Icom IC-M601 Service Manual page 30

6-3 HM-134 (OPTIONAL MICROPHONE)
[CHASSIS UNIT]
REF ORDER
NO. NO.
R1 7070000860 RESISTOR
SP1 2510001091 SPEAKER
W3 8900010970 CABLE
EP1 6950000390 COVER
[MAIN UNIT]
REF ORDER
NO. NO.
IC1 1140009390 S.IC
IC2 1110005560 IC
IC3 1110004490 S.IC
IC4 1120002830 S.IC
IC5 1180000420 S.IC
IC7 1110005730 S.IC
IC8 1130007420 S.IC
IC9 1130006220 S.IC
IC10 1130004200 S.IC
Q1 1560000810 S.FET
Q2 1520000460 S.TRANSISTOR
Q3 1530002850 S.TRANSISTOR
Q5 1590000430 S.TRANSISTOR
Q6 1590000980 S.TRANSISTOR
Q9 1560000810 S.FET
Q10 1530002060 S.TRANSISTOR
Q11 1510000510 S.TRANSISTOR
Q12 1530002850 S.TRANSISTOR
Q13 1530002850 S.TRANSISTOR
D1 1750000130 S.DIODE
D2 1750000550 S.DIODE
X1 6060000750 S.CERAMIC
R1 7030000280 S.RESISTOR
R2 7030000280 S.RESISTOR
R3 7030000280 S.RESISTOR
R6 7030003560 S.RESISTOR
R7 7030003560 S.RESISTOR
R8 7030003560 S.RESISTOR
R9 7030003560 S.RESISTOR
R10 7030003680 S.RESISTOR
R11 7030003680 S.RESISTOR
R12 7030003680 S.RESISTOR
R13 7030003680 S.RESISTOR
R14 7030003680 S.RESISTOR
R15 7030003680 S.RESISTOR
R16 7030003680 S.RESISTOR
R17 7030003680 S.RESISTOR
R18 7030003680 S.RESISTOR
R19 7030003800 S.RESISTOR
R20 7030003540 S.RESISTOR
R21 7030003630 S.RESISTOR
R22 7030004120 S.RESISTOR
R23 7030003560 S.RESISTOR
R24 7030003450 S.RESISTOR
R25 7030003560 S.RESISTOR
R26 7510001670 S.THERMISTOR
R27 7030003560 S.RESISTOR
R28 7030004120 S.RESISTOR
R29 7030003560 S.RESISTOR
R30 7030004120 S.RESISTOR
R31 7030003560 S.RESISTOR
R32 7030004120 S.RESISTOR
DESCRIPTION
ERG2SJ 150
036D0801A
OPC-1118
VCP-10
DESCRIPTION
µPD789405AGK-A30-9EU
TA8201AK
M62429FP 700C
NJM2125F-TE1
TA78L05F (TE12R)
S-80928CNMC-G8Y-T2
TC7W14FU (TE12L)
TC4W53FU (TE12L)
TC4S66F (TE85R)
2SK1069-4-TL
2SB1132 T100 R
2SC4116-BL (TE85R)
DTC144EUA T106
DTB123EK T147
2SK1069-4-TL
2SC4081 T106 R
2SA1576A T106R
2SC4116-BL (TE85R)
2SC4116-BL (TE85R)
DA204U T106
1SS355 TE-17
CSTCC4.91MG
MCR10EZHJ 150 Ω (151)
MCR10EZHJ 150 Ω (151)
MCR10EZHJ 150 Ω (151)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 203 V (20 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
NTCG16 4BH 103KT
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 203 V (20 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 203 V (20 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 203 V (20 kΩ)
[MAIN UNIT]
REF ORDER
NO. NO.
