- Page 1 Version 1.0 5.25" Embedded Eden Little board with VIA Eden 533 MHz CPU, w/ (1) 168-Pin DIMM Slot For Up To 512MB SDRAM, w/Flat Panel / CRT VGA, Dual LAN, Audio, PC104+, 4 COM / 2 LPT, CFC 3302011 User’s Manual...
-
Page 2: Packing List
Trademark All trademarks are the property of their respective holders. Packing List Hardware 3302011 Single Board Computer ........ X 1 Cable Kit IDE Flat Cable (UltraDMA/33) ........X 1 FDD Cable ..............X 1 2 x COM / 1 x LPT Port DB9 / DB25 Cable ....X 2 Dual-USB Port Cable with Bracket...... -
Page 3: Table Of Contents
Install Board’s Software ............33 Install Ultra ATA IDE Driver ............33 Install VGA Driver ..............33 Install LAN Driver ..............33 Install Audio Driver ..............33 Link to < Website > Homepage ..........33 Browse this CD................. 33 3302011 User’s Manual... - Page 4 Appendix B. Flash the BIOS ........40 BIOS Auto Flash Tool ............... 40 Flash Method ................40 Appendix C. System Resources ......... 41 I/O Port Address Map............... 41 Memory Address Map .............. 42 System IRQ and DMA Resource..........43 Contact Information ........... 46 3302011 User’s Manual...
-
Page 5: Chapter 1. Introduction
Compact Low Profile Board Size 5.25” drive size meets the industrial standard EBX form factor. The onboard CPU and SDRAM also make 3302011 be the low profile solution for embedded compact applications. Advanced Embedded Computing Platform... -
Page 6: Specifications
Four USB ports with USB version 1.1 compliant Parallel Port Two bi-direction parallel port with SPP/ECP/EPP mode 1 x FDD port supports up to two FDD IrDA Port 1 x IrDA compliant Infrared interface supports SIR K/B & Mouse PS/2 keyboard and mouse ports 3302011 User’s Manual... -
Page 7: Solid State Disk Interface
Mic-out Expansive Interface PCI Bus One 32-bit/33 MHz PCI slot with 2 x bus master PCI via an additional riser card PC/104-plus One PC/104-plus interface with 32-bit PCI-based 120-pin PC/104-plus interface and 16-bit ISA-based 104-pin PC/104 interface 3302011 User’s Manual... - Page 8 Operating within 0 ~ 60 C (32 ~ 140 Storage within -20 ~ 85 C (-4 ~ 185 Ordering Code 3302011 With VIA Eden 533MHz CPU, SVGA. Audio, Dual LAN, CompactFlash, PC/104+ Interface and 4 COM Ports 3302011 User’s Manual...
-
Page 9: Component Placement
Component Placement System Memory VIA PN133T CompactFlash SSD Onboard 128/256 MB VIA8606 and 686B Type-II Socket LVDS/TTL Flat Panel 1 x 168-pin DIMM Slot CFC / MicroDrive VIA Eden CPU PC/104+ Interface 533 MHz @ 133 FSB 3302011 User’s Manual... - Page 10 Notes (This page left blank intentionally) 3302011 User’s Manual...
-
Page 11: Chapter 2. Hardware Setup
CPU and memory installation, fan, I/O and panel connections. Jumpers and Connectors Location JIO1 JIO2 JUSB1 JUSB2 JAUDIO CDIN CPUFAN DIMM1 JVGA JCVOLT JCSEL2 JCSEL1 JRTC FDD1 JLAN2 JLAN1 JFRNT JWDT JVLCD IDE2 IDE1 JPS2 JDOM SYSFAN RJ45-1 RJ45-2 JLCD JLVDS2 JLVDS1 3302011 User’s Manual... - Page 12 JVSAFE Flat Panel’s Power Safe Setting 2.7.2 JLAN1 Primary LAN Enable/Disable Setting JLAN2 Secondary LAN Enable/Disable Setting JCSEL1 COM2 RS-232/422/485 Mode Setting 2.10.1 JCSEL2 COM2 RS-232/422/485 Mode Setting 2.10.1 JCVOLT RS232 Serial Port +5/+12V Power Setting 2.10.2 3302011 User’s Manual...
