1–P7 mode settings for special hand
controllers.
IRIS Display Characters and P3 - P7 Modes Settings
[]
Er
Nd
nO
OF
On
So
SP
P1-P2
P3
P4
P5
P6
P7
ViewPoint Wireless Touch Panels
HC function is captured, analyzed, stored, and verified.
Error: HC function did not verify correctly.
No Device. Communication device error detected, or the IRLIB program is not staged to receive
HC functions.
Normal Operation. Ready to capture HC.
P mode is off.
P mode is on.
Send OK. HC function sent without errors to a PC running IRLIB.
Special Function. Special mode to capture unusual HC functions.
Not used.
Send HC functions to a PC running IRLIB automatically after the VERIFY operation.
Disable the VERIFY operation to capture HC functions. Standard Capture mode requires the
VERIFY operation. Set this mode to ON when capturing, set it to OFF when verifying or identify-
ing IR functions.
Loose-timing mode to capture JVC (PQ10956) HC functions.
Glitch-detection mode to capture Kinderman and some Mitsubishi HC functions.
Disable glitch-detection mode to capture non-carrier HC functions.
