Icom IC-M601 Service Manual page 26

[MAIN UNIT]
REF ORDER
NO. NO.
L57 6200010510 S.COIL
L61 6200003100 S.COIL
L62 6130002370 S.COIL
L63 6200002990 S.COIL
L64 6200009560 S.COIL
L65 6200009560 S.COIL
L66 6200006990 S.COIL
L67 6200009560 S.COIL
L68 6200001980 S.COIL
L69 6200001980 S.COIL
L70 6200006990 S.COIL
L72 6200003320 S.COIL
L73 6130002370 S.COIL
L74 6200003090 S.COIL
L75 6200009560 S.COIL
L79 6200003280 S.COIL
L81 6200009560 S.COIL
L83 6200009560 S.COIL
L84 6200005740 S.COIL
L85 6200002430 S.COIL
L86 6200002430 S.COIL
L87 6200002600 S.COIL
L88 6200002600 S.COIL
L89 6110001600 COIL
L90 6170000230 COIL
L91 6200008950 S.COIL
R1 7030003670 S.RESISTOR
R4 7030003480 S.RESISTOR
R6 7030003480 S.RESISTOR
R11 7030003620 S.RESISTOR
R12 7030003680 S.RESISTOR
R13 7030003600 S.RESISTOR
R14 7030003560 S.RESISTOR
R15 7030003640 S.RESISTOR
R16 7030003440 S.RESISTOR
R17 7030004050 S.RESISTOR
R18 7030003320 S.RESISTOR
R19 7030003320 S.RESISTOR
R31 7030003450 S.RESISTOR
R32 7030003400 S.RESISTOR
R33 7030003200 S.RESISTOR
R34 7030003400 S.RESISTOR
R37 7030003240 S.RESISTOR
R38 7030003500 S.RESISTOR
R39 7030003200 S.RESISTOR
R40 7030003400 S.RESISTOR
R41 7030003450 S.RESISTOR
R43 7030003390 S.RESISTOR
R47 7030003480 S.RESISTOR
R48 7030003740 S.RESISTOR
R49 7030003620 S.RESISTOR
R50 7030003610 S.RESISTOR
R51 7030003430 S.RESISTOR
R53 7030003200 S.RESISTOR
R59 7030003440 S.RESISTOR
R61 7030003560 S.RESISTOR
R62 7030003560 S.RESISTOR
R63 7030003560 S.RESISTOR
R64 7030003440 S.RESISTOR
R65 7030003560 S.RESISTOR
R66 7030003440 S.RESISTOR
R71 7030003280 S.RESISTOR
R72 7030003680 S.RESISTOR
R73 7030003680 S.RESISTOR
R74 7030003560 S.RESISTOR
R75 7030003560 S.RESISTOR
R76 7030003560 S.RESISTOR
R77 7030003560 S.RESISTOR
R78 7030003550 S.RESISTOR
R79 7030003460 S.RESISTOR
R80 7030003760 S.RESISTOR
R81 7030003760 S.RESISTOR
R84 7030003760 S.RESISTOR
R85 7030003640 S.RESISTOR
R86 7030003280 S.RESISTOR
R87 7030003380 S.RESISTOR
DESCRIPTION
ACL2520L-3R3K-T
NL 322522T-3R9J-3
LB-258
NL 322522T-2R2J-3
MLG1608B R10J-T
MLG1608B R10J-T
ELJRE 56NG-F
MLG1608B R10J-T
NL 252018T-1R0J
NL 252018T-1R0J
ELJRE 56NG-F
NL 322522T-3R3J-3
LB-258
NL 322522T-2R7J-3
MLG1608B R10J-T
NL 252018T-2R2J
MLG1608B R10J-T
MLG1608B R10J-T
ELJRE 47NG-F
NL 252018T-082J
NL 252018T-082J
NL 252018T-047J
NL 252018T-047J
LA-243
LW-25
LQH32MN221K21L
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 1R0 V (1 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 220 V (22 Ω)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 334 V (330 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 273 V (27 kΩ)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 822 V (8.2 kΩ)
[HOL], [FRG] only
ERJ3GEYJ 152 V (1.5 kΩ)
[HOL], [FRG] only
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
[HOL], [FRG] only
ERJ3GEYJ 474 V (470 kΩ)
[HOL], [FRG] only
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 331 V (330 Ω)
[MAIN UNIT]
REF ORDER
NO. NO.