- Page 13 10-pin Audio Port Standard CDIN 4-pin CD-in Interface Standard RJ45-1 10-pin Primary LAN Port Connector Standard RJ45-2 10-pin Secondary LAN Port Connector Standard PCI1 32-bit PCI Slot Standard PC104 104-pin PC/104 Connector Standard J12~15 120-pin PC/104-plus Connector Standard 3302011 User’s Manual...
-
Page 14: Cpu And Dram Setting
The board’s data of CMOS can be setting in BIOS. If the board refuses to boot due to inappropriate CMOS settings, here is how to proceed to clear (reset) the CMOS to its default values. Jumper: JRTC Type: onboard 3-pin header JRTC Mode Clear CMOS Normal Operation Default setting JRTC 3302011 User’s Manual... -
Page 15: Watchdog Timer Setting
Watchdog Timer Active NMI Reset Default setting JWDT SWDT Back-side Jumper: SWDT Type: onboard 4-button / 2-level DIP switch (backside) Timeout Value SWDT 1 Second 2 Seconds 10 Seconds 20 Seconds 110 Seconds 220 Seconds Default setting 3302011 User’s Manual... -
Page 16: Embedded Flash Disk
Embedded Flash Disk The board supports both IDE-based DiskOnModule and CompactFlash embedded Solid State Disk (SSD). JDOM Jumper: JDOM Type: onboard 2-pin header JDOM +5V on Pin-20 of IDE1 Disable Enable Default setting 3302011 User’s Manual... -
Page 17: Power And Fan Connectors
Yellow Ground Black Ground Black Connector: JPS Type: 3-pin ATX Function Connector Description Description Description 5V Standby Ground Power On Connector: SYSFAN, CPUFAN Type: 3-pin Fan Power Wafer Connector Pin Description Description Description Ground +12V Fan Control 3302011 User’s Manual... -
Page 18: Vga Interface
The board is integrated with VIA PN133T chipset’s built-in 4xAGP S3 Savage4 VGA accelerator with 3D/2D engine and 32 MB of video memory shared with system memory. JVGA Connector: JVGA Type: 16-pin header Description Description Green Blue Ground Ground Ground Ground Ground Data HSYNC VSYNC Clock 3302011 User’s Manual... - Page 19 LVDS-based LCD display. All of the digital video interfaces used BIOS selectable 8/16/32 MB of video memory shared with system memory. JVSAFE JLCD JLVDS2/1 JVLCD Jumper: JVLCD Type: onboard 3-pin (1 x 3) header JVLCD LCD Voltage Setting +3.3V Default setting 3302011 User’s Manual...
- Page 20 JVSAFE LCD Power Sequence Control Power Input Directly Power Sequence Control by Chipset (VIA VT8606) Default setting Connector: JLCD Type: onboard 50-pin (2 x 25) 2.0 pitch header Signal Signal +12V +12V (LCD) ENAVDD ENAVEE SHFCLK ENABKL 3302011 User’s Manual...
- Page 21 Connector: JLVDS1, JLVDS2 Type: onboard 20-pin (2 x 10) 2.0mm pitch header Signal Signal LCD_Vcc +12V TCLK- TCLK+ ENABKL 3302011 User’s Manual...
- Page 22 1024x768TFT 2 pixel/clk at 32Mhz 1280x1024 TFT 640x480 DSTN 800x600 DSTN 1024x768 DSTN 1024x768 TFT 1 pixel/clk at 65Mhz 640x480 TFT 800x600 TFT 1024x768 TFT 1280x1024 TFT 1400x1050 TFT 2 pixel/clk at 54Mhz 800x600 DSTN 1024x768 DSTN 1280x1024 DSTN 3302011 User’s Manual...
