  • Page 1 Portable Air Conditioner PAC10013CBL / PAC10013HBL Owner’s Manual For more information on other great EdgeStar products on the web, go to https://www.edgestar.com To use the EdgeStar self-diagnostic tool, go to https://support.edgestar.com V2.0 - 03132019...
  • Page 2 Important Safety Information Improper handling can cause serious damage to the appliance and / or to the user. This portable air conditioner is not intended for use by children. Children should be supervised to ensure that they do not play with this product. Improper handling can cause serious damage to the appliance and/or to the user.

  • Page 3: Operation Of Safety Plug

    Operation of Safety Plug Note: Electrical products should not be disposed of with household waste. Please contact your local recycling center for more information about how to recycle electronic waste. Your portable air conditioner is supplied with a Leakage-Current Detection and Interruption (LCDI) safety plug.

  • Page 4: Table Of Contents

    Table of Contents IMPORTANT SAFETY INFORMATION .......................... I OPERATION OF SAFETY PLUG ..........................II TABLE OF CONTENTS ..............................III INTRODUCTION ................................1 PARTS IDENTIFICATION .............................. 2 Front View ..................................2 Back View ..................................2 WINDOW KIT INSTALLATION INSTRUCTIONS ......................3 Preparations for Installing the Window Kit ........................

  • Page 5: Introduction

    Introduction Thank you for purchasing this Koldfront portable air conditioner by EdgeStar. We hope that this purchase will be the beginning of a lasting and rewarding relationship between you and EdgeStar. We will provide the customer support and exemplary products necessary to nurture that relationship.

  • Page 6: Parts Identification

    Parts Identification Caution: Make sure the rubber drain plug is firmly installed to the Drain Port to prevent leaking. Front View 1. Control Panel 2. Air Outlet 3. Handle 4. Caster Back View 5. Pre-Filter 6. Air Outlet (Heat Exchanger) 7.

  • Page 7: Window Kit Installation Instructions

    Window Kit Installation Instructions Preparations for Installing the Window Kit You must vent your portable air conditioner when running it in cooling or heating (PAC10013HBL only) mode. Your unit includes a window exhaust kit that can be used to vent the unit out of a window.

  • Page 8: Installation

    Installation 1. Attach the hose connectors (#2 and #3) to the ends of the exhaust hose (#1) to create the exhaust assembly. 2. Slide the hose connector for the air conditioner (#2) into place on the rear panel and push the rocker switch to the locked position.
  • Page 9 4. Open your window and place the window kit either horizontally or vertically into the window opening. Adjust the plates to fit the width of the window opening then lock the plates into place with the wingnuts mounted to plate A. 5.

  • Page 10: Control Panel Operation

    Control Panel Operation Buttons Function Power Powers the unit on or off. Timer Turns the timer on and off. Changes between cool, dehumidify, heat (PAC10013HBL only), and Mode fan modes. The indicator light will turn on next to the mode you set. Heating mode will display a red indicator light (PAC10013HBL only).

  • Page 11: Using The Control Panel

    Using the Control Panel Power Use the Power button to turn the portable air conditioner on and off. By default when you first use the power button, the unit will begin to operate in cooling mode. The unit will remember the last used mode / settings if you shut it down and restart it.
  • Page 12 Heating Mode (PAC10013HBL only) The PAC10013HBL model air conditioner can work as a heat pump. The exhaust hose must be vented to the outside so that it can expel the cold air. To operate the unit in heat mode: 1. Make sure the power cord is plugged into a power outlet. 2.
  • Page 13 LED Display The LED Display will show the ambient temperature by default. Pressing either the Up or Down button will show the set temperature for 15 seconds, and then revert to the room temperature. You can switch between Fahrenheit and Celsius by pressing both the Up and Down Buttons simultaneously for three (3) seconds.

  • Page 14: Using The Remote Control

    Using the Remote Control Note: Be careful not to drop the remote control. Do not place the remote control in a location where it is exposed to direct sunlight. The remote control can be used instead of the control panel to remotely operate your portable air conditioner.

  • Page 15: Installing The Batteries

    Installing the Batteries 1. Remove the cover on the back of the remote control. 2. Insert the batteries with the (+) and (-) ends pointing in the correct direction, as indicated in the image above. 3. Slide the cover back on. Caution: Use only AAA batteries.

  • Page 16: Maintenance

    Maintenance Clean the air conditioner and pre-filter regularly to maximize performance and efficiency, and to prolong the unit’s life. Be sure to always unplug the air conditioner from the power outlet before cleaning. Cleaning the Unit Use a soft dry cloth to wipe the body of the air conditioner clean. If necessary, use lukewarm water to dampen a cloth to clean the unit.

  • Page 17: Preparation For Storage

    Preparation for Storage If you are not going to be using the unit for an extended period of time, follow the instructions below before storing your unit: 1. Drain all the water from the unit’s reservoir. 2. Operate the unit in fan mode for a few hours to thoroughly dry any moisture left on the coils inside the unit.

  • Page 18: Troubleshooting

    Troubleshooting Follow the troubleshooting guide below to resolve common issues. Issue Possible Cause Solution My air conditioner is not The unit is not receiving power. Make sure the unit is plugged functioning at all. in to a grounded outlet. Check the circuit breaker.
  • Page 19 Issue Possible Cause Solution My air conditioner is not cooling The unit is not operating in Set the unit to be in cooling mode, at all. cooling mode. and lower the set temperature. The compressor is not on. The compressor may take up to 3 minutes to turn on, or longer if it is too warm.

  • Page 20: Specifications

    Specifications Description of product Portable Air Conditioner Model PAC10013CBL / PAC10013HBL Voltage / Frequency AC 115V ~ 60Hz Input Power 1150 W (Cooling) 1150 W (Heating- PAC10013HBL only) Current 9.5 A (Cooling) 9.5 A (Heating- PAC10013HBL only) Cooling Capacity (SACC)

  • Page 21: New Portable Air Conditioner Btu's

    New Portable Air Conditioner BTU’s You may notice that the cooling capacities (in British Thermal Units or BTU’s) labeled on portable air conditioners (PAC’s) are now lower than on models produced prior to October 1, 2017. This is because the labeling on new productions of PAC’s must follow a new federal test standard that was established by the Department of Energy: 10 CFR 430, subpart B, appendix CC.

  • Page 22: Edgestar Limited Warranty

    EdgeStar Limited Warranty One (1) Year Parts & Ninety (90) Days Labor This product is warranted by EdgeStar to be free from defective workmanship and materials, subject to any conditions set forth as follows: WHAT IS COVERED: LABOR: For a period of NINETY (90) DAYS from the date of original purchase, labor will be performed free of charge at an authorized EdgeStar repair facility.
