Summary of Contents for Koldfront PAC9000W
-
Page 2: Table Of Contents
Table of Contents Table of Contents -------------------------------------------------------- -----1 Thank You----------------------------------------------------------------- -----2 Energy Saving Tips------------------------------------------------------ -----2 Notes------------------------------------------------------------------------ -----2 Technical Specifications------------------------------------------------------3 Safety Precautions-------------------------------------------------------------4 Parts and Accessories---------------------------------------------------------6 Installation----------------------------------------------------------------------7 -Exhaust Hose Installation----------------------------------------------------------------8 -Window Installation----------------------------------------------------------------------9 -Wall Installation---------------------------------------------------------------------------9 Operation -----------------------------------------------------------------------10 -Control Panel------------------------------------------------------------------------------10 -Control Panel Key------------------------------------------------------------------------12 -Remote Control----------------------------------------------------------------------------12 -Modes---------------------------------------------------------------------------------------12 -Water Drainage-----------------------------------------------------------------------------14 Maintenance--------------------------------------------------------------------15... -
Page 3: Thank You
Rooms that are too large will never cool completely. 2. Be careful not to obstruct the air flow coming out of the portable air conditioner. A powerful, unobstructed airflow is crucial for optimum cooling. -
Page 4: Technical Specifications
Cooling conditions: Dry bulb/Wet bulb: 95/75°F according to European standard EN14511-2004 Operating limits for cooling: Maximum ambient conditions: Dry bulb/Wet bulb: 100/80° F Minimum ambient conditions: Dry bulb/Wet bulb: 64/57°F PAC9000W 115 Volts / 60 Hertz See Label on Unit 38 Pints per 24 Hours 500g... -
Page 5: Safety Precautions
3 hours prior to turning it on. 8. Always place the unit on a level surface. 9. In order to cool, the hot air from the exhaust port in the rear of the portable air conditioner must be exhausted outside the room. - Page 6 15. Do not tilt the portable air conditioner. 16. Do not cover or obstruct the intake or outlet grills. 17. Do not use the portable air conditioner in a wet room- such as a bathroom or laundry room- to avoid the possibility of shock.
-
Page 7: Parts And Accessories
Parts and Accessories 1) Parts Ai r I nl et Ai r Fi l t er C ast er O per at i on Panel Ai r O ut l et C ont r ol Si gnal R ecept or Ai r I nl et f or condenser si de H ot Ai r D i schar gi ng Por t... -
Page 8: Installation
W at er D r ai n H ose Installation When you use this portable air conditioner as an air conditioner or a dehumidifier, the hot air should be exhausted out of the room. When the unit is operating in fan-only mode, no exhaust is required. -
Page 9: Exhaust Hose Installation
1) Exhaust Hose Installation The exhaust hose must be installed onto the unit before any further installation can occur. a) Pull out about 6” of one end of the exhaust hose. b) Screw the exhaust connector onto the exhaust hose in a clockwise motion. c) Snap the exhaust connector into place in the back of the unit. -
Page 10: Window Installation
If necessary, the window kit can be cut to size. e) Place the window kit in your window, with the exhaust hole as near as possible to the portable air conditioner. f) Close the window on the window kit. For long-term installation or to make the window kit more stable, you may want to screw the window kit into your window frame. -
Page 11: Operation
Feed as much exhaust hose as is needed through the hole. Notes: Be sure to cover the hole when it is not being used by the portable air conditioner. Be sure to have a qualified person make the hole to avoid the possibility of injury or of unintended damage to your room. - Page 12 Temperature / Time buttons, the timer display will stop flashing. Now you can set the thermostat setting that the portable air conditioner will use when it starts up. These settings will disappear from the LCD display 5 seconds after they are set, but the unit will remember them.
-
Page 13: Control Panel Key
3) Press the Mode button until the icon “ 4) Select the fan speed by using the Fan button. During the Auto mode, the portable air conditioner tries to maintain an 81°F Fahr enhei t t em p C ent i gr ade t em p... - Page 14 temperature in the room. If the ambient temperature is higher than 81°F, the unit will operate in Cooling mode. If the ambient temperature is below 81°F, the unit will operate in Fan-only mode. Note: The exhaust hose must be attached for proper operation in Auto mode. Dehumidifying 1) Plug the power cord into a power outlet.
-
Page 15: Water Drainage
Fan-only mode does not require that the exhaust hose be attached. 4) Water Drainage All air conditioners dehumidify the air as they cool. This portable air conditioner is designed to evaporate and exhaust this condensed water (sometimes called condensate). When using the Cooling or Dehumidifying modes under extremely humid conditions, the internal water tray may fill completely. -
Page 16: Maintenance
When the flow of water stops, you can turn off the portable air conditioner. Remove the drain hose and reinsert the rubber stopper. The unit will now be almost completely drained. If you were draining the unit to allow it to continue cooling or dehumidifying, simply turn the unit back on to the settings you want. -
Page 17: Long Term Storage
5) Take out the filter. Clean and dry it (see the instructions above), and reinstall it. 6) Cover the portable air conditioner to protect it from dust. It is generally a good idea to store the unit in its original box and packaging. -
Page 18: Troubleshooting
Troubleshooting Problem The portable air conditioner does not turn on The unit turns on, but the compressor does not turn on- the fan runs, but there is no cooling The air coming out of the unit is Possible Cause There was a power failure... - Page 19 You may need additional cooling or another air conditioner You may need additional cooling or another air conditioner, or you may need to add insulation Make sure the unit is level Call for service Move the unit to a location with a...
-
Page 20: Circuit Diagram
Other issues Circuit Diagram LC D D i spl ay M ai n C ont r ol PC B O per at i on Panel PC B R ecept or PC B PO W ER SU PPLY C 1: R unni ng C apaci t or For Fan M ot or of C ondenser Si de C 2: R unni ng C apaci t or... -
Page 21: Limited Warranty
Limited Warranty This Koldfront product is warranted to be free from defective workmanship and materials for the first year following the date of original purchase. Replacement parts will be supplied free of charge for the first year following the date of original purchase. Labor will be performed free of charge for the first 90 days following the date of original purchase. - Page 22 All replacement parts and units will be new, remanufacturered, or refurbished. All products and components replaced by Koldfront under warranty service become the property of Koldfront. OBTAINING WARRANTY SERVICE: Contact Koldfront for troubleshooting assistance and warranty service authorization at 1-866-319-5473. Please have your order receipt available to confirm the date of purchase. Once an Koldfront authorized representative has confirmed that your product is eligible for warranty service, the product must be returned to an Koldfront authorized repair facility.