-
Page 23: Ethernet Interface
(power saving mode / wake-on-LAN) and advanced network management functions. RJ45-1/2 JLAN2 JLAN1 Connector: RJ45-1/2 Type: 10-pin header connector Description Description Ground Ground Jumper: JLAN1/2 Type: onboard 3-pin (1 x 3) header JLAN1/2 LAN Controller Switch Enable Disable Default setting 3302011 User’s Manual... -
Page 24: Audio Interface
Connector: JAUDIO Type: 10-pin header Description Description Line – Right Ground Line – Left Ground Line Out – Left Line Out – Right Ground Connector: CDIN Type: 4-pin header Description CD – Left Ground Ground CD – Right 3302011 User’s Manual... -
Page 25: Multiple I/O Port Configuration
Jumper: JCSEL2, JCSEL1 Type: onboard 6-, 12-pin header COM2 Mode JCSEL2 JCSEL1 RS-232 1-2/4-5/7-8/10-11 RS-422 2-3/5-6/8-9/11-12 RS-485 2-3/5-6/8-9/11-12 Default setting Connector: Pin11~20 on JIO1 Type: 10-pin header Pin RS232 RS422 RS485 Pin RS232 RS422 RS485 485- 485+ 15 Ground 3302011 User’s Manual... - Page 26 The board offers the +5V/+12V power pin on the onboard 4 serial ports. The power mode can be setting with jumper JCVOLT. JCVOLT Jumper: JCVLOT Type: onboard 24-pin header Port RS232 +12V COM1 1-2/13-14 14-15 COM2 4-5/16-17 17-18 COM3 7-8/19-20 20-21 COM4 9-10/22-23 10-11 23-24 Default setting 3302011 User’s Manual...
-
Page 27: Expansive Bus Interfaces
The onboard PC/104-plus interface includes 32-bit PCI-based 120-pin PC/104-plus interface and 16-bit ISA-based PC/104 interface. There is one set of bus master PCI signal is supported on the onboard PC/104-plus interface. More information about PC/104-plus interface is available at: http://www.pc104.org/ PC/104+ 3302011 User’s Manual... -
Page 28: Switches And Indicators
2.12 Switches and Indicators JFRNT Connector: JFRNT Type: onboard 14-pin header Function Signal Signal Function Vcc (+) (+) Vcc IDE LED Power Active Reset Reset Speaker Power PWRBT Button SPKIN 3302011 User’s Manual... -
Page 29: Chapter 3. Bios Setup
>Integrated Peripherals Set Supervisor Password >Power Management Setup Set User Password >PnP / PCI Configurations Save & Exit Setup >PC Health Status Exit Without Saving Esc : Quit : Select Item F10 : Save & Exit Setup 3302011 User’s Manual... -
Page 30: Flat Panel Type Setting
Disabled PCI#2 Access #1 Retry Disabled AGP Master 1 WS Write Disabled AGP Master 1 WS Read Disabled :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5 : Previous Value F6 : Fail-Safe Defaults F7 : Optimized Defaults 3302011 User’s Manual... - Page 31 1024x768TFT 2pixel/clk at 32Mhz 1280x1024 TFT 640x480 DSTN 800x600 DSTN 1024x768 DSTN 1024x768 TFT 1pixel/clk at 65Mhz 640x480 TFT 800x600 TFT 1024x768 TFT 1280x1024 TFT 1400x1050 TFT 2pixel/clk at 54Mhz 800x600 DSTN 1024x768 DSTN 1280x1024 DSTN Default Setting 3302011 User’s Manual...
- Page 32 Notes (This page left blank intentionally) 3302011 User’s Manual...
-
Page 33: Chapter 4. Driver Installation
The selection helps you to install the driver of onboard audio interface. Link to < Website > Homepage The selection help you to link to the website to find the updated technical documents and download directly. Manual View 3302011 Manual in PDF format. 3302011 User’s Manual... - Page 34 Notes (This page left blank intentionally) 3302011 User’s Manual...