R33 7030004120 S.RESISTOR
R34 7030003440 S.RESISTOR
R35 7030003440 S.RESISTOR
R36 7030003520 S.RESISTOR
R37 7030003560 S.RESISTOR
R38 7030003580 S.RESISTOR
R42 7030003570 S.RESISTOR
R43 7030003490 S.RESISTOR
R44 7030003680 S.RESISTOR
R45 7030003680 S.RESISTOR
R46 7030003620 S.RESISTOR
R47 7030003760 S.RESISTOR
R50 7030003680 S.RESISTOR
R53 7030003680 S.RESISTOR
R54 7030003440 S.RESISTOR
R55 7030003640 S.RESISTOR
R56 7030003440 S.RESISTOR
R57 7030003520 S.RESISTOR
R58 7030003280 S.RESISTOR
R61 7030003440 S.RESISTOR
R63 7030003550 S.RESISTOR
R64 7030003560 S.RESISTOR
R65 7030003800 S.RESISTOR
R66 7030003800 S.RESISTOR
R67 7030003800 S.RESISTOR
R70 7030003260 S.RESISTOR
R71 7030003400 S.RESISTOR
R72 7030000060 S.RESISTOR
R73 7030000060 S.RESISTOR
R75 7030003800 S.RESISTOR
R76 7030003640 S.RESISTOR
R77 7030003680 S.RESISTOR
R78 7030003440 S.RESISTOR
R79 7030003800 S.RESISTOR
C1 4510004630 S.ELECTROLYTIC
C3 4510005430 S.ELECTROLYTIC
C4 4030006900 S.CERAMIC
C5 4030006900 S.CERAMIC
C6 4030006900 S.CERAMIC
C7 4030011600 S.CERAMIC
C9 4030006900 S.CERAMIC
C10 4030012600 S.CERAMIC
C14 4030011600 S.CERAMIC
C15 4510006670 S.ELECTROLYTIC
C22 4030006900 S.CERAMIC
C23 4510005430 S.ELECTROLYTIC
C24 4030012600 S.CERAMIC
C26 4030012600 S.CERAMIC
C27 4030006850 S.CERAMIC
C28 4030011600 S.CERAMIC
C29 4030006860 S.CERAMIC
C30 4510004630 S.ELECTROLYTIC
C31 4030011810 S.CERAMIC
C32 4030007090 S.CERAMIC
C33 4030012600 S.CERAMIC
C34 4030011600 S.CERAMIC
C35 4510005430 S.ELECTROLYTIC
C36 4030011600 S.CERAMIC
C37 4510005430 S.ELECTROLYTIC
C42 4030008890 S.CERAMIC
C44 4030011600 S.CERAMIC
C45 4030006900 S.CERAMIC
C46 4030011600 S.CERAMIC
C47 4030006850 S.CERAMIC
C50 4030006860 S.CERAMIC
C53 4030006900 S.CERAMIC
C54 4030012600 S.CERAMIC
C56 4030006860 S.CERAMIC
C58 4030011600 S.CERAMIC
C59 4030006860 S.CERAMIC
C60 4030006860 S.CERAMIC
C61 4030011600 S.CERAMIC
C64 4030007090 S.CERAMIC
C65 4030007090 S.CERAMIC
C66 4030007090 S.CERAMIC
C67 4030007090 S.CERAMIC
C68 4030007090 S.CERAMIC
C69 4030007090 S.CERAMIC
C70 4030007090 S.CERAMIC
C71 4030007090 S.CERAMIC
6 - 11
DESCRIPTION
ERJ3GEYJ 203 V (20 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 330 V (33 Ω)
ERJ3GEYJ 471 V (470 Ω)
MCR10EZHJ 2.2 Ω (2R2)
MCR10EZHJ 2.2 Ω (2R2)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ECEV1CA100SR
ECEV0JA220SR
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1H 103K-T-A
C2012 JB 1A 105M-T-A
C1608 JB 1E 104K-T-N
ECEV1CA471P
C1608 JB 1H 103K-T-A
ECEV0JA220SR
C2012 JB 1A 105M-T-A
C2012 JB 1A 105M-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1H 102K-T-A
ECEV1CA100SR
C1608 JB 1A 224K-T-N
C1608 CH 1H 470J-T-A
C2012 JB 1A 105M-T-A
C1608 JB 1E 104K-T-N
ECEV0JA220SR
C1608 JB 1E 104K-T-N
ECEV0JA220SR
C1608 JB 1H 273K-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1H 103K-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1H 471K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 103K-T-A
C2012 JB 1A 105M-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1E 104K-T-N
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
S.=Surface mount
