Applying The Arm Cuff - Physio Logic Manual InflateBlood Pressure Monitor Instruction Manual

1. Insert the cuff's connecting tube into the unit.
2. Unwrap the arm cuff, leaving the "Index" end of the cuff through
the D-ring of the cuff.
3. Put your left arm through the cuff loop. Position the artery mark
( ) at the middle of your arm above the elbow, in line with your
middle finger. Tighten the cuff by pulling the "Index" end of the
cuff (snug, not tight).
4. Turn your left palm upward
and place the edge of the arm
cuff at approximately 2 to 3
cm (0.8" - 1.2") above the
inner side of the elbow joint.
5. If the Index line falls within
the OK range, indicated at the
edge of the cuff, this cuff is
suitable for your use. If the
Index line falls out of the OK
range, you may need a
different size cuff.

Applying the Arm Cuff

9
2 3 cm / 0,8" 1,2"
