Summary of Contents for Koldfront PAC1405
- Page 1 Portable Air Conditioner PAC1405 Owner’s Manual For more information on other great Koldfront products on the web, go to http://www.avallon.com...
-
Page 2: Important Safety Information
Do not use the TEST and RESET buttons as an ON/OFF switch. Electrical products should not be disposed of with household waste. Please contact your local recycling center for more information on how to recycle electronic waste. Koldfront Portable Air Conditioner... -
Page 3: Table Of Contents
Table of Contents IMPORTANT SAFETY INFORMATION ..............II INTRODUCTION ....................1 PARTS IDENTIFICATION ..................2 ......................2 ......................2 RONT INSTALLING THE CARBON FILTER ..............3 WINDOW KIT INSTALLATION INSTRUCTIONS ..........4 ..........4 REPARATIONS FOR INSTALLING THE WINDOW KIT ................ -
Page 5: Introduction
Introduction Thank you for purchasing this portable air conditioner. This manual contains important information regarding the proper installation, use and maintenance of your portable air conditioner. Following this manual will ensure that your product will work at its peak performance and efficiency. Please save the original product packaging in case you need to safely transport your portable air conditioner. -
Page 6: Parts Identification
Window Plate Window Plate with Hole Control Panel Oval Window Kit Adapter Front Air Vent/ Louvers Exhaust Hose Handle Caster Back View Pre-filter Air Intake Exhaust Outlet Upper Drain Valve Air Intake/ Compressor pre-filter Lower Drain Valve Koldfront Portable Air Conditioner... -
Page 7: Installing The Carbon Filter
Installing the Carbon Filter Your portable air conditioner ships with a pre-filter and an activated carbon filter. The carbon filter will help remove contaminates and odors from the air. It is recommended you replace the carbon filter every two to three months, or as needed. It is necessary to clean the pre-filter periodically. -
Page 8: Window Kit Installation Instructions
Your window kit can be installed on a horizontal or vertical sliding window as shown in the following pictures: Follow the instructions on the next pages to install the window kit. Koldfront Portable Air Conditioner... -
Page 9: Installing The Window Plates
Installing the window plates 1. Open your window and place the window kit with grooved side facing outward on the window sill. Then, slide the window kit plate to fit the width of the window. You can use screws to secure the window kit plate from sliding. CAUTION: Secure your 2. -
Page 10: Attaching The Oval Adapter To The Exhaust Hose
4. Roll the unit towards the window kit. Leave a space that is at least 20 inches to the wall. Koldfront Portable Air Conditioner... -
Page 11: Connecting The Exhaust Hose To The Unit
Connecting the exhaust hose to the unit 5. Align the slots on the hose connector to the tabs and snap into the back of the unit. Connecting the oval adapter to the window kit 6. Push the oval adapter through the window kit hole until it snaps in place. -
Page 12: Notes About The Exhaust Hose
B: You must remove the exhaust hose if the unit is in Fan Mode or Dehumidify mode. Note: the exhaust hose may be compressed or extended according to your installation requirements; however, it is recommended to keep the exhaust hose length at a minimum. Koldfront Portable Air Conditioner... -
Page 13: Draining The Unit
Draining the Unit The unit will need to be drained if set to dehumidify mode. When the portable air conditioner is in cooling mode, it will remove moisture from the air. The condensed water from the air will be collected in an internal reservoir and will be evaporated and exhausted out of the exhaust hose. -
Page 14: Control Panel Overview
Function LED Display The LED can display the ambient temperature in Fan and Dehumidify Mode, set temperature in Cool Mode, and the number of hours when setting the timer. Infrared Receiver for the remote control. Sensor Koldfront Portable Air Conditioner... -
Page 15: Operating The Control Panel
Operating the Control Panel Use the Power button to turn the portable air conditioner on and off. Power Auto-Restart: If power to the unit is interrupted, the air conditioner will restart itself in its last used mode/settings once power is restored. The compressor will restart after 3 minutes. -
Page 16: Fan Button
2 degrees after an additional 30 minutes and maintain this temperature for 7 hours before it returns to the original temperature and ends the Sleep mode. The Sleep mode is not available in Dehumidify and Fan Only modes. Koldfront Portable Air Conditioner... -
Page 17: Using The Remote Control
Using the Remote Control The remote control can be used instead of the control panel to remotely operate your portable air conditioner. The functions on the remote are the same as on the control panel. NOTES: Be careful not drop Up Button the remote control. -
Page 18: Normal Sounds
Clean the air conditioner and filters regularly to maximize performance and efficiency, and prolong the unit’s life. Be sure to always unplug the air conditioner from the power outlet before cleaning. Follow the instructions on the next page to clean the portable air conditioner. Koldfront Portable Air Conditioner... -
Page 19: Cleaning The Unit
2-3 needed. Allow the pre-filter to air dry in a cool and shaded place. months or as needed. Contact Dry thoroughly before reinstalling. Koldfront retailers for replacement filters. Warning: Never operate the unit without the filters. Preparation for Storage... -
Page 20: Troubleshooting
The control panel Unit may have a faulty Contact customer lights blink randomly control panel service Koldfront Portable Air Conditioner... -
Page 21: Troubleshooting Continued
Troubleshooting continued Issue Possible Cause Solution My air conditioner is Unit is not operating in Set the unit to be in not cooling at all cooling mode cooling mode, and lower the set temperature (pg. 11) The compressor is not The compressor may take up to 3 minutes to turn on, or longer if it is... -
Page 22: Specifications
Portable Air Conditioner Model PAC1405 Voltage/Frequency AC 115V~60Hz Input Power 1480W Current 13.1A Color White Dehumidifying capacity 70 Pints/Day Coolant R-410A Timer 24 Hour Dimensions 19” x 32” x 16” W x H x D Weight 75 lbs Koldfront Portable Air Conditioner... -
Page 23: Product Warranty
Product Warranty Warranty Period Koldfront will be responsible for: Consumer will be responsible for: 1st year All costs for repairing or replacing parts and/or unit which proves to All transportation costs after 90 days. be defective. All transportation costs in the first 90 days. - Page 24 AVALLON GLOBAL, LLC 3736 Bee Cave Rd. STE 1 #188 West Lake Hills, TX 78746 Toll Free: 1-866-471-7427 Web: http://www.avallon.com E-mail: service@avallon.com Product contents and specifications may change without notice. Copyright © 2013 Avallon Gobal, LLC...
