- Page 1 Manual Inflate Blood Pressure Monitor Instruction Manual Features: • Digital Technology • Auto memory for up to 60 readings • Semi-Automatic • Easy-to-read Display 106-900...
-
Page 2: Table Of Contents
Table of Contents Statement of accuracy ....... . . 3 About blood pressure . -
Page 3: Statement Of Accuracy
Statement of Accuracy Blood pressure measurements determined with Physio Logic™ are equivalent to those obtained by a trained observer using cuff / stethoscope auscultation method, within the limits prescribed by the American National Standard for Electronic or Automated Sphygmomanometers (ANSI /AAMI). -
Page 4: Blood Pressure Standard
Blood Pressure Standard The Joint National Committee on prevention, detection, evalua- tion, and treatment of high blood pressure has developed a blood pressure standard, according to which areas of low and high risk blood pressure are identified. This standard is a guideline as blood pressure varies among different people and different age groups... -
Page 5: Before Taking A Measurement
Before Taking a Measurement To help you obtain more accurate readings: • Urinate if necessary. • Remove any clothing and jewellery from your left arm. Placing the cuff on anything other than bare skin can result in an inaccurate reading. •... -
Page 6: Name / Function Of Each Part
Name / Function of Each Part On / Off button Memory recall button LCD display Battery compartment Arm cuff Air tube and connector Air release valve Inflation bulb... -
Page 7: Display Explanation
Display Explanation Systolic pressure Diastolic pressure No. of Memory Pulse rate Sequence Appears when manual Appears when manual cuff deflation is needed. cuff inflation is needed. Shows the pulse rate Occurs when a error was per minute. made during measurement. Appears when batteries should be replaced. -
Page 8: Recalling Memory
Recalling Memory 1. To recall stored blood pressure readings from memory, simply press the Memory button. The last set of memorized readings will be displayed. 2. Another press of the Memory button will recall the previous set of readings. 3. All readings stored in memory will be displayed with its sequence number. -
Page 9: Applying The Arm Cuff
Applying the Arm Cuff 1. Insert the cuff’s connecting tube into the unit. 2. Unwrap the arm cuff, leaving the “Index” end of the cuff through the D-ring of the cuff. 3. Put your left arm through the cuff loop. Position the artery mark ( ) at the middle of your arm above the elbow, in line with your middle finger. -
Page 10: Taking A Measurement
Taking a Measurement 1. Press the On / Off button. All displays will appear for approximately one second before returning to “0”. The unit is ready for measurement at this point. If the downward arrow “ ” flashes, release the remaining cuff air by pressing the “Air Release Valve”... -
Page 11: Troubleshooting
Troubleshooting Symptom: No display when the On / Off button is pressed. Correction: If the batteries have run down, replace them with new alkaline batteries. If the batteries are not in the correct position, re-insert them with the correct polarities. Symptom: mark shown on display or the blood pressure value is displayed excessively low (high). -
Page 12: Specifications
Specifications Measurement method : Oscillometric Measurement range : Pressure: 20 to 280 mmHg ; Pulse: 40 to 180 beats / min. Pressure sensor : Semi conductor Accuracy : Pressure: ± 3 mmHg; Pulse: ± 5 % of reading Inflation : Manual inflation Deflation : Automatic pressure release valve Memory capacity...
