Display Explanation; Installing Batteries - Physio Logic Manual InflateBlood Pressure Monitor Instruction Manual

No. of Memory
Sequence
Appears when manual
cuff deflation is needed.
Shows the pulse rate
per minute.
Appears when batteries should be replaced.
1. Press down and lift the battery cover in the direction of the arrow
to open the battery compartment.
2. Install 4 "AA" 1.5 V alkaline batteries according to the
indication inside the compartment.
3. Replace the battery cover by inserting the bottom tabs first, then
push in the top end of the battery cover.
Replace batteries when:
1. Low battery icon appears on display.
2. The On / Off / Start button is
pushed and nothing appears
on display.

Display Explanation

Installing Batteries

7
Systolic pressure
Diastolic pressure
Pulse rate
Appears when manual
cuff inflation is needed.
Occurs when a error was
made during measurement.