-
Page 35: Appendix A. I/O Port Pin Assignment
IDE Port Connector: IDE1 Type: 40-pin (2 x 20) box header Description Description Reset Ground Ground N/C (Vcc) Ground IOW-/STOP Ground IOR-/HDMARDY Ground IORDY/DDMARDY IDESEL DACK- Ground CBLID CS0 (MASTER CS) CS1 (SLAVE CS) LED ACT- Ground 3302011 User’s Manual... - Page 36 Connector: IDE2 Type: 44-pin (2 x 22) box header Description Description Reset Ground Ground Ground IOW-/STOP Ground IOR-/HDMARDY Ground IORDY/DDMARDY Ground DACK- Ground ASP1 Ground Ground Ground 3302011 User’s Manual...
-
Page 37: Fdd Port
Ground DRIVER SELECT B- Ground DRIVER SELECT A- Ground MOTOR ENABLE B- Ground DIRECTION- Ground STEP- Ground WRITE DATA- Ground WRITE GATE- Ground TRACK 0- Ground WRITE PROTECT- Ground READ DATA- Ground HEAD SELECT- Ground DISK CHANGE- 3302011 User’s Manual... -
Page 38: Serial And Parallel Port
D21 (2) SELECT INPUT1 (2) D31 (2) Ground D41 (2) Ground D51 (2) Ground D61 (2) Ground D71 (2) Ground ACKNOWLEDGE1 (2) Ground BUSY1 (2) Ground PAPER EMPTY1 (2) Ground SELECT1 (2) AUTO FEED1 (2) Ground Ground 3302011 User’s Manual... -
Page 39: Usb Port
Type: 5-pin (1 x 5) header for SIR Port Description IRRX Ground IRTX PS/2 Keyboard and Mouse Port Connector: JPS2 Type: 10-pin (2 x 5) header connector Description Description Keyboard Data Mouse Data Ground Ground Ground Ground Keyboard Clock Mouse Clock 3302011 User’s Manual... -
Page 40: Appendix B. Flash The Bios
File name of the tool is “awdflash.exe”, it’s the utility that can write the data into the BIOS flash ship and update the BIOS. Flash Method Get the “.bin” file including the image of new BIOS you want to update. Power on the system and flash the BIOS. Re-star the system. 3302011 User’s Manual... -
Page 41: Appendix C. System Resources
0278-027A Parport 02E8-02EE Serial 02F8-02FE Serial 0376-0376 viadsk 0378-037A Parport 03B0-03BB VgaSave 03C0-03CF S3Inc 03C0-03DF VgaSave 03D4-03DB S3Inc 03E8-03EE Serial 03F0-03F5 Floppy 03F6-03F6 viadsk 03F7-03F7 Floppy 03F8-03FE Serial D000-D007 viadsk D008-D00F viadsk DC00-DCFF alcxnt E000-E003 alcxnt 3302011 User’s Manual... -
Page 42: Memory Address Map
S3 Graphics Twister xEC100000 - xEC1001FF Realtek RTL8139(A/B/C/8130) PCI Fast Ethernet NIC xEC101000 - xEC1011FF Realtek RTL8139(A/B/C/8130) PCI Fast Ethernet NIC xFEE00000 - xFEE0FFFF System board extension for PnP BIOS xFFFE0000 - xFFFFFFFF System board extension for PnP BIOS 3302011 User’s Manual... -
Page 43: System Irq And Dma Resource
IRQ Holder for PCI Steering Communications Port (COM3) Communications Port (COM4) PS/2 Compatible Mouse Port Numeric data processor Primary IDE controller (dual fifo) VIA Bus Master PCI IDE Controller Secondary IDE controller (dual fifo) VIA Bus Master PCI IDE Controller 3302011 User’s Manual... - Page 44 C.3.2 DMA Channel Device (free) (free) Standard Floppy Disk Controller (free) Direct memory access controller (free) (free) (free) 3302011 User’s Manual...
- Page 45 Notes (This page left blank intentionally) 3302011 User’s Manual...
-
Page 46: Contact Information
Contact Information Thank you for purchasing from Global American Inc. We will stand by our slogan, Integration with Integrity . Please let us know how your product is performing and if we can help you with any future product lines.
