Related Manuals for BT V-IP Featurehone
Summary of Contents for BT V-IP Featurehone
- Page 2 Extension Pairing The V-IP Featurehone can be paired with another extension. For example, a user can have two paired extensions, one in the office and one at home. By entering a 3-digit code in either extension, the office extension can be transferred to the user’s home and the home extension transferred to the office.
- Page 3 Connect the blue cable to the LAN connector on the Transformer and connect the other end of the cable to an Ethernet port on the Broadband Module (V-IP Featurephone connected locally to the BT Versatility) or broadband router (V-IP Featurephone installed at a remote location).
- Page 4 Programming the V-IP Featurephone Programming the V-IP Featurephone involves entering the REMOTE SYSTEM IP address. This IP address will be provided by the BT Versatility system administrator. All other parameters remain at their default settings and should not be changed.
- Page 5 << >> Enter the REMOTE SYSTEM IP address of the BT Versatility using digits. For example, 3 079 77 006. The IP address will be supplied by the BT Versatility system administrator. Select EXIT SAVE CHANGES ? ...
- Page 6 Quick Reference User Guide Using the V-IP Featurephone The V-IP Featurehone provides the same functionality as the BT Versatility Featurephone. It has the same menu system with Program, Message, Directory, ISDN, as well as 6 programmable keys. It also has a Voice Message indication light, speaker with volume control.
- Page 7 V-IP Featurephone Quick Reference User Guide Answering and making calls Answer a call that is ringing on the VIP Phone using the handset Pick up the handset or Select Answer the call and/or pick up the handset. Answer a call that is ringing on the VIP Phone using hands-free Select ...
- Page 8 V-IP Featurephone Quick Reference User Guide Diverting calls Divert all calls Scroll down Select Divert Select Divert all calls Select the required extension from the display or key the Extension number, or Key 9 and the target external number, (for incoming external calls only).
- Page 9 V-IP Featurephone Quick Reference User Guide external calls only). Or press “Divert to voicemail” Cancel divert a call on no answer Scroll down Select Divert Select Divert on no answer and the diversion is cancelled. Diverting Group calls Divert all calls Scroll down Select ...
- Page 10 V-IP Featurephone Quick Reference User Guide Divert calls when your group does not answer (after four rings) Scroll down Select Group Divert Select the group which is to be diverted Select Divert on no answer Select the required extension from the display or key the Extension number, or Key 9 and the target external number, (for incoming external calls only).
- Page 11 V-IP Featurephone Quick Reference User Guide Retrieve messages from your voice mailbox Select New voice messages Enter your Extension number. You will be prompted to Enter your Voice Mailbox Password, followed by #. Select Play Change your Voice Mailbox Password Press , then Select ...
- Page 12 V-IP Featurephone Quick Reference User Guide Select Confirm Press to finish programming. Dial a number from your personal speed dial list Press , then Select Personal speed dial Select the desired location and the number will be dialled. System speed dials Any extension can programme the 00 system speed dial numbers once the system password is entered by them.
- Page 13 V-IP Featurephone Quick Reference User Guide Troubleshooting the V-IP Featurephone In the event that the V-IP Featurehone does not work, carry out the following checks. Can a PC directly connected to the Check your broad- broadband router band connection browse ?
- Page 14 Offices Wordwide The telecommunications services described in this publication are subject to availability and may be modified from time to time. Services and equipment are provided subject to British Telecommunications plc’s respective standard conditions of contract. Nothing in this publication forms any part of any contract. ©British Telecommunications plc 2005 Registerd office: 81Newgate Street, London EC1A 7AJ Registered in England No.