R88 7030003680 S.RESISTOR
R89 7030003630 S.RESISTOR
R90 7030003580 S.RESISTOR
R91 7030003480 S.RESISTOR
R95 7030003420 S.RESISTOR
R96 7030003680 S.RESISTOR
R97 7030003380 S.RESISTOR
R98 7030003500 S.RESISTOR
R104 7030003370 S.RESISTOR
R105 7030003230 S.RESISTOR
R106 7030003370 S.RESISTOR
R107 7030003240 S.RESISTOR
R108 7030003500 S.RESISTOR
R111 7030003400 S.RESISTOR
R112 7030003450 S.RESISTOR
R113 7030003390 S.RESISTOR
R116 7030003200 S.RESISTOR
R120 7030003450 S.RESISTOR
R121 7030003560 S.RESISTOR
R122 7030003680 S.RESISTOR
R123 7030003380 S.RESISTOR
R124 7030003500 S.RESISTOR
R142 7030003680 S.RESISTOR
R143 7030003680 S.RESISTOR
R144 7030003560 S.RESISTOR
R145 7030003560 S.RESISTOR
R146 7030003560 S.RESISTOR
R147 7030003560 S.RESISTOR
R148 7030003550 S.RESISTOR
R149 7030003460 S.RESISTOR
R150 7030003760 S.RESISTOR
R151 7030003760 S.RESISTOR
R154 7030003760 S.RESISTOR
R155 7030003640 S.RESISTOR
R157 7030003380 S.RESISTOR
R158 7030003680 S.RESISTOR
R159 7030003630 S.RESISTOR
R160 7030003580 S.RESISTOR
R161 7030003480 S.RESISTOR
R163 7030003680 S.RESISTOR
R181 7030003560 S.RESISTOR
R182 7030003440 S.RESISTOR
R185 7030003320 S.RESISTOR
R186 7030003450 S.RESISTOR
R188 7030003380 S.RESISTOR
R189 7030003520 S.RESISTOR
R190 7030003520 S.RESISTOR
R191 7030003320 S.RESISTOR
R192 7030003420 S.RESISTOR
R193 7030003660 S.RESISTOR
R194 7030003320 S.RESISTOR
R195 7030003300 S.RESISTOR
R196 7030003320 S.RESISTOR
R201 7030003420 S.RESISTOR
R202 7030003660 S.RESISTOR
R203 7030003320 S.RESISTOR
R204 7030003300 S.RESISTOR
R205 7030003320 S.RESISTOR
R207 7030003760 S.RESISTOR
R208 7030003640 S.RESISTOR
R209 7030003320 S.RESISTOR
R212 7030003680 S.RESISTOR
R213 7030003440 S.RESISTOR
R214 7030003610 S.RESISTOR
R217 7030003480 S.RESISTOR
R218 7030003500 S.RESISTOR
R219 7030003480 S.RESISTOR
R220 7030003260 S.RESISTOR
R221 7030003450 S.RESISTOR
R222 7030003760 S.RESISTOR
R226 7030003560 S.RESISTOR
R227 7030003640 S.RESISTOR
R228 7030003620 S.RESISTOR
R230 7030003450 S.RESISTOR
R232 7030003420 S.RESISTOR
R233 7030003660 S.RESISTOR
R236 7030001150 S.RESISTOR
R238 7030003440 S.RESISTOR
6 - 6
DESCRIPTION
ERJ3GEYJ 104 V (100 kΩ)
[HOL], [FRG] only
ERJ3GEYJ 393 V (39 kΩ)
[HOL], [FRG] only
ERJ3GEYJ 153 V (15 kΩ)
[HOL], [FRG] only
ERJ3GEYJ 222 V (2.2 kΩ)
[HOL], [FRG] only
ERJ3GEYJ 681 V (680 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 180 V (18 Ω)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 220 V (22 Ω)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 681 V (680 Ω)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 680 V (68 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 681 V (680 Ω)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 680 V (68 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 273 V (27 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 330 V (33 Ω)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 681 V (680 Ω)
ERJ3GEYJ 683 V (68 kΩ)
MCR50JZHJ 150 Ω (151)
ERJ3GEYJ 102 V (1 kΩ)
S.=Surface mount
