SECTION 7
7-1 IC-M601
[CHASSIS PARTS]
REF. ORDER
NO. NO.
J1 6510004880 Antenna connector MR-DS-E 01
W1 8900011450 Cable OPC-1175
W2 8900011460 Cable OPC-1176
MP1 8010019070 2577 chassis
MP2 8210019050 2577 rear panel
MP3 8930058270 2577 F-packing
MP4 8930058260 2577 R-packing
MP5 8930058460 2577 bush plate
MP6 8110007800 2577 module cover
MP7 8930058480 2577 module plate
MP8 8510014900 2577 shield cover
MP9 8930034300 1542 ANT seal
MP10 8930058780 2577 sheet
Screw PH BT M3 × 8 NI-ZU
MP11 8810008660
Screw PH BT M3 × 8 NI-ZU
MP12 8810008660
MP13 8820001210 2438 screw
MP14 8820001210 2438 screw
MP15 8820001210 2438 screw
MP16 8820001210 2438 screw
Screw PH M3 × 10 ZK
MP17 8810004300
MP18 8830001400 Sonic lock SL-M5-5.8 NI
MP19 8930052290 O ring (AD)
MP20 8930058450 2577 IC clip
MP21 8930058470 2577 IC plate
MP22 8930049040 Insulation plate
MP23 8930055040 2438 cap
MP25 8930059020 Thermally sheet (AI)
Screw PH BT M3 × 8 NI-ZU
MP26 8810008660
[MAIN UNIT]
REF. ORDER
NO. NO.
W12 7030010860 Jumper MJP-0.6
EP3 6910002160 Shield case BM7
MP1 8510014870 2577 RX-VCO case
MP2 8510014880 2577 TX-VCO case
MP3 8510014890 2577 DBM case
MP4 8510014890 2577 DBM case
MP5 8510015100 2577 shield case
MP6 8930059350 2577 earth plate
MP7 8930014140 Earth spring (D)
MP8 8930005320 Filter spacer
[LOGIC BOARD]
REF. ORDER
NO. NO.
S1 2230000250 Switch SPPH22014A
BT1 3020000110 Battery CR2032
DS1 5030002390 LCD HLM7784-010100
MP1 8930058440 2577 LCD holder
MP2 8210019060 2577 reflector
MP3 8930058910 2577 LCD sheet
Screw abbreviations BT: Self-tapping PH: Pan head
ZK: Black
SUS: Stainless
Accessories illustration is shown at the next page.
MECHANICAL PARTS AND DISASSEMBLY
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
NI: Nickel
NI-ZU: Nickel-Zinc

[FRONT UNIT]

REF. ORDER
NO. NO.
1 W1 8900011470
1 SP1 2510001210
1
MP1 8210019300
1 MP2 8930059450
1 MP3 8310054590
1 MP5 8930059440
1 MP8 8930052030
1 MP9 8930052010
1 MP10 8930052020
1 MP11 8110007160
1 MP12 8610011240
1 MP13 8610011240
1 MP14 8610011210
7 MP15 8830001350
3 MP17 8810008660
6 MP18 8930059200
6 MP19 8930053030
2 MP20 8930058900
2 MP21 8850001980
2 MP22 8930052280
2 MP23 8930058790
8
1
[CONNECT-A UNIT]
1
1
REF. ORDER
4 NO. NO.
1
J1 6510022440
1
J2 6510022440
J3 6510023320
[DIAL BOARD]
REF. ORDER
NO. NO.
1
S1 2250000470
1
[SQL BOARD]
1
REF. ORDER
1
NO. NO.
1
1 R1 7210002360
1
[VR BOARD]
1
1
REF. ORDER
1
NO. NO.
R1 7210003080
[ACCESSORIES]
REF. ORDER
1
NO. NO.
1 W1 8900011440
W2 8900010760
1
P1 5610000330
1 P2 6510023300
1
1 MC1 0800006850
MP1 8950005110
MP2 8610010561
MP3 8010018860
MP5 8810001490
MP6 8850000500
MP7 8850000180
MP8 8810004700
MP9 8930059480
7 - 1
DESCRIPTION
Cable OPC-1177
Speaker 066P0804
2577 front panel (B)
2577 2-key (A)
2577 windows plate (B)
2577 18-key (A)
2345 spring
2345 shaft
2345 shaft angle
2345 cover
Knob N295
Knob N295
Knob N293
Sonic lock SL-M3-5.8
Screw PH BT M3 × 8 NI-ZU
O ring (AT)
2345 earth plate
Rubber sheet (BB)
Flat washer M10
O ring (AC)
2577 SP net
DESCRIPTION
Connector LTW-8MP-C
Connector LTW-8MP-C
Connector LTWD-06PMMP-LC
DESCRIPTION
Switch EVQ-V9C00116E
DESCRIPTION
Variable resistor TP96N97-15F-10KA-1301
DESCRIPTION
Variable resistor TP96N97-15F-10KA-2345
DESCRIPTION
Cable OPC-1174
Cable OPC-1096 [EUR],[HOL],[FRG]only
LTWBU-10BFFA-L180
LTWB-03BFFA-L180
HM-137B
2289 mic hanger
2040 knob bolt-1
2455 bracket
Screw PH A M5 × 20 SUS
Spring washer M5 SUS
Flat washer M5 SUS
Screw PH A M3 × 16 SUS
Sponge (GZ)
QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
6
7
1
1
2
1
2
1
QTY.
1
1
1
QTY.
1
QTY.
1
QTY.
1
QTY.
1
1
1
1
1
1
2
1
4
4
4
2
2
