Icom IC-M601 Service Manual page 29

[MAIN UNIT]
REF ORDER
NO. NO.
C370 4030006860 S.CERAMIC
C371 4030006860 S.CERAMIC
C372 4550006130 S.TANTALUM
C373 4030011600 S.CERAMIC
C374 4030006860 S.CERAMIC
C375 4030007050 S.CERAMIC
C376 4030006860 S.CERAMIC
C377 4030006860 S.CERAMIC
C378 4550006700 S.TANTALUM
C379 4030006860 S.CERAMIC
C381 4030006860 S.CERAMIC
C383 4030006900 S.CERAMIC
C385 4030006860 S.CERAMIC
C386 4030006900 S.CERAMIC
C391 4550006650 S.TANTALUM
C392 4030006860 S.CERAMIC
C393 4030006850 S.CERAMIC
C397 4030006860 S.CERAMIC
C398 4030006850 S.CERAMIC
C399 4030006860 S.CERAMIC
C400 4030009520 S.CERAMIC
C401 4030007170 S.CERAMIC
C402 4030006850 S.CERAMIC
C403 4030006860 S.CERAMIC
C404 4030011600 S.CERAMIC
C405 4030006850 S.CERAMIC
C406 4030011600 S.CERAMIC
C407 4030009920 S.CERAMIC
C408 4030011770 S.CERAMIC
C409 4030006860 S.CERAMIC
C410 4030009540 S.CERAMIC
C411 4030009510 S.CERAMIC
C412 4030006990 S.CERAMIC
C413 4030009350 S.CERAMIC
C414 4030009560 S.CERAMIC
C415 4030009560 S.CERAMIC
C416 4030006990 S.CERAMIC
C417 4030009350 S.CERAMIC
C418 4030009510 S.CERAMIC
C419 4030009540 S.CERAMIC
C420 4030007020 S.CERAMIC
C421 4030009530 S.CERAMIC
C423 4030007100 S.CERAMIC
C427 4030006860 S.CERAMIC
C428 4030006860 S.CERAMIC
C431 4030006860 S.CERAMIC
C432 4030006860 S.CERAMIC
C433 4030006860 S.CERAMIC
C434 4030006860 S.CERAMIC
C435 4030006860 S.CERAMIC
C436 4030006850 S.CERAMIC
C437 4030006860 S.CERAMIC
C438 4030006850 S.CERAMIC
C439 4030006860 S.CERAMIC
C440 4030006860 S.CERAMIC
C441 4030006860 S.CERAMIC
J1 6510023360 S.CONNECTOR 26FLT-SM1-TB
J2 6510022620 S.CONNECTOR 10FMN-BMTTR-A-TBT
J3 6510007020 CONNECTOR
W1 7030003860 S.JUMPER
W2 7030003860 S.JUMPER
W3 7030003860 S.JUMPER
W4 7030003860 S.JUMPER
W5 7030003860 S.JUMPER
W6 7030003860 S.JUMPER
W7 7030010840 S.JUMPER
W8 7030010850 S.JUMPER
W9 7030010850 S.JUMPER
W10 7030010850 S.JUMPER
W11 7030010850 S.JUMPER
W12 7030010860 JUMPER
EP1 0910056045 PCB
EP2 6910013370 S.BEAD
EP3 6910002160 CASE
DESCRIPTION
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
ECST1VY224R
C1608 JB 1E 104K-T
C1608 JB 1H 102K-T
C1608 CH 1H 220J-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
ECST1AY106R
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 103K-T
C1608 JB 1H 102K-T
C1608 JB 1H 103K-T
ECST1CY685R
C1608 JB 1H 102K-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
C1608 CH 1H 020B-T
C1608 CH 1H 221J-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
C1608 JB 1E 104K-T
C1608 JB 1H 471K-T
C1608 JB 1E 104K-T
C1608 CH 1H 050B-T
C1608 CH 1H 060B-T
C1608 JB 1H 102K-T
C1608 CH 1H 1R5B-T
C1608 CH 1H 010B-T
C1608 CH 1H 080D-T
C1608 CH 1H 3R5B-T
C1608 CH 1H R75B-T
C1608 CH 1H R75B-T
C1608 CH 1H 080D-T
C1608 CH 1H 3R5B-T
C1608 CH 1H 010B-T
C1608 CH 1H 1R5B-T
C1608 CH 1H 120J-T
C1608 CH 1H 030B-T
C1608 CH 1H 560J-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
TMP-J01X-V6
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
MJP-0.2-T
MCR100JZHJ JPW
MCR100JZHJ JPW
MCR100JZHJ JPW
MCR100JZHJ JPW
MJP-0.6
B 5879E
BLM18BB221SN1D
BM7
6-2 HM-137
[MAIN UNIT]
REF ORDER
NO. NO.
R1 7010006890 RESISTOR
R2 7010006880 RESISTOR
R3 7010006900 RESISTOR
R4 7010006910 RESISTOR
R5 7070001150 RESISTOR
C1 4010007711 CERAMIC
C2 4030017280 S.CERAMIC
J1 6510022450 CONNECTOR
MC1 7700002120 MICROPHONE
S1 2260002330 SWITCH
S2 2260002340 SWITCH
S3 2260002340 SWITCH
S4 2260002340 SWITCH
SP1 2510001092 SPEAKER
W1 9044902012 WIRE
W2 9044902012 WIRE
W3 9045995030 WIRE
W4 9045995030 WIRE
EP1 0910052553 PCB
EP2 9029701901 TUBE
6 - 10
DESCRIPTION
R20J 12 kΩ
R20J 6.8 kΩ
R20J 15 kΩ
R20J 33 kΩ
MOS2W-150-J <KN>
HE40SJ YB 471K 50V
C1608 CH 1H 471J-T-A <KN>
S07B-EH-S <KN>
KUC2123-030245
SKHHLP014A
SKHHAM024A
SKHHAM024A
SKHHAM024A
S36D0801B <KN>
71/98/010/X98/X98
71/98/010/X98/X98
71/98/020/X98/X98
71/98/020/X98/X98
B 5431C
IRRAX 0.7 (d) L=4 mm
S.=Surface mount
